  • Page 1 J4060-01 12G SAS JBOD SERIES User's Manual UM_J4060-01_v6_061218...

  • Page 2: Table Of Contents

    CONTENTS PREFACE �������������������������������������������������������������������������������������������������������� i SAFETY INSTRUCTIONS ��������������������������������������������������������������������������������� ii CHAPTER OVERVIEW ���������������������������������������������������������������������������������� iv Chapter 1� Product Features ��������������������������������������������������������������������1 1�1 Box Content ������������������������������������������������������������������������������������������������������ 1 1.2 Specifications ��������������������������������������������������������������������������������������������������� 2 1�3 Feature �������������������������������������������������������������������������������������������������������������� 3 1.4 8644 with Zoning Configuration and 8644 Port Definition ����������������������������� 7 Chapter 2�...
  • Page 3 Chapter 4. BMC Configuration Settings ������������������������������������������������64 4.1 Login ��������������������������������������������������������������������������������������������������������������� 64 4.2 Sensor’s Location for Fan & Temperature ����������������������������������������������������� 65 4�3 Utility Setup on Host ���������������������������������������������������������������������������������������� 66 4�4 Connect Host to BMC by RS232 �������������������������������������������������������������������� 66 4.5 BMC LED Signal ����������������������������������������������������������������������������������������������� 69 4�6 Web UI �������������������������������������������������������������������������������������������������������������...
  • Page 4 Copyright © 2016 AIC, Inc� All Rights Reserved� This document contains proprietary information about AIC products and is not to be disclosed or used except in accordance with applicable agreements.

  • Page 5: Preface

    • Disclaimer AIC shall not be liable for technical or editorial errors or omissions contained herein. The information provided is provided "as is" without warranty of any kind. To the extent permitted by law, neither AIC or its affiliates, subcontractors or suppliers will be liable for incidental, special or consequential damages including downtime cost;...

  • Page 6: Safety Instructions

    SAFETY INSTRUCTIONS Before getting started, please read the following important cautions: • All cautions and warnings on the equipment or in the manuals should be noted. • Most electronic components are sensitive to electrical static discharge. Therefore, be sure to ground yourself at all times when installing the internal components. •...
  • Page 7 • If the equipment is not used for a long time, disconnect the equipment from mains to avoid being damaged by transient over-voltage. • Never open the equipment. For safety reasons, only qualified service personnel should open the equipment. • If one of the following situations arise, the equipment should be checked by service personnel: 1.

  • Page 8: Chapter Overview

    Chapter 1 Product Features Chapter 1 Product Features J4060-01 is an ideal SAS JBOD that is specifically designed to accommodate diverse corporations and enterprises who pursue flexibility, easy control, and density in external or backup storage. This product supports hot swap designs and is easily deployed for your benefit.

  • Page 9: Chapter 1� Product Features

    • Enclosure (Power supply, fan, 60 HDD tray included) • RS232 cable x 1pcs • Power cord x 2pcs • Screws kit x 1set • Mounting Optional Slide Rail x 1set If any items are missing, please contact your authorized reseller or sales representative. J4060-01 User's Manual...

  • Page 10: Specifications

    (W x D x H) inches : 23.7 x 44.1 x 20 • Long tool-less slide rail for 1.2m Rack (with CMA support) • Cable management kit Mounting Options • Short tool-less slide rail for 1m Rack (without CMA support) J4060-01 User's Manual...

  • Page 11: 1�3 Feature

    Chapter 1 Product Features 1�3 Feature J4060-01 is a reliable SAS JBOD with 3.5” x 60 hotswap drives bays. This product is designed to accommodate 2 external expanders and 6 internal expander with 6 Mini SAS HD per expander module. Featuring the expander chip, Broadcom SAS3x36R and...
  • Page 12 Chapter 1 Product Features Front Panel Fault LED (red) Interpretation The drives has failed, or a predictive failure alert has been received for the drives. J4060-01 User's Manual...
  • Page 13 Chapter 1 Product Features Rear Expander Panel Console port SFF 8644 wide port Debug port Identify LED BMC LAN port BMC console port J4060-01 User's Manual...
  • Page 14 Chapter 1 Product Features Rear Panel 1400W 1+1 hot-swap redundant power suppl y SECONDARY PRIMARY 4 x 8cm fans Mini SAS HD J4060-01 User's Manual...

