INSTALLATION INSTRUCTIONS
Two USB connector cables are located at the rear of the Apache radio
body. During installation, you must route the cables to a convenient and
accessible location for plugging in USB devices. If the cables provided are
not long enough, you may use our optional USB/AUX Extension Cable (not
included) to extend the reach of the cable. This cable also allows you to
install the USB/AUX port into the factory location for the cigarette lighter for
a factory look and easy access.
Plug in the Bluetooth microphone and route it to an accessable area such
®
as the steering column or A-pillar.
SiriusXM Input
The SiriusXM input is located at the rear of the radio body. Instructions for
wiring and installing your SiriusXM Connect vehicle tuner are included
with your SiriusXM Connect vehicle tuner box.
DAB/DAB+ Input
The DAB+ input is the brass connection located at the rear of the
radiobody. A special antenna is required to listen to DAB and DAB+ digital
audio broadcasts (see page 11).
STEP 5: Finish the Installation
IF USING A BEZEL, Place the bezel on the face of the radio, then install the
assembled radio from behind the dash until the bezel and radio face are
flush with the front of the dash and the radio shafts protrude through the
shaft openings in the dash. Using the supplied washers and shaft nuts (see
"What's In the Box" on page 4), secure the radio to the dash.
IF USING A FACEPLATE, slide the radio into the hole from behind the dash,
then align the faceplate over the radio shafts from the front. Using the
supplied washers and shaft nuts (see "What's In the Box"
on page 4), secure the faceplate to the dash and the radio.
DAMAGE RESULTING FROM OVERTIGHTENING THE SHAFT NUTS
WILL VOID YOUR WARRANTY.
Next, you'll need to secure the rear of the radio using the supplied
