Veris E30 series Installation Manual

TM
E30
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
• Follow safe electrical work practices. See NFPA 70E in the USA, or applicable local codes.
• This equipment must only be installed and serviced by qualified electrical personnel.
• Read, understand and follow the instructions before installing this product.
• Turn off all power supplying equipment before working on or inside the equipment.
• Use a properly rated voltage sensing device to confirm power is off.
DO NOT DEPEND ON THIS PRODUCT FOR VOLTAGE INDICATION
• Only install this product on insulated conductors.
Failure to follow these instructions will result in death or serious injury.
NOTICE
• This product is not intended for life or safety applications.
• Do not install this product in hazardous or classified locations.
• The installer is responsible for conformance to all applicable codes.
• Mount this product inside a suitable fire and electrical enclosure.
FCC PART 15 INFORMATION
NOTE: This equipment has been tested by the manufacturer and found
to comply with the limits for a class A digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in
a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
Modifications to this product without the express authorization of
Veris Industries nullify this statement.
Product IdentIfIcatIon
Description
CT Option
E30
A = Advanced 0 = 100A, 3/4" spacing
B = Intermediate 1 = 100A, 1" spacing
C = Basic
Z204998-0M PAGE 1
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Veris, and the Veris 'V' logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Power MoNITorING
# of CTs
42 = 2 strips*
84 = 4 strips*
*Each strip contains 21 current sensors.
©2012 Veris Industries USA 800.354.8556 or +1.503.598.4564 / support@veris.com
INSTALLATIoN GUIDe
E30
Panelboard Monitoring System
Installer's Specifications
Inputs:
Input Power
Accuracy:
Power/Energy
Voltage
Operation:
Sampling Frequency
Update Rate
Overload Capability
Outputs:
Type
Connection
Address
Baud Rate
Parity
Communication Format
Termination
Mechanical:
Ribbon Cable Support
Environmental:
Operating Temperature Range
Storage Temperature Range
Altitude of Operation
Agency Approvals
* See Configuration section for details.
table of contents
Quick Install
Operation
Dimensions
Product Diagram
Data Output
Blink Codes for Status LED
Solid-Core CT Accuracy
Installation
Wiring
Configuration
Default DIP Switch Settings
Address Setup
Commissioning
Recommended Accessories
Safety
Troubleshooting
China RoHS Compliance Information IEFUP Table)
90-277VAC, 50/60 Hz
IEC 62053-21 Class 1, ANSI C12.1-2008
±0.5% of reading 90-277V line-to-neutral
1.8 seconds (both panels)
DIP switch-selectable 2-wire or 4-wire, RS-485
DIP switch-selectable address 1 to 247 (in pairs of 2)*
DIP switch-selectable 9600, 19200, 38400
DIP switch-selectable NONE, ODD, EVEN
8-data-bits, 1-start-bit, 1-stop-bit
5-position depluggable connector
(TX+ TX- SHIELD TX+/RX+ TX-/RX-)
4 ft. (0.9 m) flat ribbon cable ships standard;
up to 20 ft. (6 m) available
0° to 60°C (32° to 140°F) (<95% RH noncondensing)
-40° to 70°C (-40° to 158°F)
UL508, EN61010
2560 Hz
22 kAIC
Modbus RTU
3000 m
2
2
2
3
3
3
3
4
7
8
8
9
10
10
10
11
11
07121