  • Page 15: 8644 With Zoning Configuration And 8644 Port Definition

    8644 ports will have a variety of zone group settings. Before you begin, your JBOD must be equipped with HUB/EDGE setting. Refer to 3.2 Connect Host to JBOD via RS232 Refer to 3.5.2 How to configure T10 zoning SMART PORT (CONSOLE PORT) SMART PORT(CONSOLE PORT) J4060-01 User's Manual...
  • Page 16 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 J4060-01 User's Manual...
  • Page 17 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 GROUP1 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 J4060-01 User's Manual...
  • Page 18 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 J4060-01 User's Manual...

  • Page 19: Chapter 2� Hardware Setup

    Chapter 2 Hardware Setup Chapter 2� Hardware Setup This chapter provides detailed instructions on hardware installation. 2�1 Removing and Installing Top Cover Push the release button on both sides and slide forward the top cover to open cover. J4060-01 User's Manual...

  • Page 20: 2�2 Removing And Installing The Hard Disk Drive

    Grasp and open the ejector lever and then pull the drive tray out of the slot. 2.2.2 Installing the hard disk drive tray Insert the drive carrier into its bay. Push the tray lever until it clicks. Make sure the drive tray is correctly secured in place. J4060-01 User's Manual...
  • Page 21 Directly place HDD into tool-less HDD tray until it snaps. Please check if the screw holes on HDD match the dimples on HDD tray. HDD can also be screwed on HDD tray by fastening two screws as picture showed. J4060-01 User's Manual...
  • Page 22 Chapter 2 Hardware Setup 2.2.4 Drive Slot Map The drive slot map follows. Left Edge Center Edge Right Edge J4060-01 User's Manual...

  • Page 23: 2�3 Removing And Installing The Power Supply Unit Module

    3. Push the latch then hold the tray handle tab. Then pull the module gently until it slides out of the enclosure. 2.3.2 Installing the power supply module 1. Slide in the module into the enclosure. 2. Make sure the latch on the module is fully hooked onto the power supply housing. J4060-01 User's Manual...

  • Page 24: 2�4 Removing And Installing The Fan Module

    2. Hold the fan module from both sides. 3. Pull the fan module gently and firmly until it is removed. 2.4.2 Installing the fan module 1. Align the fan module with the opening in the enclosure. 2. Insert the fan module into the enclosure. J4060-01 User's Manual...

  • Page 25: 2�5 Removing And Installing The Expander Module

    1. Align the expander module with the opening in front of the enclosure and insert it firmly into the enclosure. 2. Close the lever and secure the retaining screw. Secondary Edge Expander Board Secondary Edge Expander Board Primary Edge Expander Board Primary Edge Expander Board J4060-01 User's Manual...

  • Page 26: 2�6 Removing And Installing The Bmc Module

    1. Dislodge the BMC module from the carrier board. 2. Remove the BMC module. 2.6.2 Installing the BMC module 1. Align the BMC module on the carrier board 2. Place the BMC module onto the carrier board. J4060-01 User's Manual...

  • Page 27: 2�7 Removing And Installing The Hdd Backplane Module

    1. Slide the HDD backplane module into JBOD and close the lever. 2. Cover JBOD with LED front board and screw both sides. warning : before you pull out the hdd backplane, must remove all the hdd trays and expander modules first. J4060-01 User's Manual...

  • Page 28: 2�8 Installing The Slide Rail

    2.8.1 Installing the slide rail To install the slide rail, please refer to the manual in the slide rail kit. Option 1: AP61-843 Slide Rail Screw Sack User’s Manual Option 2 : AP61-920 J4060-01 User's Manual Slide Rail Screw Sack User’s Manual...

  • Page 29: Chapter 3. Sub-System Configuration Setup

    : To have multiple host access support (the host number can be up to the number of wide ports on each AIC 12G Expander Controller), only the following drives are supported for shared access: 1. SAS drive / nearline sas drive 2.

  • Page 30: 3�2 Connect Host To Jbod Via Rs232

    Chapter 3 Sub-system Configuration Setup 3�2 Connect Host to JBOD via RS232 Use a RS-232 DB9 cable to connect the console port of JBOD with host's PC COM port (see figures below for DB9 RS-232 cable and SAS expander COM port). J4060-01 User's Manual...

