- Page 1 USER MANUAL USER MANUAL Ghost Hunter Binocular 1x24 Goggle Kit, 2x24 and 4x50 English / Francais / Español...
- Page 2 ABOUT SIGHTMARK ® Sightmark offers a wide range of products that include red dot scopes, reflex sights, rangefinders, riflescopes, laser sights, night vision and award-winning flashlights and boresights. Sightmark products are inspired by military and law enforcement applications. All products are designed to be the most effective weapon accessories possible. MAKE YOUR MARK www.sightmark.com...
-
Page 3: Technical Specifications
ENGLISH FEATURES: TECHNICAL SPECIFICATIONS: • High quality image and resolution SM15070 • Close observational range of focus Generation 1 / EP 33-U Battery life (with IR) 20hr • High power built-in infrared illuminator Magnification Batter life (w/out IR) • Ergonomic design Objective Lens diameter 24mm Tripod mount... - Page 4 SM15071 Generation 1 / EP 33-U Battery life (with IR) 20hr Magnification Batter life (w/out IR) 70hr Objective Lens diameter 24mm Tripod mount 1/4” Field of view 25º Operating temp. -20...40 ºC Field of view, m@100m Dimensions 136x113x60mm Min. focusing distance Weight 14.1oz (w/out batteries)
- Page 5 DIAGRAM: 1) Objective lens 2) On / off button 3) IR illuminator 4) IR button 5) Eyepiece 6) Battery compartment...
-
Page 6: Warnings And Precautions
(with IR illumination). The IR illuminator is recommended for use in low-ambient light conditions or total darkness. The Ghost Hunter binocular series consists of various models that suit various situations for close range to long range observation. The standard ¼” tripod socket allows the Ghost Hunters to be installed on a head mount or various accessories. -
Page 7: Battery Installation
• Keep the binocular away from dust and sudden temperature drop. • Do not subject the unit to water submersion, drops, or splashes. • Avoid dropping or otherwise shocking the unit. The binocular incorporates a sophisticated optical system which could be damaged in extreme cases of misuse. BATTERY INSTALLATION: Your binocular runs on two AAA batteries. - Page 8 USING THE HEAD MOUNT The Ghost Hunter 1x24 night vision binocular includes a compact head mount. This allows hands-free operation of the night vison device in partial and complete darkness. The head mount ensures stable positioning of the Ghost Hunter 1x24 in front of the user’s eyes, even while in fast motion (pacing, runing, and abrupt movements).
-
Page 9: Maintenance
MAINTENANCE: • Clean the lens with professional lens cleaning supplies intended for use with multicoated optics. • Blow any dust or dirt off the lenses using dry, compressed air. • Clean the monocular’s housing with a soft, clean cloth coated in some synthetic cleaning means. STORAGE: Always store the monocular in its case in a dry well-ventilated and well-heated room away from heating / air condi- tioning vents. - Page 10 • The scope flickers, flashes or “snows”… The scope may flicker or flash when used in a bright environment; to correct this, place the cap over the objective lens and enter a dark environment. The scope will restore itself to a natural functioning state in several minutes or hours, depending on how long the scope had been exposed to the light.
