AIC J2024-01 User Manual

Sas/sata jbod series
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
J2024-01
SAS/SATA JBOD SERIES
User's Manual
D/N:MAN-00304-C
P/N: H882JKC000-00010-?

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the J2024-01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AIC J2024-01

Summary of Contents for AIC J2024-01

  • Page 1 J2024-01 SAS/SATA JBOD SERIES User's Manual D/N:MAN-00304-C P/N: H882JKC000-00010-?

  • Page 2: Table Of Contents

    CONTENTS PREFACE �������������������������������������������������������������������������������������������������������� i SAFETY INSTRUCTIONS ��������������������������������������������������������������������������������� ii Chapter 1� Prodcut Introduction �������������������������������������������������������������1 1�1 Box Content ������������������������������������������������������������������������������������������������������ 1 1.2 Specifications ��������������������������������������������������������������������������������������������������� 2 1�3 General Information ����������������������������������������������������������������������������������������� 3 1�4 SCSI Enclosure Services - 2 (SES-2) ����������������������������������������������������������������� 6 Chapter 2� Hardware Installation ������������������������������������������������������������7 2�1 Removing and Installing Top Cover ���������������������������������������������������������������...
  • Page 3 Copyright © 2015 AIC, Inc� All Rights Reserved� This document contains proprietary information about AIC products and is not to be disclosed or used except in accordance with applicable agreements.

  • Page 4: Preface

    AIC shall not be liable for technical or editorial errors or omissions contained herein. The information provided is provided "as is" without warranty of any kind. To the extent permitted by law, neither AIC or its affiliates, subcontractors or suppliers will be liable for incidental, special or consequential damages including downtime cost;...

  • Page 5: Safety Instructions

    SAFETY INSTRUCTIONS • Before getting started, please read the following important cautions: • All cautions and warnings on the equipment or in the manuals should be noted. • Most electronic components are sensitive to electrical static discharge. Therefore, be sure to ground yourself at all times when installing the internal components.
  • Page 6 • product, voltage and current marked on the product’s electrical ratings label. The voltage and current rating of the cord should be greater than the voltage and current rating marked on the product. • If the equipment is not used for a long time, disconnect the equipment from mains to avoid being damaged by transient over-voltage.

  • Page 7: Chapter 1� Prodcut Introduction

    • RS232 cablex 1pcs • Power cord x 2pcs • Screws kit x 1set • Mounting Optional • Slide Rail x 1set • Adjuster Plate x 1set If any items are missing, please contact your authorized reseller or sales representative. J2024-01 User's Manual...

  • Page 8: Specifications

    600 x 810 x 278 inches: 23.6 x 31.9 x 11 Mounting Option Adjuster plate or 20” tool-less rail （optional Product Features New Technology LSI SAS 12G High Density Optimized Thermal/Acoustic Solution Fully Hot swap Modulize Design J2024-01 User's Manual...

  • Page 9: 1�3 General Information

    Chapter 1 Product Introduction 1�3 General Information J2024-01 is a 2U rackmount chassis with 24 x 2.5”HDD hot swap bay and dual expand module JBOD, which is a high performance, high density, scalable storage product. The J2024-01 JBOD supports T10 zoning function and can be shared by up to 6 servers.

  • Page 10: Chapter 1 Product Introduction

    Chapter 1 Product Introduction • Rear Expender Panel BMC LAN port(option) Debug port BMC console port SFF 8644 wide port Console port BMC LAN port(option) BMC console port SFF 8644 wide port 2 Dual Expander (Primary & Secondary) J2024-01 User's Manual...
  • Page 11 Chapter 1 Product Introduction • Rear Panel J2024-01 User's Manual...

  • Page 12: 1�4 Scsi Enclosure Services - 2 (Ses-2)

    Chapter 1 Product Introduction 1�4 SCSI Enclosure Services - 2 (SES-2) To ensure J2024-01 can work properly and provide high performance, durability. J2024-01 has implemented SCSI Enclosure Services-2 to monitor the status of power supply, system cooling fan and working temperature.