  • Page 31: 3�3 Utility Setup On Host

    Step 1: Set up host RS232 connection Set up RS232 connection application into your host as shown in the example process below. For example: OS: Microsoft Windows Server 2008 RS232 connection application: Hyperterminal Step 2: Install HyperTrm.exe J4060-01 User's Manual...
  • Page 32 Step 3: Enter a new name for the icon in the field below and click OK. Step 4: Connect by using selecting an option in the drop down menu circled in red below (we selected COM2 in this example) and click OK. J4060-01 User's Manual...
  • Page 33 Step 5: Under “Bits per second,” select 38400. Under “Flow control,” select: None. Click OK when you have finished your selections. Step 6: After step 5, you will enter hyper terminal screen. Then please press "Enter" key and the cmd line will appear on the screen. J4060-01 User's Manual...

  • Page 34: 3�4 Updating Firmware And Mfg Through Console Port

    Chapter 3 Sub-system Configuration Setup 3�4 Updating Firmware and MFG through Console Port Step 1: Please input “fdl 0 0” in command line to update the firmware. Step 2: Select the tool bar ''Transfer'' → ''Send File'' within 10 seconds. J4060-01 User's Manual...
  • Page 35 Chapter 3 Sub-system Configuration Setup Step 3: Select the Firmware file and set the Protocol type as “Xmodem.” Press the “Send” button. 4U60swap Step 4 : After completing the FW update, “ Buffer Download Complete” will appear on the screen. J4060-01 User's Manual...
  • Page 36 Step 6 : Go to the Transfer menu and then select “Send file” within 10 seconds. Step 7 : Select the MFG file and set the Protocol type as “Xmodem.” Press the “Send” button. Step 8 : After completing the MFG update, “ Buffer Download Complete” will appear on the screen. J4060-01 User's Manual...

  • Page 37: Configure Command Line Interface Operation

    3.5.1 How to enable/disable T10 zoning The default T10 zoning configuration is off. (A) Check the current zoning state cmd> phyzone state Zoning is OFF (B) Enable zoning cmd> phyzone on (C) Disable zoning cmd> phyzone off J4060-01 User's Manual...
  • Page 38 Step 5: Assign the drive on PHY21 of EDGE to be accessed only by the second port of HUB instead of the first port cmd> phyzone 21 9 Step 6: Rest HUB and EDGE for taking effect with the new settings. cmd> reset J4060-01 User's Manual...
  • Page 39 Chapter 3 Sub-system Configuration Setup J4060-01 User's Manual...
  • Page 40 Chapter 3 Sub-system Configuration Setup 3.5.3 How to get all revisions in AIC SAS 12G Expander (A) Expander firmware revision cmd> rev (B) Expander configuration revision cmd> showmfg (C) MCU firmware revision or sensor information (MCU firmware revision is reported by Hub only) cmd>...
  • Page 41 (C) We also take expander temperature into consideration, and the temperature parameters for expander are non-changeable. Expander temperature parameters: T1=40, T2=86 (max 115*0.75) ,and no warning or alarm. The smart fan feature will use the highest PWM output which is calculated from system and expander temperature parameters. J4060-01 User's Manual...
  • Page 42 >enclosure_addr Enclosure Address: 0x50015B21682C7F3F cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd >enclosure_addr 500605B0000272BF Succeeded to set Enclosure address cmd >reset_ J4060-01 User's Manual...
  • Page 43 (B) Set the standby timer with 10 minutes. The new setting will take effect after reset. cmd> standby_timer 10 cmd> reset WARNING : This function is not recommended to use with RAID card since RAID card limitation. J4060-01 User's Manual...
  • Page 44 This feature is applicable for SAS drives instead of SATA drives. If there is no connection with any active SAS initiator by checking all wide ports, AIC Expander Controller stops all attached SAS drives to save power consumption of SAS drives. Otherwise, AIC Expander Controller starts all attached SAS drives to provide drive access service to any active SAS initiator.
  • Page 45 Chapter 3 Sub-system Configuration Setup J4060-01 User's Manual...
  • Page 46 E x p a n d e r n u m b e r : 4 2 1 - 1 2 0 2 1 7 0 4 5 1 0 0 1 0 o r E x p a n d e r n u m b e r : 4 2 1 - 12021704510010 Enclosure number: 526-12071100500088 (B) Only set Expander serial number with 421-12021704510010. cmd> serial_number 421-12021704510010 (C) Set both of Expander serial number (421-12021704510010) and Enclosure serial number (526-12071100500088). cmd> serial_number 421-12021704510010 526-12071100500088 J4060-01 User's Manual...
  • Page 47 3.5.9 How to power off/on all disk drives automatically This feature is applicable for SAS/SATA drives. If there is no connection with any active SAS initiator by checking all wide ports, AIC Expander Controller powers off all attached SAS/SATA drives to save power consumption. Otherwise, AIC Expander Controller powers on all attached SAS/SATA drives to provide drive access service to any active SAS initiator.
  • Page 48 Chapter 3 Sub-system Configuration Setup 3.5.10 How to configure EDFB (EDGE only) The default EDFB configuration is off. (A) Check the current configuration cmd> edfb EDFB is OFF (B)Enable the edfb cmd>edfb on (C)Disable the edfb cmd> edfb off J4060-01 User's Manual...
  • Page 49 "keep on", and "keep last state". The default setting is "keep off". (A) Get the current power setting cmd> power_setting Power setting: keep off (B) Set "keep off" cmd> power_setting keep_off (C) Set "keep on" cmd> power_setting keep_on (D) Set "keep last state" cmd> power_setting keep_last_state J4060-01 User's Manual...
  • Page 50 Chapter 3 Sub-system Configuration Setup J4060-01 User's Manual...
  • Page 51 Port connection, refer to 1.4 8644 with Zoning Configuration and 8644 port definition (A)Get current zone count cmd> zonecount Zone Count 1 (B) Set zone count = 2 cmd> zonecount 2 Succeeded to set zone count 2 J4060-01 User's Manual...
  • Page 52 (C-3) When Zone Count = 4, T10 zoning is enabled. No disk could be seen if we connect HBA/RAID card with port 5 and 6 of HUB. HUB: Zone # Others Wideport EDGE: Zone # Slot 1~15 16~30 31~45 46~60 J4060-01 User's Manual...
  • Page 53 7 cmd> reset (B) Restore the default of the zone count = 1 after keeping the SAS address. The SAS address (500605B0:000272BF) is used for HUB. cmd> regerase 4 cmd> regerase 5 cmd> sasaddr 500605B0000272BF cmd> reset J4060-01 User's Manual...

