F-CONTROL AUDIO FCA202

The POWER LED indicates that the equipment is ready to operate. It lights up as soon as the

FCA202 is provided with power from the mains adapter or via the FireWire

socket.

The FW LED lights up as soon as the FCA202 is correctly connected by a FireWire

cable to

a computer that is in operation. If the LED does not light up, check the FireWire

connection to

the computer. You can find more information on hardware and driver installation in Chapter 2.

3.2 Rear panel

Fig. 3.2 back of the FCA202

Use the DC IN socket to connect the mains adapter provided. For further information, please

carefully read through Chapter 2.4.

The LOCK port in combination with a suitable security lock from Kensington

offers you a

very good way to protect your equipment against theft. For further information, visit

www.kensington.com.

3. OPERATING ELEMENTS AND CONNECTIONS
