ClearClick HD Video Capture Box Ultimate User's Manual And Quick Manual
Hide thumbs
Also See for HD Video Capture Box Ultimate:
- Users manual & quick start manual (21 pages) ,
- Users manual & quick start manual (14 pages) ,
- Users manual & quick start manual (14 pages)
Related Manuals for ClearClick HD Video Capture Box Ultimate
Summary of Contents for ClearClick HD Video Capture Box Ultimate
- Page 1 User’s Manual & Quick Start Guide Full 1-Year Warranty & USA-Based Tech Support Email Us At: support@clearclick.tech www.ClearClick.tech...
-
Page 2: Safety Precautions
Register Your Product Make sure you register your product at: www.ClearClick.tech Browse All Our Products! If you’re looking for fun, unique, and easy-to-use technology, we’ve got it! Please visit our website to browse all of our products: www.ClearClick.tech Safety Precautions 1. - Page 3 What’s In The Box? Device Diagram & Explanation (continued on next page)
- Page 4 IR Receiver: Receives the signal from the remote control LED indicators: A blue light means the device is on. A blue blinking light means it is running low on memory. A red blinking light means it is running low on battery & it needs charging immediately. A red light means that the device is off and charging.
- Page 5 Remote Control Diagram & Explanation...
- Page 6 Quick Start Guide – Normal Recording Mode 1. Connect the power adapter to the DC input jack (see #5 from device diagram) of the HD Video Capture Box. Plug in the power adapter to any power outlet. 2. Turn on the HD Video Capture Box by holding down the power button for several seconds.
- Page 7 How To Schedule Recordings You can schedule a recording by pressing “Schedule” on the remote, or by selecting “Schedule Recording” in the menu of the HD Video Capture Box. NOTE: Make sure your device is set to the right time and date before scheduling.
- Page 8 Quick Start Guide – Live Streaming with XSplit 1. Connect a micro USB cable (not included) to the “USB TO PC” port on the HD Video Capture Box. Plug the other end into your PC. (Macintosh not supported.) 2. The menu below will appear on the HD Video Capture Box. Select “PC Streaming Mode”...
- Page 9 Quick Start Guide – Live Streaming with OBS 1. Connect a micro USB cable (not included) to the “USB TO PC” port on the HD Video Capture Box. Plug the other end into your PC. (Macintosh not supported.) 2. The menu below will appear on the HD Video Capture Box. Select “PC Streaming Mode”...
- Page 10 Device Specifications Supported Video Resolutions 1920x1080 (60p) 1920x1080 (50p) 1920x1080 (30p) 1920x1080 (25p) 1920x1080 (24p) Input 1920x1080 (60i) 1920x1080 (50i) 1280x720 (60p) 1280x720 (50p) 720x480 (60i/p) 720x576 (50i/p) HDMI Output 1280x720 (60p) for playback / Loop-through up to 1920x1080 Local Recording: 1920x1080 (60p).
-
Page 11: Troubleshooting
Troubleshooting 1. My video doesn’t show up on the LCD. Please make sure the HDMI or AV source input is connected properly. Make sure the “Video Source” setting in the device menu is set correctly. Make sure your HDMI cable is plugged into the “IN” port, not the “OUT” port. - Page 12 PC or Mac with a better CPU and graphics card. 12. I have a question that isn’t listed here, or need further support. No problem! Please email us at support@clearclick.tech with your order number, and we will get back to you as soon as possible.
Need help?
Do you have a question about the HD Video Capture Box Ultimate and is the answer not in the manual?
Questions and answers
I just tried to convert a UHS tape to the flash drive. It all appeared to be working fine. When I put the flash drive into the computer there is no movie
The ClearClick HD Video Capture Box Ultimate may not have saved the movie file on the flash drive due to several possible reasons:
1. Incorrect Input Connection – Ensure the UHS tape player is properly connected to the capture device using the correct input (e.g., RCA, HDMI, or S-Video).
2. Unsupported Flash Drive Format – The flash drive must be formatted in a compatible file system (e.g., FAT32 or exFAT).
3. Insufficient Storage – Check if the flash drive has enough free space to store the recorded video.
4. Recording Not Started Properly – Ensure the capture process was started and stopped correctly according to the device instructions.
5. File Corruption or Error – The recording process may have been interrupted, leading to a missing or corrupted file.
6. Device Malfunction – If the problem persists, try using a different flash drive or contact ClearClick support for troubleshooting.
This answer is automatically generated