  • Page 54: 3�6 Ses Inband Features

    Chapter 3 Sub-system Configuration Setup 3�6 SES Inband Features To ensure J4060-01 can work properly and provide high performance, durability. J4060-01 has implemented SCSI Enclosure Services to monitor the status of power supply, system cooling fan and working temperature. It also has the indicators to deliver the status of fail devices such as power supply or cooling fan.
  • Page 55 Threshold control element format BYTE/BIT REQUESTED HIGH CRITICAL THRESHOLD REQUESTED HIGH WARNING THRESHOLD REQUESTED LOW WARNING THRESHOLD REQUESTED LOW CRITICAL THRESHOLD Threshold control element format BYTE/BIT HIGH CRITICAL THRESHOLD HIGH WARNING THRESHOLD LOW WARNING THRESHOLD LOW CRITICAL THRESHOLD J4060-01 User's Manual...
  • Page 56 BYTE/BIT Chassis Number If no chassis number is found, return Status = 1 (failed) only, else return Status=0 (success) followed by chassis number. Chassis Number status format BYTE/BIT Status (0: success, 1: failed) Chassis Number (if success) J4060-01 User's Manual...
  • Page 57 BYTE/BIT Canister Number If no canister number is found, return Status = 1 (failed) only, else return Status=0 (success) followed by canister number. Canister Number status format BYTE/BIT Status (0: success, 1: failed) Canister Number (if success) J4060-01 User's Manual...
  • Page 58 A failure condition is detected 1: On RQSTED ON 0: Off for Disk Power Supply 1: Off for Disk Power Supply 0: On AC FAIL A failure condition is detected DC FAIL A failure condition is detected J4060-01 User's Manual...
  • Page 59 0: Enable the smart fan function 1: Disable the smart fan function ACTUAL FAN Current fan RPM SPEED FAIL The fan RPM can’t be detected or equal to 0. ACTUAL SPEED Speed code level bases on current fan RPM. CODE J4060-01 User's Manual...
  • Page 60 Temperature has exceeded the failure high threshold value OT WARNING Temperature has exceeded the warning high threshold value UT FAILURE Temperature is below the failure low threshold value UT WARNING Temperature is below the warning low threshold value J4060-01 User's Manual...
  • Page 61 0: Identify LED of Hub is OFF IDENT 1: Identify LED of Hub is solid ON FAILURE Set by the REQUEST FAILURE on Enclosure Control Element REQUESTED WARNING Set by the REQUEST WARNING on Enclosure Control Element REQUESTED J4060-01 User's Manual...
  • Page 62 OVER UNDER VOLTAGE Field Value OK: Everything is Ok ELEMENT NON-CRITICAL: If either warning limit is exceeded STATUS CODE CRITICAL: If either failure limit is exceeded FAIL A warning or failure condition is detected VOLTAGE Voltage reading J4060-01 User's Manual...
  • Page 63 RQST REMOVE Please refer to section “SES Element Control Functions” for details. RQST IDENT Please refer to section “SES Element Control Functions” for details. RQST FAULT Please refer to section “SES Element Control Functions” for details. DEVICE OFF Please refer to section “SES Element Control Functions” for details. J4060-01 User's Manual...
  • Page 64 Set by the RQST REMOVE on Array Device Control Element IDENT Set by the RQST IDENT on Array Device Control Element FAULT REQSTD Set by the RQST FAULT on Array Device Control Element DEVICE OFF Set by the DEVICE OFF on Array Device Control Element J4060-01 User's Manual...
