2
InView Marquee Message Display
Publication 2706-QS001D-EN-P - January 2009
Equipment Setup
Connect a power cord or power supply and catalog number
2706-PCABLE1, series A, to the InView display and to COM1 of the
computer.
Verify RSLinx software is not using the serial port.
TIP
Configure the Display
Follow these steps to configure the display.
1. Install the InView Messaging software.
Refer to the installation instructions included on the CD.
2. Launch the InView Software from Start > Programs > Rockwell
Automation > InView Software > InView Messaging Software.
3. After opening the software, click Create New InView Project and
click OK.