  • Page 13: Chapter 2� Hardware Installation

    Chapter 2� Hardware Installation This chapter provides detailed instructions on hardware installation. 2�1 Removing and Installing Top Cover Loosen 5 screws on top cover. Take it out of the enclosure. J2024-01 User's Manual...

  • Page 14: 2�2 Removing/Installing A Drive Tray/ Hard Drive/ Drive Slot Map

    2.2.2 Installing a Disk Drive Adjust and place the 2.5” HDD on the HDD tray. Choose to the proper position screw hole then secure it with screws on the bottom. Mounting location 1 : HDD with the interposer board attached. J2024-01 User's Manual...
  • Page 15 Insert the drive carrier into its bay. Push the tray lever until it clicks. Make sure the drive tray is correctly secured in place when its front edge aligns with the bay edge. 2.2.4 Drive Slot Map The drive slot map follows. HBA Card MegaRaid Card J2024-01 User's Manual...

  • Page 16: 2�3 Removing And Installing A Psu Module

    Pushing the latch then hold the tray handle tab. Then pull the PSU module gently until it slides out of the JBOD. 2.3.2 Installing a PSU Module • Slide in PSU module. • Make sure the latch on the module is fully hooked onto the PSU housing. J2024-01 User's Manual...

  • Page 17: 2�4 Removing And Installing A Fan Module

    Hold the fan module from both sides. • Pull the fan module gently and firmly until it clears the enclosure chassis. 2.4.2Installing a Fan Module • Align the fan module with the opening in the enclosure. • Insert the fan module into JBOD. J2024-01 User's Manual...

  • Page 18: 2�5 Removing And Installing External Expander Module

    Hold the lever to pull the expander out of JBOD. 2.5.2 Installing an expander module • Align the expander module with the opening in front of the enclosure, and insert it into the enclosure firmly. • Close the lever and secure the retaining screw. J2024-01 User's Manual...

  • Page 19: 2�6 Removing And Installing The Hdd Backplane Module

    Hold the backplane module to pull the backplane module out of JBOD. 2.6.2 Installing a HDD backplane module • Slide the HDD backplane module into JBOD. • Secure the HDD backplane module onto the JBOD using the screws. J2024-01 User's Manual...

  • Page 20: 2�7 Installing Slide Rail /Adjuster Plate

    Chapter 2 Hardware Installation 2�7 Installing Slide Rail /Adjuster Plate 2.7.1 Installing slide rail To install the slide rail, please refer to the manual in the slide rail kit. 7.Slide Rail Installation User’s Manual Screws kit J2024-01 User's Manual...
  • Page 21 Secure the adjuster plate on the rack using the screws. • Insert the slide rail into the adjuster plate and make sure the slide rail is fully hooked into the adjuster plate. M4 X 6L screws kit * 1sets (10pcs) Adjuster plate *2 sets J2024-01 User's Manual...
  • Page 22 Chapter 2 Hardware Installation 2.7.3 Installing the front of JBOD onto the rack • Secure the JBOD on the rack using the screws. • Complete installing JBOD. J2024-01 User's Manual...

  • Page 23: Chapter 3. Sub-System Configuration Setup

    Each AIC 12G Expander Controller note : To have multiple host access support (the host number can be up to the number of wide ports on each AIC 12G Expander Controller), only the following drives are supported for shared access: 1. SAS drive 2.

  • Page 24: 3�2 Utility Set Up On Host

    Step 1: Set up host RS232 connection Set up RS232 connection application into your host as shown in the example process below. For example: OS: Microsoft Windows Server 2008 RS232 connection application: Hyperterminal Step 2: Install HyperTrm.exe J2024-01 User's Manual...
  • Page 25 Step 3: Enter a new name for the icon in the field below and click OK. Step 4: Connect by using selecting an option in the drop down menu circled in red below (we selected COM2 in this example) and click OK. J2024-01 User's Manual...
  • Page 26 Click OK when you have finished your selections. Properties Port Setting Bits per second: Data bits: Parity: None Stop bits: Flow control: None Restore Defaults Cancel Apply Step 6 : Set up is complete. The diagram below depicts what screen should displayed. J2024-01 User's Manual...