  • Page 65 RQST R/R ABORT Activity Slow Blink RQST ACTIVE Activity DO NOT REMOVE Activity RQST MISSING RQST INSERT Activity Slow Blink RQST REMOVE Activity Slow Blink RQST IDENT Slow Blink RQST FAULT DEVICE OFF PRDFAIL Activity Slow Blink J4060-01 User's Manual...
  • Page 66 We use the software package "sg3_utils" on Linux for example, and have a SAS HBA and a cable to connect your host with the expander. (A) Show the device for AIC Expander Controller (canister) $ sg_map -i /dev/sg2 AIC 12G 4U60swap: Edge-L 0c08 (B) Get the current state of a slot power.
  • Page 67 “PowerSupply01” or “PowerSupply02” to power off the entire enclosure. We use the software package "sg3_utils" on Linux for example, and have a SAS HBA and a cable to connect your host with the expander. (A) Show the device for AIC Expander Controller (canister) $ sg_map -i /dev/sg2 AIC 12G 4U60swap: Hub...
  • Page 68 Clear the bit to disable the identity. We use the software package "sg3_utils" on Linux for example, and have a SAS HBA and a cable to connect your host with the expander. (A) Show the device for AIC Expander Controller (canister) $ sg_map -i /dev/sg2 AIC 12G 4U60swap: Hub...
  • Page 69 "sg3_utils" on Linux for example, and have a SAS HBA and a cable to connect your host with the expander. (A) Show the device for AIC Expander Controller (canister) $ sg_map -i /dev/sg2 AIC 12G 4U60swap: Hub...
  • Page 70 We use the software package "sg3_utils" on Linux for example, and have a SAS HBA and a cable to connect your host with the expander. (A) Show the device for AIC Expander Controller (canister) $ sg_map -i...
  • Page 71 Chapter 3 Sub-system Configuration Setup REQUESTED SPEED CODE 100% Leave at current speed J4060-01 User's Manual...

  • Page 72: Chapter 4. Bmc Configuration Settings

    4.1 Login Open a web browser and enter the default IP http://192.168.11.11. When the login window appears, set the user name and password to ''admin.'' Click Log In to continue. Type the default account and password Account:admin Password:admin J4060-01 User's Manual...

  • Page 73: Sensor's Location For Fan & Temperature

    Chapter 4 BMC Configuration Settings 4.2 Sensor’s Location for Fan & Temperature EXP: expander chip J4060-01 User's Manual...

  • Page 74: 4�3 Utility Setup On Host

    [OK]. Type in the command "#[30 0 2 1 3 0 0]" to check for the BMC default IP. The screen will automatically display [34 00 02 00 11 C0 AB 0B 0B]. J4060-01 User's Manual...
  • Page 75 The number in the red box represents hexadecimal number. According to the left picture, the IP is calculated as follows: 16*12 + 0 = 192, 16*10 + 8 = 168, 16*5 + 8 = 88, 16*6 + 11 = 107 192.168.88.107 J4060-01 User's Manual...
  • Page 76 The green number in the red box is the completed code. 00 means OK. The blue text is the value that can be configured. To configure the IP address, set the LAN status to static. To use BMC firmware 4U60JBC020020 or later versions, set the default IP to 192.168.11.11. J4060-01 User's Manual...

