Controls
Features and appearance will vary.
Lights next to the touch pads on the air conditioner control panel indicate the selected settings.
7
FULL
POWER
1
Controls
1. Power Control
The power control turns the unit on and off.
2. Timer
Auto Turn Off:
With machine in running mode, press timer button to
select number of hours you would like the unit to run
in air conditioning mode until it automatically shuts off.
Auto Turn On:
With machine in stand by mode, press timer button to
select number of hours until you would like the unit to
automatically start running in air conditioning mode.
3. Mode Control
Press this button to change the operation mode.
COOL: LED lights when in cooling mode.
DEHUM:
FAN: Green LED lights when in fan mode.
HEAT: Red LED lights when in heat mode (applies
only to heat and cool models).
4. Fan Speed Control
The Fan Speed Control has 3 settings: High, Low,
and Sleep.
4
COOL
TIMER
MODE
DRY
FAN/HEAT
2
3
Air Conditioner Controls
6
HIGH
FAN
LOW
SLEEP
4
5. Timer/Temp Set Controls
• Used for adjusting the timer and thermostat.
• The default display is room temperature.
• In cooling mode when + or - button is pressed, the
set temperature is displayed and may be adjusted.
After 10 seconds the display will revert back to room
temperature. Temperature is only adjustable in cool
mode. The time is adjustable between 1-24 hours.
NOTE: By pressing both + and - buttons at the
same time, the display will toggle between Celsius
and Fahrenheit. The temperature cannot be
adjusted in the fan or dehumidification modes.
6. Display
7. Warning Light
Condensed water may accumulate in the unit. If the
internal tank becomes full, the warning light will light
up and the unit will not operate until the unit has been
drained.
_
+
5
49-7836