  • Page 27: 3�3 Connect Host To Jbod Via Rs232

    Chapter 3 Sub-System configuration Setup 3�3 Connect Host to JBOD via RS232 Use a RS-232 DB9 cable connect the console port of JBOD with host's PC COM port (see figures below for DB9 RS-232 cable and SAS expander COM port). J2024-01 User's Manual...

  • Page 28: Configure Command Line Interface Operation

    Succeeded to enable zoning cmd >_ cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd >phyzone off Succeeded to dissable zoning cmd >_ J2024-01 User's Manual...
  • Page 29 Step 4: Assign the drive on PHY12 to be accessed only by the first port instead of the second port cmd> phyzone 12 8 Step 5: Assign the drive on PHY13 to be accessed only by the second port instead of the first port cmd> phyzone 13 9 Step 6: Reset J2024-01 User's Manual...
  • Page 30 > cmd > cmd >_ cmd >phyzone 13 9 Succeeded to set zone group for the phy cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd >reset J2024-01 User's Manual...
  • Page 31 Chapter 3 Sub-System configuration Setup 3.4.3 How to get all revisions in AIC SAS 12G Expander (A) Expander firmware revision cmd> rev (B) Expander configuration revision cmd> showmfg (C) MCU firmware for managing sensors cmd> sensor cmd >rev =================================================================== Firmware Revision Information;-...
  • Page 32 Temperature in Celsius(t1=20 C, t2=50 C, Warning=50 C, alarm=55 C) cmd > cmd > cmd > cmd >_ cmd > cmd > cmd > cmd > cmd > cmd >temperature 18 52 48 54 Succeeded to update temperature cmd >reset_ J2024-01 User's Manual...
  • Page 33 >enclosure_addr Enclosure Address: 0x50015B21682C7F3F cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd >enclosure_addr 500605B0000272BF Succeeded to set Enclosure address cmd >reset_ J2024-01 User's Manual...
  • Page 34 > cmd >standby_timer Standby Timer : 0 minutes cmd >_ cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd >standby_timer 10 Succeeded to set standby timer cmd >reset_ J2024-01 User's Manual...
  • Page 35 This feature is applicable for SAS drives instead of SATA drives. If there is no connection with any active SAS initiator by checking all wide ports, AIC Expander Controller stops all attached SAS drives to save power consumption of SAS drives. Otherwise, AIC Expander Controller starts all attached SAS drives to provide drive access service to any active SAS initiator.
  • Page 36 >check_wide_port on Succeeded to configure checking wide port cmd >reset_ cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd >check_wide_port off Succeeded to configure checking wide port cmd >reset_ J2024-01 User's Manual...
  • Page 37 (C) Set both of Expander serial number (421-12021704510010) and Enclosure serial number (526-12071100500088). cmd> serial_number 421-12021704510010 526-12071100500088 cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd >serial_number 421-12021704510010 526-12071100500088_ J2024-01 User's Manual...
  • Page 38 SAS HBA and a cable to connect your host with the expander. We use Linux for example. (A) Show the device for AIC Expander Controller (canister) $ sg_map -i /dev/sg2 AIC 12G 2U24SAS3swap 0c01 (B) Get the current state of a slot power.
  • Page 39 Chapter 3 Sub-System configuration Setup J2024-01 User's Manual...
  • Page 40 Chapter 3 Sub-System configuration Setup J2024-01 User's Manual...
  • Page 41 Chapter 3 Sub-System configuration Setup J2024-01 User's Manual...
  • Page 42 Chapter 3 Sub-System configuration Setup J2024-01 User's Manual...
  • Page 43 Chapter 3 Sub-System configuration Setup J2024-01 User's Manual...
  • Page 44 "sg3_utils" on your host computer, and have a SAS HBA and a cable to connect your host with the expander. We use Linux for example. (A) Show the device for AIC Expander Controller (canister) $ sg_map -i /dev/sg2 AIC 12G 2U24SAS3swap 0c01...
  • Page 45 Chapter 3 Sub-System configuration Setup J2024-01 User's Manual...
  • Page 46 Chapter 3 Sub-System configuration Setup J2024-01 User's Manual...
  • Page 47 Chapter 3 Sub-System configuration Setup J2024-01 User's Manual...
  • Page 48 We use the software package "sg3_utils" on Linux for example, and have a SAS HBA and a cable to connect your host with the expander. (A) Show the device for AIC Expander Controller (canister) $ sg_map -i /dev/sg2 AIC 12G 2U24SAS3swap 0c01 (B)Set "RQST IDENT"...
  • Page 49 Chapter 3 Sub-System configuration Setup [root@localhost ~]# sg_map -i dev/sg2 AIC 12G 2U24SAS3swap 0c01 J2024-01 User's Manual...
  • Page 50 Chapter 3 Sub-System configuration Setup # sg_ses --descriptor=SystemCooingElement01 --set=1:7:1 /dev/sg2 J2024-01 User's Manual...
  • Page 51 Chapter 3 Sub-System configuration Setup # sg_ses --descriptor=SystemCooingElement01 --set=3:2:3=7 /dev/sg2 J2024-01 User's Manual...
  • Page 52 3.4.12 How to power off/on all disk drives automatically This feature is applicable for SAS/SATA drives. If there is no connection with any active SAS initiator by checking all wide ports, AIC Expander Controller powers off all attached SAS/SATA drives to save power consumption.
  • Page 53 "keep off", "keep on", and "keep last state". The default setting is "keep off". (A) Get the current power setting cmd> power_setting Power setting: keep off (B) Set "keep off" cmd> power_setting keep_off (C) Set "keep on" cmd> power_setting keep_on (D) Set "keep last state" cmd> power_setting keep_last_state J2024-01 User's Manual...
  • Page 54 >edfb on Succeeded to set EDFB cmd>_ Disable the edfb cmd> edfb off cmd > cmd > cmd > cmd >edfb EDFB is OFF cmd >edfb on Succeeded to set EDFB cmd>edfb off EDFB is OFF cmd>_ J2024-01 User's Manual...