  • Page 77: Bmc Led Signal

    The are two BMD LED signals under the BMC console port. Blue LED Light- Normal execution. Red LED Light- An error occurred while executing.     BMC LAN port BMC console port BMC LAN port BMC console port J4060-01 User's Manual...

  • Page 78: 4�6 Web Ui

    A graphical representation of all events incurred by the various sensors and % occupied/available space in logs. If you click on the color-coded rectangle in the Legend for the chart, you can view a list of those specific events only. J4060-01 User's Manual...
  • Page 79 • Area Format Version • Product Part Number • Product Version • Language • Manufacture Date Time • Product Serial Number • Board Manufacturer • Asset Tag • Board Product Name • FRU File ID • Product Extra J4060-01 User's Manual...
  • Page 80 Blue: The HDD is inserted into the slot and the power is off. Red: The HDD is inserted into the slot and there is an error. Gray: The HDD is not inserted into the slot. Orange: The disk is rebuilding. J4060-01 User's Manual...
  • Page 81 Turn ON or OFF the live widget for this sensor. This widget gives a dynamic representation of the readings for the sensor. View this Event Log Click this button to go the event log page for the viewed sensor. J4060-01 User's Manual...
  • Page 82 Navigational arrows can be used to selectively access different pages of the Event Log. Clear All Event Logs Clear All Event Logs option will delete all existing records for all sensors. Save All Event Logs Save All Event Logs option will save all existing records for all sensors. J4060-01 User's Manual...
  • Page 83 Domain Settings It lists the options for the domain interface as Manual, v4 or v6 for multi LAN channels. Domain Name It displays the domain name of the device if Auto is selected. If the Domain setting is chosen as Manual, then specify the domain name of the device. J4060-01 User's Manual...
  • Page 84 • IPv4 Address format. • IPv6 Address format. Save Click ‘Save’ to save any changes made. You will be logged out of current UI session and will need to log back in. Reset Reset the modified changes. J4060-01 User's Manual...
  • Page 85 This field displays the MAC address of the selected interface (read only). IPv4 Configuration It lists the IPv4 configuration settings. Obtain an IP address automatically Enable ‘Use DHCP’ to dynamically configure the IPv4 address using Dynamic Host Configuration Protocol (DHCP). J4060-01 User's Manual...
  • Page 86 Save Click ‘Save’ to save any changes made. You will be prompted to log out of the current UI session and log back in at the new IP address. Reset Click ‘Reset’ to reset the modified changes. J4060-01 User's Manual...
  • Page 87 Link speed will list all the supported capabilities of the network interface. It can be 10/100/1000 Mbps. Duplex Mode Select any one of the following Duplex Modes. - Half Duplex - Full Duplex Save Click 'Save' to save the settings. Reset J4060-01 User's Manual Click 'Reset' to reset the modified changes.
  • Page 88 Specify the NTP Server for the device. Check the ‘Automatically synchronize’ option to configure the NTP Server. The NTP Server will support the following: • IP Address (Both IPv4 and IPv6 format). • FQDN (Fully qualified domain name) format. J4060-01 User's Manual...
  • Page 89 Check this option to automatically synchronize Date and Time with the NTP Server. Refresh Click ‘Refresh’ to reload the current date & time settings. Save Click ‘Save’ to save any changes made. Reset Click ‘Reset’ to reset the modified changes. J4060-01 User's Manual...
  • Page 90 A maximum of 60 slots are available. LAN Destination Click the LAN Destination tab to show configured LAN destinations and available slots. You can modify or add new LAN destination entries here. A maximum of 15 slots are available J4060-01 User's Manual...
  • Page 91 Select a free slot and click ‘Add’ to add a new entry to the device. Alternatively, double click on a free slot. Modify Select a configured slot and click ‘Modify’ to modify that entry. Alternatively, double click on the configured slot. Delete Select the desired configured slot to be deleted and click ‘Delete’. J4060-01 User's Manual...
  • Page 92 • Machine Name is a string of maximum 15 alpha-numeric characters. • Space, special characters are not allowed. Primary SMTP Server It lists the Primary SMTP Server configuration. SMTP Support Check this option to enable SMTP support for the BMC. J4060-01 User's Manual...
  • Page 93 It lists the Secondary SMTP Server configuration. It is an optional field. If the Primary SMTP server is not working, then it tries the Secondary SMTP Server configuration. Save Click ‘Save’ to save the new SMTP server configuration. J4060-01 User's Manual Reset Click ‘Reset’ to reset the modified changes.
  • Page 94 This page displays the device's current date & time. It can be used to configure dates within a week or specific a date to power on/off the device. If you want to change the device date & time, please go to the NTP page. J4060-01 User's Manual...
  • Page 95 Check a action to do power on/off for the device. Set days for action Setting dates within a week to do power on/off for the device. Date Specify a date for the device. Time Specify a time for the device. J4060-01 User's Manual...
  • Page 96 Modify User Select a configured slot and click ‘Modify User’ to modify that user. Alternatively, double click on the configured slot. Delete User Select the desired user to be deleted and click ‘Delete User’ J4060-01 User's Manual...
  • Page 97 Power On Storage Select this option to power on the storage. Power Cycle Storage Select this option to first power off, and then reboot the system (cold boot). Perform Action Click ‘Perform Action’ to perform the selected option. J4060-01 User's Manual...
  • Page 98 Choose an expander that can use smart console in Java SOL. note : A compatible JRE must be installed in the system prior to the launch of the JNLP file. Volatile-Bit-Rate Please set 38.4K Non-Volatile-Bit-Rate Please set 38.4K J4060-01 User's Manual This function can connect to expander command line mode.

