Plymovent Junior LM-2 Product Manual

Fume extractor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Table of contents:

Technical description ........................................ 2
Delivery .......................................................... 2
Advantages ..................................................... 2
Technical data ................................................. 2
Construction and function ................................. 2
Handling ......................................................... 2
Hood operation ................................................ 2
Mounting example ............................................ 3
Working area ................................................... 3
Pressure loss ................................................... 3
Alternative system layouts ................................. 4
Mounting instruction ..................................... 6 - 9
Maintenance instruction ............................ 10 - 11
Spare part drawing ..................................... 12-13
Thank you for buying a PlymoVent product.
Before you unpack and put it into operation please read
this product manual, and follow the instructions.
THIS MANUAL SHOULD BE HANDED OVER
AND KEPT BY THE SERVICE DEPARTMENT
PlymoVent Canada Inc.
6615 Ordan Drive, Unit # 3
Mississauga, Ontario L5T 1X2, Canada
Tel: +1 (905) 564 4748
Fax: +1 (905) 564 4609
USA/CAN
Product manual
Junior LM-2
AFTER THE INSTALLATION!
Page:
PlymoVent Corp.
375 Raritan Center Parkway,
Edison New Jersey 08837, USA
Tel: +1 (732) 417 0808
Fax: +1 (732) 417 1818

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Junior LM-2 and is the answer not in the manual?

Questions and answers

Related Manuals for Plymovent Junior LM-2

Summary of Contents for Plymovent Junior LM-2

  • Page 1: Table Of Contents

    Mounting instruction ........6 - 9 Maintenance instruction ......10 - 11 Spare part drawing ........12-13 Thank you for buying a PlymoVent product. Before you unpack and put it into operation please read this product manual, and follow the instructions.

  • Page 2: Junior

    The arm can be turned through 300° due to PlymoVent's renow-ned ball-bearing joint. This is fitted together with an adjustable friction brake in the wall mounting bracket. All movement of the arm is controlled from the hood.

  • Page 3: Mounting Example

    Floor mounted LM-2 with stanchion PA-220 and separate fan. Pressure Loss The following aspects The pressure loss diagram below shows affect the pressure loss in PlymoVent's LM-2. the average pressure loss through the LM-2. 1. The air volume. Welding: 800-1200 m /hr.

  • Page 4: Alternative System Layouts

    Alternative System Layouts Alt. 1 Central system: 3 X LM-2 with one central FS-4700 fan. Recommended fan per no of arms: FS-3000: 2-3 arms. FS-4700: 3-4 arms. FA-6000: 4-5 arms. Alt. 2 Central fan Central system: 3 X LM-2 fitted with ASE-12 automatic dampers, M-1000 control unit and one central fan.

  • Page 5: Complementary Products And Accessories

    2950 CFM. For more information, see technical data Extendable up to 3 m. To be used when installing for oilmist and Electrostatic Filters (EF/EFO). switch assembly for PlymoVent LM-2 and Extractor Cranes ”Plymoth ® ”. Prod. no: SK-300...

  • Page 6: Mounting Instruction

    BSAB no: T0.31 Ser.no: LM/MA MOUNTING INSTRUCTION Date: Sept-97 Replace: Jan-95 JUNIOR LM-2 Pos no DESCRIPTION Wall mounting bracket Counterweight LM-2 Hood collar Hood Spigot LM/USA/CAN/6/13...
  • Page 7 Mounting instructions 1. Bolt mounting bracket to wall. 2. Attach arm to mounting bracket. 3. Mount counter-weight (1) and tube over counter-weight (2). 6 mm 17 mm 4. Adjust to the desired friction. 10 mm LM/USA/CAN/7/13...
  • Page 8 5. Pull over the rubber seal. 6. Fix flexible hose in place, using jubilee clips as supplied. LM/USA/CAN/8/13...
  • Page 9 For central system. For individual fan. 7. Mount spigot Ø 160 mm, 6,3". LM/USA/CAN/9/13...

  • Page 10: Maintenance Instruction

    BSAB no: T0.31 MAINTENANCE Ser.no: LM/DS Date: Sept-97 INSTRUCTION Replace: Jan-95 JUNIOR LM-2 If the arm will not stay in the required position: 1. Loosen the hose at A. 2. Pull the extractor out to its full length and angle it horizontally. Loosen the friction brake until the arm drops towards the floor.
  • Page 11 To change wire 1. Unbolt the counterweight tube. 2. Loosen both jubilee clips and push the hose together in the middle of the telescopic tube. 3. Detach the counterweight. 4. Unscrew the bolt holding the hood attachment to the telescopic tube, and remove the hood attachment carefully.

  • Page 12: Spare Part Drawing

    BSAB no: T0.31 Ser.no: LM/RR SPARE PART DRAWING Date: Sept-97 Replace: Jan-95 JUNIOR LM-2 LM/USA/CAN/12/13...
  • Page 13 © Copyright: All right reserved. All information within this printed matter may not be reproduced, handed over, copied, xeroxed or translated into another language, in any form or any means witho written permission from PlymoVent AB. PlymoVent AB reserves the right to make design changes Produkt No:...
