TECHNICAL SPECIFICATIONS
Magnification (x) 10
Objective lens diameter (mm) 42
Type of prism (type/material) roof
Lens coating (CL/FC/BMC/FBMC) Fully multi-coated
Field of view (angle) 5
Field of view (Ft/1,000yds) 261
Field of view (m/1,000m) 87
Minimum focus distance (m/ yd) 13 / 15
Diopter range -4 to +4
Interpupillary distance. (in/mm) 2.2 - 2.8 / 58-72
Waterproof/nitrogen purged(yes/no) yes
IP Rating IP67, 1m for 1hour
FDA Class 1 / IEC
Laser type
Class 1
INCLUDED ACCESSORIES
Nylon carrying case Neck strap
2
Accuracy, yd/m +-1
Max range (reflective), yd/m 1312 / 1200
Max range (trees), yd/m 1202 / 1100
Max range (deer), yd/m 1093 / 1000
Min Range, yd/m 5 / 4.5
Measuring time Less than 1 second
Auto Power Off After 35 seconds
Battery type CR2
Battery life At least 5,000 actuations
Length, in/mm 6.3 / 160
Width, in/mm 4.9 / 124
Height, in/mm 2.4 / 60
Weight, oz 33
Lens covers
DIAGRAM
1. Laser aperture 6. Diopter adjustment
2. Objective lens 7. Display focus
3. Mode selection 8. Battery cap
4. Power button 9. Reticle
5. Eyepiece 10. Distance/Angle* display
8
5
7
4
3
11. Unit of measurement
12. Angle mode*
13. True Horizontal
Distance mode*
14. Height mode*
* SM22007 Solitude LRF-A only
1
5
6
2
9
13
12
Ang Horz Hig
m
YD
10
11
5
14
ºm
YD
3
