14Tr Swedish Rack.qxp
5/19/09
3:03 PM
SWEDISH WINE RACK
EASY ASSEMBLY
4. Starting from the
bottom up (Figure
4a), tighten the
grommets (B)
(Figure 4b) with a
Phillips screw driver.
Re-tighten after
one week. If extra
stability is required,
use appropriate
hardware to fasten
the unit to a wall.
5. If attaching
multiple units
together, insert
steel support rods
in corresponding
outer holes and
repeat Step 2.
Figure 4b
B
B
B
B
Call 800.356.8466 or visit our website at WineEnthusiast.com
Wine Enthusiast Companies, 333 North Bedford Road, Mount Kisco, NY 10549
Wine Enthusiast and logo are registered trademarks of Wine Enthusiast Companies. @2009 Wine Enthusiast Companies
Made in Indonesia exclusively for WIne Enthusiast
Page 1
Figure 4a
B
B
B
B
®
.
SWEDISH WINE RACK
ASSEMBLY INSTRUCTIONS
W i n e E n t h u s i a s t . c o m
800.356.8466