  • Page 99: 4�7 Firmware Update

    1. Check if the BMC IP is valid. 2. Open a browser and type in the BMC IP. It will show the BMC web UI. Type in the default account or use an administrator privileged account. Username: admin Password: admin J4060-01 User's Manual...
  • Page 100 Chapter 4 BMC Configuration Settings 3. This is login main page. 4. Click the “Firmware Update” and a drop-down menu will pop up. Click the “Firmware Update.” J4060-01 User's Manual...
  • Page 101 5. This page will show the update warning. If you really want to update BMC firmware, click the “Enter Update Mode” button. 6. Wait few minutes, it will pop a window. Click the “Select file” to upload firmware file that you want to update. J4060-01 User's Manual...
  • Page 102 7. Wait a few minutes. it will pop a window for check update section. Check the “Check this option to do all full firmware flash” option. 8. Click “OK” for the firmware to start the update process. J4060-01 User's Manual...
  • Page 103 9. In the update process, it will take 3~5 minutes. Caution: Please do not close this webpage!! Or it will let the firmware death 10. When “Device has been reset” window appears, it means firmware update is successful. Wait 90 seconds for BMC to restart. J4060-01 User's Manual...

  • Page 104: 4�8 Expander Firmware Update

    Chapter 4 BMC Configuration Settings 4�8 Expander Firmware update 1. Click the “Firmware Update” and it will pop a drop-down menu. Click the “Expand Update.” 2. Choose the expander firmware file that you want to update. J4060-01 User's Manual...
  • Page 105 Chapter 4 BMC Configuration Settings 3. Choose the expander firmware file and then click the “upload” button. 4. Click the ''Proceed'' button. J4060-01 User's Manual...
  • Page 106 Chapter 4 BMC Configuration Settings 5. Processing 6. Update successful. J4060-01 User's Manual...
  • Page 107 Chapter 4 BMC Configuration Settings 7. If the update processes not successful, please check the version of the expander firmware or whether if the system is turned off. J4060-01 User's Manual...

  • Page 108: Firmware Safety Mode

    1. If you see the sensor name, status LED and ID LED are abnormal, the LEDs are cross blinking, it means the firmware is in safety mode. In safety mode some of the functions will be useless! J4060-01 User's Manual...
  • Page 109 Chapter 4 BMC Configuration Settings     BMC LAN port BMC console port BMC LAN port BMC console port J4060-01 User's Manual...
  • Page 110 Chapter 4 BMC Configuration Settings 2. Please clear browser cookies and re-start browser. The BMC web UI will refresh the web page object. J4060-01 User's Manual...
  • Page 111 Chapter 4 BMC Configuration Settings 3. Click the “BMC Reset” button to go into the reset page. 4. Select the “BMC reset” and Click the “Perform Action” button. J4060-01 User's Manual...
  • Page 112 5. The page will show “Requesting” status. This web page will be invalid because of resetting the BMC. Wait 90 seconds to clear browser cookies to re-login the web UI again. 6. If you still see the safety mode page, please follow section 4.5 web update to do firmware update. J4060-01 User's Manual...

  • Page 113: Chapter 5� Technical Support
