- Page 1 RSC-15 Rackmount Storage Chassis User's Manual UM_RSC-15_v.2_061616...
-
Page 2: Table Of Contents
CONTENTS PREFACE ������������������������������������������������������������������������������������������� i SAFETY INSTRUCTIONS �������������������������������������������������������������������� ii Chapter 1� Prodcut Introduction ������������������������������������������������ 1 1�1 Box Content ����������������������������������������������������������������������������������������1 1.2 Specifications �������������������������������������������������������������������������������������2 1�3 General Information ���������������������������������������������������������������������������3 Chapter 2� Hardware Installation ����������������������������������������������� 6 2�1 Removing and Installing Top Cover �������������������������������������������������6 2�2 Installing/ Removing a Hard Disk Drive ��������������������������������������������7 2�3 Removing and Installing a PSU Module �������������������������������������������8 2�6 Removing and Installing a Fan Module �������������������������������������������9 2�4 Removing and Installing a Fan Module �������������������������������������������9... - Page 3 Copyright © 2016 AIC, Inc� All Rights Reserved� This document contains proprietary information about AIC products and is not to be disclosed or used except in accordance with applicable agreements.
-
Page 4: Preface
AIC shall not be liable for technical or editorial errors or omissions contained herein. The information provided is provided "as is" without warranty of any kind. To the extent permitted by law, neither AIC or its affiliates, subcontractors or suppliers will be liable for incidental, special or consequential damages including downtime cost;... -
Page 5: Safety Instructions
SAFETY INSTRUCTIONS • Before getting started, please read the following important cautions: • All cautions and warnings on the equipment or in the manuals should be noted. • Most electronic components are sensitive to electrical static discharge. Therefore, be sure to ground yourself at all times when installing the internal components. - Page 6 • product, voltage and current marked on the product’s electrical ratings label. The voltage and current rating of the cord should be greater than the voltage and current rating marked on the product. • If the equipment is not used for a long time, disconnect the equipment from mains to avoid being damaged by transient over-voltage.
-
Page 7: Chapter 1� Prodcut Introduction
• Enclosure( Power supply, fan, 16 x 3.5'' HDD tray included) • Power cord • Screws kit x 1pcs • (Include console serial cable) • Slide rail x 1set ♦ PACKAGE CONTENT MAY VARY PER REGION. RSC-15 User's Manual... -
Page 8: Chapter 1 Product Introduction
Container Load 40’ 12”(W) x 13”(D) E-ATX/SSI EEB 3.6 compliant MB Quantity System Board 12”(W) x 9.6”(D) ATX (for 33” depth option) 40’ H 3.5” hot swap Mounting Standard 30” tool-less slide rail Drive Bays Internal 2.5” RSC-15 User's Manual... -
Page 9: 1�3 General Information
Chapter 1 Product Introduction 1�3 General Information RSC-15 is a 1.5U rackmount chassis with 16 x 3.5”HDD hot swap Bays at Top and single 12G expander on HDD Backplane which is a high performance server storage product. • Front Panel System power on/off and system reset 2 drawers, each loads 8 x 3.5”... - Page 10 Chapter 1 Product Introduction • Rear Panel 2 x8 PCIe 3.0 slots 750W 1+1 redundant PSU 80+ Gold RSC-15 User's Manual...
- Page 11 Chapter 1 Product Introduction • Major Components 750W 1+1 redundant PSU 80+ Gold 4 x 6038 PWM easy swap fans 4 x 6038 PWM easy swap fans Two drawers, each supports 8 x 3.5” drives RSC-15 User's Manual...
