Summary of Contents for WATSON INDUSTRIES SMS-P233
- Page 1 STABILIZED MOUNT SYSTEM OWNER'S MANUAL PART NUMBER: SMS-P233 WATSON INDUSTRIES, INC. 3035 MELBY STREET EAU CLAIRE, WI 54703 Phone: (715) 839-0628 FAX: (715) 839-8248 email: support@watson-gyro.com Watson Industries, Inc. SMS-P233 Rev B 10/17/2017...
-
Page 2: Table Of Contents
Set Baud Rate................................22 Watson Industries prides itself on solving customer problems and serving their needs in a timely fashion. This manual is intended to facilitate this goal and to provide written information about your product. We ask that you carefully read this manual. -
Page 3: Introduction
The whole system is user configurable to adapt to a wide range of payloads and requirements. Watson Industries also provides custom systems for special requirements. Our system design is modular and configurable for economical and quick adaptation to a wide variety of hardware configurations. - Page 4 In other words, the servo- control system ensures that the motion of the platform exactly matches that of the preset value in inertial space. Watson Industries, Inc. SMS-P233 Rev B 10/17/2017...
-
Page 5: Start-Up
When increasing errors are detected, the time constant is made longer so that the gyros are in more control of the attitude. This is done on the assumption that short-term errors are more likely to be caused by vehicle dynamics. Watson Industries, Inc. SMS-P233 Rev B 10/17/2017... -
Page 6: Pointing Angle
This is a last line of defense from a system failure, as it is fully independent from the other safety systems. Driving the mount away from this limit is not inhibited. Watson Industries, Inc. SMS-P233 Rev B 10/17/2017... -
Page 7: Reverse Power Connection
2. Adjust the position of the mounting ring of the servo system so that the paint mark on the mounting ring will line up with the center position of the intended field of view. Paint Mark Watson Industries, Inc. SMS-P233 Rev B 10/17/2017... - Page 8 5. Using a level, adjust the position of the servo system so that it is reasonably level. 6. Once the servo system is completely level, secure the four M6mounting bolts. Watson Industries, Inc. SMS-P233 Rev B 10/17/2017...
-
Page 9: Sensor Package
As in all moving mechanisms there is concern about ice interfering with operation. The system has internal protection against damage from stalling the motors, but performance may be reduced. The system should be considered fragile. DO NOT APPLY LOADS OR FORCES TO THE PAYLOAD. Watson Industries, Inc. SMS-P233 Rev B 10/17/2017... -
Page 10: Connections
This product has one connector for all system connections. The user mating connector is Amphenol part number MS3106A-20-7S (included with the system). The connections are: Function Power Return +28 Volt Power No Connection RS-232 Transmit from SMS-P233 Signal Ground (connected internally to Power Return) RS-232 Receive to SMS-P233 No Connection Case Ground Power: This unit has an internal regulator to allow operation over a moderate voltage input range. -
Page 11: Specifications
Payload Mounting Holes: Qty 8 #12 (M6) clearance 4" dia. bolt circle • Specifications are subject to change without notice. • This product may be subject to export restrictions. Export Classification ECCN EAR99. Watson Industries, Inc. SMS-P233 Rev B 10/17/2017... -
Page 12: Rs-232 Output Format
This may be reduced to more basic information to improve the update rate to compensate for lower baud rate by using special commands to modify the EEPROM of the unit. Watson Industries, Inc. SMS-P233 Rev B 10/17/2017... -
Page 13: Rs-232 Input Commands
“*” command from the interfacing computer. Such a change in setting can be made the default setting. Data transmission sent by the SMS-P233 can also be suppressed or restored by a “+” command from the interfacing computer. This change can be made the default setting. - Page 14 “Q”, and sometimes Escape or a Delete will interrupt the command and return to operation with the least disturbance to the system. All other unspecified characters such as carriage return, line feed and space are ignored by the system. Watson Industries, Inc. SMS-P233 Rev B 10/17/2017...
-
Page 15: Warning
All sensors returned under warranty will be repaired (or replaced at the sole option of Watson Industries) at no cost to the customer other than shipping charge from customer to Watson Industries (plus any export and transportation charges outside the United States). - Page 16 Customer Service All repairs, calibrations and upgrades are performed at the factory. Before returning any product, please contact Watson Industries to obtain a Returned Material Authorization number (RMA). Return Address & Contact Information Watson Industries, Inc. 3035 Melby Street Eau Claire, WI 54703...
-
Page 17: Appendix A
Bank Error Initialization Digit Limit Exceeded Limit Exceeded 4 + 2 + 1 4 + 2 4 + 1 “4” Elev. Limit Exceeded “2” Bank Limit Exceeded 2 + 1 “1” In Initialization Watson Industries, Inc. SMS-P233 Rev B 10/17/2017... - Page 18 2) Elevation angle negative stop limit equals a value of 1 when the Elevation potentiometer reaches a preset limit. Second Elevation Angle Elevation Angle Digit Positive Stop Limit Negative Stop Limit “2” Elevation Positive Stop Limit “1” Elevation Negative Stop Limit Watson Industries, Inc. SMS-P233 Rev B 10/17/2017...
- Page 19 2) Y Rate limit equals a value of 1 when the Y axis angular rate exceeds 25 degrees per second. Third X Axis Rate Y Axis Rate Digit Limit Exceeded Limit Exceeded 2 + 1 “2” X Rate Limit Exceeded “1” Y Rate Limit Exceed Watson Industries, Inc. SMS-P233 Rev B 10/17/2017...
-
Page 20: Activating Command Mode (Double Spacebar Mode)
1 = ADJUST TIME CONSTANTS 2 = SET OUTPUT CHANNELS 3 = LIST CURRENT OUTPUT CHANNEL SELECTION 4 = SET NEW BAUD RATE 3) Typing in '3' will show which channels are currently active. Watson Industries, Inc. SMS-P233 Rev B 10/17/2017... -
Page 21: Setting Output Channels
Extended Time Constant is used to reduce the effects on the system. Consult the factory for recommendation before adjusting these values. 4) Press the spacebar after changing the time constant to resume data transmission. Watson Industries, Inc. SMS-P233 Rev B 10/17/2017... -
Page 22: Set Baud Rate
Note: The baud rate of the software that is communicating to the sensor will need to be changed to match the new setting. 5) Press the space bar to resume data transmission. The factory settings for serial communications are 9.6K baud with 8 bits and one stop bit, no parity. Watson Industries, Inc. SMS-P233 Rev B 10/17/2017...
