DECLARATION OF CONFORMITY WITH FCC RULES FOR
ELECTROMAGNETIC COMPATIBILITY
We, Belkin Components, of 501 West Walnut Street, Compton
CA 90220, declare under our sole responsibility that the product:
Belkin Components F5U111
to which this declaration relates:
Complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
CE Declaration of Conformity
We, Belkin Components, declare under our sole responsibility
that the
Belkin Components F5U111
to which this declaration relates, is in conformity with General
Emissions Standard EN50081-1 and with Generic Immunity
Standard EN50082-1 1992.
Belkin Components
501 West Walnut
Compton • CA • 90220-5221
Phone 800.2BELKIN (223.5546)
310.898.1100
Fax
310.898.1111
© 1999 Belkin Components. All Rights Reserved. All Trade Names Are Registered Trademarks Of Respective Manufacturers Listed.
Belkin Components, Ltd.
13 Gatelodge Close
Round Spinney • Northampton • NN3 8RX
Phone +44 (0) 1604678300
Fax
www.belkin.com
usb.belkin.com
+44 (0) 1604678330