-
Page 12: Chapter 2� Hardware Installation
Chapter 2 Hardware Installation Chapter 2� Hardware Installation This chapter provides detailed instructions on hardware installation. 2�1 Removing and Installing Top Cover Pushing release button on both side and slide forward the top cover to open cover. RSC-15 User's Manual... -
Page 13: 2�2 Installing/ Removing A Hard Disk Drive
Slide the tray out of the cage by release the latch. Remove the screw holding the hard drive tray in place. These screws cannot be removed completely from the tray. They are fastened to the tray to avoid loss. Grab the hard drive and pull to remove. RSC-15 User's Manual... -
Page 14: 2�3 Removing And Installing A Psu Module
Slide the small levers (see red arrow ) to the right. Hold the PSU lever and firmly pull the PSU out of the server chassis. 2.3.2 Installing a PSU Module • To install PSU module, follow the reverse order. RSC-15 User's Manual... -
Page 15: 2�6 Removing And Installing A Fan Module
If one of the fans is facing the wrong direction, please remove the heat sink and reinstall it so that it is facing the correct direction. * Power supply is included. Motherboard is not included. RSC-15 User's Manual... - Page 16 Pull the fan module up gently and taking out the fan module by removing rubbers out from the fan bar. 2.4.2 Installing a Fan Module Make sure the 4 rubbers and connector insert firmly while fan module is inserted. RSC-15 User's Manual...
-
Page 17: 2�5 Removing And Installing The Hdd Backplane Module
• Grasp and lift up the blackplane then can get out. 2.5.2 Installing a HDD backplane module • Slide the HDD backplane module into enclosures. • Secure the HDD backplane module onto the enclosures using the screws. Follow the reverse order. RSC-15 User's Manual... -
Page 18: 2�6 Removing And Installing A 2�5-Inch Ssd
Then place the other rear bracket side of HDD into the cage until it clips. * Power supply is included. Motherboard is not included. RSC-15 User's Manual... -
Page 19: 2�8 Tool-Less Blade Slide Installation Introduction
Chapter 2 Hardware Installation 2�8 Tool-less Blade Slide Installation Introduction 1. Pull on the ‘’Front-Release’’to unlock the inner channel from the Slide Assembly. 2. Release the Detent-Lock and push Middle Channel inwards to retract Middle Channel. RSC-15 User's Manual... - Page 20 Chapter 2 Hardware Installation Optional: Remove Metal Spacer for Aluminium Racks Metal Spacer 3. Aligning the Front Bracket with the Mounting Hole. 4. Push in to assembly the Front Bracket onto the Rack. RSC-15 User's Manual...
- Page 21 Chapter 2 Hardware Installation 5. Now the bracket is fixed onto the Rack. (Optional M6x10L screws are to secure the rails with posts if needed.) 6. Refer to Diagram 3. & 4. to assemble the End Bracket onto the Rack. RSC-15 User's Manual...
- Page 22 Chapter 3 Hardware Instruction 7. Assemble the inner channel onto the chassis using thescrews provided. 8. Push the chassis with inner channels into Slide to complete Rack Installation. RSC-15 User's Manual...
-
Page 23: Chapter 3� Hardware Instruction
SASHD JPWR JFAIL_IN JFAIL_OUT HDD1 HDD2 HDD3 HDD1 3.1.2 Internal Connectors/Jumpers Led status Header - JLED_IN Description Description HDD1_ACT HDD1_FAIL HDD2_ACT HDD2_FAIL HDD3_ACT HDD3_FAIL HDD4_ACT HDD4_FAIL Led Fail status Header – JFAIL_IN Description FAIL_IN_1 FAIL_IN_2 FAIL_IN_3 FAIL_IN_4 RSC-15 User's Manual... - Page 24 Access LED from SGPIO. Open Identify behavior according to Host. Close Blinking the Identify LED behavior. Open Disable SGPIO. Close Enable SGPIO. Note: For Expander jumper: JSGPIO_SET [2] [3,4] [6][8] For HBA/RAID card : JSGPIO_SET [2] [3,4] [6][7,8] RSC-15 User's Manual...
-
Page 25: 3�2 Drive Slot Map
Chapter 3 Hardware Instruction 3�2 Drive Slot Map FIRST LEVEL HBA Card SENCOND LEVEL HBA Card AND SO ON FIRST LEVEL MegaRaid Card AND SO ON RSC-15 User's Manual... -
Page 26: Chapter 4� Technical Support
Chapter 1 Product Introduction Chapter 1 Product Introduction Chapter 4� Technical Support www�aicipc�com • TAIWAN Tel: +886 3 433 9188 Fax: +886 3 287 1818 Email : sales@aicipc�com�tw • CHINA Tel: +86�21�54961421, +86�21�54961422 Fax: Extension: 608 Email Technical Support: support@aicipc�com •...
