- Page 1 Viega Smartpress Instructions for Use Year built: from 04/2016 en_INT...
- Page 2 Viega Smartpress 2 from 23...
-
Page 3: Table Of Contents
Handling Storage Assembly information 3.2.1 Mounting instructions 3.2.2 Space requirements and intervals 3.2.3 Required tools Assembly 3.3.1 Bending pipes 3.3.2 Shortening the pipes 3.3.3 Stripping pipes 3.3.4 Pressing the connection 3.3.5 Leakage test Maintenance Disposal Viega Smartpress 3 from 23... -
Page 4: About These Instructions For Use
This restriction does not extend to possible operating instructions. The installation of Viega products must take place in accordance with the general rules of engineering and the Viega instructions for use. -
Page 5: About This Translated Version
German/European directives specified in this manual: The information herein is not binding for other countries and regions; as said above, they should be understood as a recommendation. Viega Smartpress 5 from 23... -
Page 6: Product Information
Regulations for external corrosion DIN EN 806, Part 2 protection Regulations for external corrosion DIN 1988-200 protection Regulations from section: Storage Scope / Notice Regulations applicable in Ger‐ many Requirements for material storage DIN EN 806-4, Chapter 4.2 Viega Smartpress 6 from 23... -
Page 7: Intended Use
DIN EN 806-5 drinking water installations Intended use Coordinate the use of the system for areas of use and media other than those described with the Viega Service Center. 2.2.1 Areas of use Use is possible in the following areas among others:... -
Page 8: Media
Use of the system outside or in special surroundings must be agreed with the Viega Service Center. 2.2.2 Media The system is suitable for the following media, amongst others: Viega Smartpress multilayer pipe (dimensionally stable with external oxygen seal coat) – Drinking water –... -
Page 9: Pipes
Pipes The following pipes are available from the system described: Viega Smartpress multilayer pipes, with or without protective pipe, with various thicknesses of insulation are available in coiled bundles. Dimen‐ sionally stable multilayer pipes are also available in 5 m lengths. The fol‐... - Page 10 Product information Viega Smartpress PERT/Al/PERT Type of pipe Areas of use Pipe without pro‐ 16, 20 Drinking water and heating tective pipe installations Pipe with protective 16, 20 Drinking water and heating pipe (black) installations Pipe with 6 mm 16, 20 Drinking water and heating surrounding insula‐...
- Page 11 – Connect the intersection horizontally with the right-hand dia‐ gram up to the intersection of the characteristic line for pipe diameter 20 mm. Result: Read the value from the x-axis: L = 480 mm. Viega Smartpress 11 from 23...
-
Page 12: Press Connectors
Press connectors are available in a number of shapes. An overview of the press connectors suitable for the system can be found in the cata‐ logue. The press connectors of the Viega Smartpress system consist of the fol‐ lowing materials: Gunmetal/silicon bronze... -
Page 13: Markings On Components
SC-Contur Fig. 4: SC-Contur Viega press connectors are equipped with the SC-Contur. The SC- Contur is a safety technology that is certified by the DVGW and ensures that the connector is guaranteed to be leaky in an unpressed state. In this way, inadvertently unpressed connections are noticed immediately when filling the system. -
Page 14: Mixed Installations
Permitted mixed installations To ensure proper function, the Viega Smartpress connectors may only be used with the Viega pipes from the systems Viega Smartpress, Pexfit Pro, and Pexfit Fosta. Since the use with pipes of other systems or by other manufacturers has not been tested, proper function cannot be ensured in this case. -
Page 15: Information For Use
Stainless steel components must not come into contact with building materials or mortar containing chloride. If external corrosion protection is required, observe the general rules of engineering, see Ä „Regulations from section: Chemical resistance“ on page 6. Viega Smartpress 15 from 23... -
Page 16: Handling
– As a sealant, only use commercially available hemp together with thread sealing paste or certified sealing tape for potable water. – Please contact the Viega Service Center if you have any questions. Checking system components System components may, in some cases, become damaged through transportation and storage. -
Page 17: Space Requirements And Intervals
Space requirement Picco, Pressgun Picco a [mm] b [mm] c [mm] Pressing in wall slots Space requirement type 2 (PT2), PT3-EH, PT3-AH, Pressgun 4B, 4E, 5 a [mm] 20 b [mm] 90 c [mm] 140 Viega Smartpress 17 from 23... -
Page 18: Required Tools
For the Z dimensions, refer to the respective product page in the online catalogue. 3.2.3 Required tools The use of original Viega tools or equivalent tools is recommended for installation. The following tools are required for production of a press connection: Hand or electric saws or angle grinders are not permitted. -
Page 19: Assembly
Handling Fig. 6: Pressgun 5 with Viega Smartpress jaw Recommended Viega press machines: Pressgun 5 Pressgun Picco Pressgun 4E / 4B Picco Type PT3-AH Type PT3-H / EH Type 2 (PT2) Assembly 3.3.1 Bending pipes NOTICE! Product damage due to use of metal internal bending... -
Page 20: Shortening The Pipes
– To avoid damage, choose a bending point with sufficient distance to the connector. Viega Smartpress multilayer pipes in the dimensions 16–32 mm can be bent by hand with a bending radius of 5 x d or with a bending tool with... -
Page 21: Stripping Pipes
2758.5. The use of other chamfer tools is not permitted. Remove coating from the pipe end using a chamfer. Replace the worn blades with model 2758.1. 3.3.4 Pressing the connection Viega Smartpress 21 from 23... - Page 22 Open the hand press tool and place it at a right-angle onto the con‐ nector. Observe the intervals in section Ä Chapter 3.2.2 „Space require‐ ments and intervals“ on page 17. Carry out the pressing process. ð Connection is pressed. Viega Smartpress 22 from 23...
-
Page 23: Leakage Test
Ä „Regulations from section: Mainte‐ nance“ on page 7. Disposal Separate the product and packaging materials (e. g. paper, metal, plastic or non-ferrous metals) and dispose of in accordance with valid national legal requirements. Viega Smartpress 23 from 23...