  • Page 55: 3�5 Power On/Off The Enclosure Via Rs232

    -F $PORT $BAUDRATE cs8 parenb parodd -cstopb $NOFLOW opost onlcr case $1 in start) echo "RemoteStart" echo -e "\n" > $PORT echo -e "RemoteStart\n" > $PORT echo -e "RemoteStart\n" > $PORT echo -e "RemoteStart\n" > $PORT echo -e "RemoteStart\n" > $PORT echo -e "RemoteStart\n" > $PORT J2024-01 User's Manual...
  • Page 56 Chapter 3 Sub-System configuration Setup stop) echo "RemoteStop" echo -e "\n" > $PORT echo -e "RemoteStop\n" > $PORT echo -e "RemoteStop\n" > $PORT J2024-01 User's Manual...

  • Page 57: Chapter 4. Bmc Configuration And Settings

    Chapter 4 BMC Configuration and Setting Chapter 4. BMC Configuration and Settings 4�1 Sensor’s location for Fan & Temperature Fan1 Fan0 FRONT J2024-01 User's Manual...

  • Page 58: 4�2 Utility Setup On Host

    Please refer to Section 3.2 4�3 Connect Host to BMC by RS232 1. Type the “[” , it will show the IPMI serial interface Type command for login the interface. #[sys pwd –u admin admin ] It will response [OK] J2024-01 User's Manual...
  • Page 59 Get LAN static IP /DHCP: 01 is static IP, 02 is DHCP� The red box is hexadecimal, according to the left picture, the IP is 16*12 + 0 = 192, 16*10 + 8 = 168, 16*5 + 8 = 88, 16*6 + 11 = 107, It is 192�168�88�107 J2024-01 User's Manual...
  • Page 60 The Green returns text that in red box is completion code, 00 means OK, The blue text can change the value what you want, if you want to change the IP address, must set the LAN status to static. J2024-01 User's Manual...
  • Page 61 Chapter 4 BMC Configuration and Setting 4. Login the web page Open a browser, type the IP in the address bar Type the default account and password Account:admin Password:admin J2024-01 User's Manual...

