- Page 1 IP2250EN Ditec PWR25H/35H Technical Manual Automation for hinged gates (translation of the original instructions) www.entrematic.com...
-
Page 2: Table Of Contents
Contents Subject Page General safety precautions Declaration of incorporation of partly completed machinery Machinery Directive Technical specifications Standard installation Gearmotor dimensions and references Installation Preliminary checks Bracket fastening Positioning usage Gearmotor installation Adjusting the mechanical end stops Electrical connections Magnetic limit switches adjustment (PWR35H only) Routine maintenance plan Troubleshooting Disposal... -
Page 3: General Safety Precautions
1. General safety precautions Failure to respect the information given in this manual may cause personal injury or damage to the device. Keep these instructions for future reference This installation manual is intended for qualified personnel only. Installation, electrical connections and adjustments must be performed in accordance with Good Working Methods and in compliance with the present standards. -
Page 4: Declaration Of Incorporation Of Partly Completed Machinery
The manufacturer Entrematic Group AB, with headquarters in Lodjursgatan 10, SE-261 44 Landskrona, Sweden, declares that the Ditec PWR25H / PWR35H automation for swing gates: - is designed to be installed on a manual gate to form a machine pursuant to Directive 2006/42/ EC. -
Page 5: Technical Specifications
3. Technical specifications Tab. 3.0 PWR25H PWR35H Power Maximum 5.5A power Absorbed power 55W nom. / 120W max 65W nom. / 132W max Maximum thrust 2000 N 3000 N Maximum stroke 350mm 450mm Opening time 10÷60 s/90° 14÷80 s/90° 80 cycles/day [max]... - Page 6 Severity index Severity index Two examples of the operator durability calculation are shown below: PWR25H PWR35H Example of the duration calculation for PWR25H Wing weight >150 Kg 150.000 300.000 140.000 280.000 Wing width >2m 130.000 260.000...
-
Page 7: Standard Installation
2 x 1 mm² Antenna (integrated into the flashing light) coaxial 58 Ω Key selector switch 4 x 0.5 mm² Digital combination wireless keypad Actuator PWR25H 2 x 1.5 mm² Actuator PWR35H Actuator PWR35H with magnetic limit switches 3 x 1.5 mm² Photocells 4 x 0.5 mm²... -
Page 8: Gearmotor Dimensions And References
5. Gearmotor dimensions and references PWR35H PWR25H Fig. 5.1 Fig. 5.2 Ref. Description Rear cover Release lock hatch Cover fastening screw Release key Release pin Front cover Model PWR25H PWR35H... -
Page 9: Installation
Reducing measurement [B], you increase the degrees of gate opening. Measurements [A] and [B] must, however, be compatible with the effective stroke of the piston. min 60 con apertura a 90° min. 60 with 90° opening Tab. 6.1 95° 100° 110° PWR25H 90° 90° 90° 95° 100° 110° PWR35H 90°... -
Page 10: Bracket Fastening
NB: If necessary, the front bracket [14] can be rotated and fixed as shown in figures [B], in this way the operator position will be higher by about 40 mm. Configuration [A] is the one recommended for a greater mechanical resistance. PWR25H 3xØ9 80 (S) -
Page 11: Positioning Usage
PWR35H 4xØ9 3xØ9 80 (S) 110 (S) 140 (S) Ø17,2 6.3 Positioning template usage The positioning of the brackets can be greatly simplified by using the positioning template (optional accessory), which allows to establish with certainty the fixing positions and distances of a bracket with respect to the other during installation. -
Page 12: Gearmotor Installation
6.4 Gearmotor installation • Open the release lock hatch [8], loosen the screw [9] and remove the rear cover [7]. • Release the piston by inserting the key [10] in the appropriate pin [11] and turn it counter-clock- wise as indicated by the arrow. •... -
Page 13: Adjusting The Mechanical End Stops
6.5 Adjusting the mechanical end stops The mechanical end stops are adjusted in steps of 4mm. Example: GATE WING STOP at stroke [R] = 340 – 344 – 348mm, etc. If the stopping point of the gate wing does not coincide with the required position, remove the mechanical end stop and rotate it 180°... -
Page 14: Electrical Connections
• Connect the various wires as shown in the wiring diagram in Fig. 6.4; • Secure the rear cover [9] to the gearmotor. The electrical wiring and start-up of the gear-motors PWR25H and PWR35H are shown in the installation manuals of control panels LCU30 and LCU40. -
Page 15: Magnetic Limit Switches Adjustment (Pwr35H Only)
6.7 Magnetic limit switches adjustment (PWR35H only) The front cover must be removed for the maintenance, adjustment and/or installation of the magnetic limit switches: • Loosen screw [11], slide the cover [12] forward and lift the front of it. Fig. 6.5 •... -
Page 16: Routine Maintenance Plan
7 . Routine maintenance plan 7.1 Maintenance every 6 months or 10,000 cycles Perform the following operations and checks every 6 months or based on the intensity of use of the automation. Disconnect the 230 V~ power supply and batteries (if present): - Clean and lubricate the gate's rotation pins, hinges and drive screws with neutral grease. -
Page 17: Troubleshooting
8 . Troubleshooting Problem Possible cause Operation The gate doesn't No power supply. Check that the mains power supply is open or close. present. Gearmotor released. See release instructions. Photocells interrupted. Check that the photocells are clean and operating correctly. Permanent stop command. -
Page 19: Operating Instructions
Operating instructions General safety precautions These precautions are an integral and essential part of the product and must be supplied to the user. Read them carefully since they contain important information on safe in- stallation, use and maintenance. These instructions must be kept and forwarded to all possible future users of the system. -
Page 20: Manual Release Instructions
All the rights concerning this material are the exclusive property of Entrematic Group AB. Although the contents of this publication have been drawn up with the greatest care, Entrematic Group AB cannot be held responsible in any way for any damage caused by mistakes or omissions. We reserve the right to make changes without prior notice. - Page 21 Installer's stamp Operator Date of intervention Technician's signature Customer's signature Intervention performed...
- Page 22 Entrematic Group AB Lodjursgatan 10 SE-261 44, Landskrona Sweden www.entrematic.com...
