Summary of Contents for Viega 2489.1
- Page 1 Pressgun Picco press machine set Instructions for Use Model Year built: 2489.1 from 01/2015 en_INT...
- Page 2 Pressgun Picco press machine set 2 from 22...
-
Page 3: Table Of Contents
Table of contents Table of contents About these instructions for use Target groups Labelling of notes About this translated version Note on use of abbreviated terms Product information Standards and regulations Safety advice Intended use 2.3.1 Areas of use 2.3.2 Maintenance Product description 2.4.1... -
Page 4: About These Instructions For Use
This restriction does not extend to possible operating instructions. The use of Viega products must be carried out in accordance with the general rules of engineering and the Viega instructions for use. -
Page 5: About This Translated Version
Note on use of abbreviated terms For reading comfort, the following abbreviated terms are used in these instructions for use: Viega system press machine Press machine Pressgun Picco Viega system press jaws... -
Page 6: Product Information
2 Product information Standards and regulations The following standards and regulations apply to Germany / Europe. National regulations can be found on the relevant web site of your viega.com/standards . country at Regulations from section: Technical data Scope / Notice... - Page 7 Product information b) Do not touch earthed surfaces, for example of pipes, heaters, cookers, and fridges. Increased risk of electric shock if your body is earthed. c) Keep electrical tools out of the rain and protect them from moisture. Increased risk of electric shock if water gets into an electrical tool. d) It is forbidden to use the cable to carry the electrical tool or hang it up, or to remove the plug from the socket by pulling at the cable.
- Page 8 Product information 4) Using and handling electrical tools a) Do not overload the tool. Use the electrical tool intended for the task you are doing. For better results and more safety, use the appropriate electrical tool in the specified power range. b) Do not use an electrical tool with a defective switch.
-
Page 9: Intended Use
The Viega system press machine Pressgun Picco is intended for pressing press connectors into the respective piping systems. In combi- nation with Viega press jaws, the press tool is suitable for use with all Viega sanitary and heating installation systems up and including dimen- sion 35. -
Page 10: Technical Data
8 - button for manual release Scope of delivery Refer to the model number to see the scope of delivery of your press machine in the table below: Model number 2489.1 5389.1 2489.2 Pressgun Picco Press jaw set (dimensions 15 / 22 / 28) Press jaw set Raxofix (dimensions 16 / 20 / 25) Lithium ion battery (18 V / 2.0 Ah) - Page 11 Lithium ions Capacity 18 V / 2.0 Ah 18 V / 4.0 Ah Charger Original charger (Viega) Charging time 45 min. (18 V / 2.0 Ah) 60 min. (18 V / 4.0 Ah) Pressgun Picco press machine set 11 from 22...
-
Page 12: Operating Mode
Product information Charger – depending on scope of delivery Input 120 V AC or 230 V AC Tolerance range ±10 V Frequency 50–60 Hz Input current max. 1.0 A Output 18 V DC Battery technology Lithium ions Weight 0.73 kg Dimensions (L x W x H) 153 x 142 x 94 mm 2.4.3... - Page 13 Product information The following are monitored: retaining bolt Pressing time Voltage / battery capacity Service interval Operating temperatures Significance of the LEDs Status Description green flashing Low battery charge level – Recharge bat- tery. lit up Machine is ready for operation. flashing Machine is blocked –...
-
Page 14: Handling
Handling 3 Handling Transport and storage NOTICE! Transporting and storing the battery Observe the manufacturer's instructions for transport and storage. DANGER! Risk of crushing! Risk of getting your fingers and hands crushed. – Store the press machine out of the reach of children and unauthorized persons. -
Page 15: Commissioning
Handling Commissioning DANGER! Danger due to electrical current An electric shock can lead to burns and serious injury and even death. – Before using the power pack, check that the mains cable is intact. – Pull the mains plug before removing the power pack from the press machine. -
Page 16: Carrying Out The Pressing Process
Handling Insert the press jaw in the press jaw fixture of the cylinder head. INFO! The Figures show an example for the use of a press jaw. Hinged adapter jaws can be used in the same way. Slide the retaining bolt in as far as it will go. Press the On / Off button. - Page 17 Handling NOTICE! Damage to objects due to damages press jaws Using a defectively, incorrectly dimensioned, or worn press jaw may result in incorrect pressing. – Before using the press jaw, check it for visible defects. – Only use faultless press jaws of a suitable size. The press jaw must be able to lock properly during pressing.
-
Page 18: Troubleshooting
Handling Aborting the pressing process When the roller head has not touched the press jaw yet and no pressing force has been built up, simply let go of the Start button to abort pressing. Next, actuate the button for manual unlocking and move the roller head back to the starting position. -
Page 19: Performing Checks
The functional safety and permanent leak tightness of the press con- nector systems primarily depends on the functional and operational safety of the Viega system press tools, i.e. the Viega press machine plus Viega system press jaw, ring, chain, and (articulated) adapter jaw. These Viega system press tools have been specifically designed for and adapted to the installation of the Viega press connector systems. -
Page 20: Service Partners
Press jaws and press rings The Viega system press jaws and system press rings have a label showing the date when the next maintenance is due (e.g. 1st quarter 2019). Have your machine serviced when due to ensure safety and availability. - Page 21 Handling Country Company Address / contact information code Allied Power Tools Pty. 12/76 Rushdale St, Knoxfield, VIC 3180 Ltd. +61 (3) 9764 2911/ alliedservice@aanet.com.au OMICRON-Benelux bvba Grote Steenweg 116, 3454 Rummen +32 (11) 58 43 50 / rudy.massa@omicron-weldingtechnology.com Mátl & Bula, spol. s r.o. Stará...
-
Page 22: Disposal
Handling Country Company Address / contact information code KONTURS-SDM Moscow Region, Solnechnogorsk district, Leningradskoye shosse, 35 km., str.15 (Polygon MADI) +7 (499) 702-45-88 / remont@konturs-sdm.ru AB Lindströms Elverkstad Propellervägen 7, 39241 Kalmar +46 (48) 018877 / Fredrik.Greiff@lindstroms-elverkstad.se MEP LLA Glasgow - Unit K, Ashley Drive Bothwell, G71 8BS Glasgow Depot 190 +44 (1698) 740047 / angela.hepburn@vpplc.com...