  • Page 62: 4�4 Web Ui

    A graphical representation of all events incurred by the various sensors and % occupied/available space in logs. If you click on the color- coded rectangle in the Legend for the chart, you can view a list of those specific events only. J2024-01 User's Manual...
  • Page 63 • Area Format Version • Product Version • Language • Product Serial Number • Manufacture Date Time • Asset Tag • Board Manufacturer • FRU File ID • Board Product Name • Product Extra • Board Serial Number J2024-01 User's Manual...
  • Page 64 Select a HDD to turn it power on. Power off Select a HDD to turn it power off. note : When select a HDD to power on/off, must to refresh this page for get the new status. J2024-01 User's Manual...
  • Page 65 Turn On or Off the live widget for this sensor. This widget gives a dynamic representation of the readings for the sensor. View this Event Log Click this button to go the event log page for the viewed sensor. J2024-01 User's Manual...
  • Page 66 Event Log. Clear All Event Logs Clear All Event Logs option will delete all existing records for all sensors. Save All Event Logs Save All Event Logs option will save all existing records for all sensors. J2024-01 User's Manual...
  • Page 67 LAN channels. Domain Name It displays the domain name of the device if Auto is selected. If the Domain setting is chosen as Manual, then specify the domain name of the device. Domain Name Server Configuration J2024-01 User's Manual...
  • Page 68 • IPv4 Address format. • IPv6 Address format. Save Click ‘Save’ to save any changes made. You will be logged out of current UI session and will need to log back in. Reset Reset the modified changes. J2024-01 User's Manual...
  • Page 69 • An IP Address consists of 4 sets of numbers separated by dots as in “xxx.xxx.xxx.xxx”. • Each set ranges from 0 to 255. • The first Number must not be 0. IPv6 Configuration It lists the IPv6 configuration settings. J2024-01 User's Manual...
  • Page 70 Save Click ‘Save’ to save any changes made. You will be prompted to log out of the current UI session and log back in at the new IP address. Reset Click ‘Reset’ to reset the modified changes. J2024-01 User's Manual...
  • Page 71 Link speed will list all the supported capabilities of the network interface. It can be 10/100/1000 Mbps. Duplex Mode Select any one of the following Duplex Modes. - Half Duplex - Full Duplex Save Click 'Save' to save the settings. Reset Click 'Reset' to reset the modified changes. J2024-01 User's Manual...
  • Page 72 Specify the NTP Server for the device. Check the ‘Automatically synchronize’ option to configure the NTP Server. The NTP Server will support the following: • IP Address (Both IPv4 and IPv6 format). • FQDN (Fully qualified domain name) format. J2024-01 User's Manual...
  • Page 73 Check this option to automatically synchronize Date and Time with the NTP Server. Refresh Click ‘Refresh’ to reload the current date & time settings. Save Click ‘Save’ to save any changes made. Reset Click ‘Reset’ to reset the modified changes. J2024-01 User's Manual...
  • Page 74 You can modify or add new LAN destination entries here. A maximum of 15 slots are available Send Test Alert Select a configured slot in the LAN Destination tab and click ‘Send Test Alert’ to send a sample alert to the configured destination. J2024-01 User's Manual...
  • Page 75 Alternatively, double click on a free slot. Modify Select a configured slot and click ‘Modify’ to modify that entry. Alternatively, double click on the configured slot. Delete Select the desired configured slot to be deleted and click ‘Delete’. J2024-01 User's Manual...
  • Page 76 • An IP Address is made of 4 numbers separated by dots as in “xxx.xxx.xxx.xxx”. • Each Number ranges from 0 to 255. • The first Number must not be 0. The server address will support the following: • IPv4 Address format. • IPv6 Address format. J2024-01 User's Manual...
  • Page 77 It lists the Secondary SMTP Server configuration. It is an optional field. If the Primary SMTP server is not working, then it tries the Secondary SMTP Server configuration. Save Click ‘Save’ to save the new SMTP server configuration. Reset Click ‘Reset’ to reset the modified changes. J2024-01 User's Manual...
  • Page 78 Alternatively, double click on a free slot to add a user. Modify User Select a configured slot and click ‘Modify User’ to modify that user. Alternatively, double click on the configured slot. Delete User Select the desired user to be deleted and click ‘Delete User’ J2024-01 User's Manual...
  • Page 79 Power On Storage Select this option to power on the storage. Power Cycle Storage Select this option to first power off, and then reboot the system (cold boot). Perform Action Click ‘Perform Action’ to perform the selected option. J2024-01 User's Manual...
  • Page 80 Launch the Java SOL, you must have Administrator privileges. note : A compatible JRE must be installed in the system prior to the launch of the JNLP file. Volatile-Bit-Rate Please set 38.4K Non-Volatile-Bit-Rate Please set 38.4K This function can connect to expander command line mode. J2024-01 User's Manual...

  • Page 81: 4�5 Firmware Update

    4.5.2 Web update 1. Check the BMC IP is valid. 2. Open a browser, type in the BMC IP, it will show the BMC web UI, type the default account, or have administrator privileges account. Username: admin Password: admin J2024-01 User's Manual...
  • Page 82 Chapter 4 BMC Configuration and Setting 3. This is login main page. 4. Click the “Firmware Update”, it will pop a drop-down menu, click the “Firmware Update” J2024-01 User's Manual...
  • Page 83 5. This page will show the update warning, if you really want to update BMC firmware, click the “Enter Update Mode” button. 6. Wait few minutes, it will pop a window, click the “Select file” to upload firmware file that you want update. J2024-01 User's Manual...
  • Page 84 Chapter 4 BMC Configuration and Setting 7. Wait a minutes, it will pop a window for check update section, just check the “Check this option to do all full firmware flash” option. 8. Click “OK” the firmware will started update operation. J2024-01 User's Manual...
  • Page 85 9. In the update processes, it will take 3~5 minutes. Caution: Please do not close this webpage!! Or it will let the firmware death 10. When show the “Device has been reset” window, it means firmware update successful, wait 90 seconds for BMC restarted. J2024-01 User's Manual...

  • Page 86: Expander Firmware Update

    Chapter 4 BMC Configuration and Setting 4.6 Expander firmware update 1. Click the “Firmware Update”, it will pop a drop-down menu, click the “Expand Update” 2. Chose the expander firmware file then click the “upload” button. J2024-01 User's Manual...
  • Page 87 Chapter 4 BMC Configuration and Setting 3. Click the “Proceed” button. 4. Updating J2024-01 User's Manual...
  • Page 88 Chapter 4 BMC Configuration and Setting 5. Update finished and successful. 6. If update processes not success, please check the expander firmware is current version or the system is already power off. J2024-01 User's Manual...

  • Page 89: 4�7 Firmware Safety Mode

    1. If you saw the sensor name, status LED and ID LED are abnormal, the LEDs are cross blinking, it means firmware is in safety mode, in safety mode some function will be useless! J2024-01 User's Manual...
  • Page 90 Chapter 4 BMC Configuration and Setting J2024-01 User's Manual...
  • Page 91 Chapter 4 BMC Configuration and Setting 2. Please clear browser cookies, and re-start browser, BMC web UI will refresh web page object J2024-01 User's Manual...
  • Page 92 Chapter 4 BMC Configuration and Setting 3. Click the “BMC Reset” button, into the reset page 4. Select the “BMC reset”, and Click the “Perform Action” button. J2024-01 User's Manual...
  • Page 93 5. The page will show “Requesting” status, because reset BMC, this web page will be invalid, wait 90 seconds and clear browser cookies, re-login web UI again. 6. If still see the safety mode page, please follow section 4.5 to do firmware update. J2024-01 User's Manual...
