Table of Content 1. INTRODUCTION 1-1. Main features 1-2. Hardware introduction 1-3. How to use Web-Server 1-4. SNMP V2C Description 2. INSTALLATION AND OPERATION 2-1. Installation of SN-1 2-2. Connecting from SN-1 to PC 2-3. Reset SN-1 to Default Value 3.
1. Introduction 1-1. Main features SNMP : SN-1’s version is V2C. It can be connected to system with NMS, to set up and monitor SR-Host parameters. Web-Server : Using the browser to set up and monitor SR-Host parameters. 1-2.
1-3. How to use Web-Server 1-3-1 Web-Server introduction Fig. 2 Web-Server Main menu item description: Status: To display SR-Host status *SR-Host:SR-1600、SRC-2500… System Control: system output control UI Configuration: RS232/ Interface language/ Login password Inverter Configuration: Inverter parameter (settings ex.OVP/UVP…) Network Configuration: SNMP network settings (DHCP/IP…) SNMP Configuration: Community Name setup for SNMP V2C Note! Note! Default login name: admin...
Page 5
1-3-2 Status Page Fig. 3 Status Description Function Type Model name Loading Inverter loading Capacity Charge Current SRC Inverter series only Energy Graph It displays the energy stream direction...
Page 6
1-3-3 System Control Page Fig. 4 System Control Power Switch: To control the power on/off of the Inverter. 1-3-4 UI Config Page Fig. 5 UI Config RS-485 Baudrate: To set RS-485 baudrate. Password: 4 digits or characters password. (Default: 0000)
Page 7
1-3-5 Inverter Config Page Fig. 6 Inverter Config You may change SR Host operation and protection setting in this page: OVP Setting: Over Voltage Protection setting. OVP Recovery: Over Voltage Protection Recovery setting. UVP setting: Under Voltage Protection setting. ...
Page 8
1-3-6 Network Config Page Fig. 7 Network Config Description Function Host Name SN-1 Network Name Primary DNS Primary Domain Name Server Secondary DNS Secondary Domain Name Server Note! Incorrect network setting may cause SN-1 connection issue. Please set the values back to default whenever issue arises ( Refer to 2-3 )
Setting the interval at which traps occur each time. MAX = 65535 / per100ms, MIN = 1 / per100ms Note! Please contact your COTEK local distributor for MIB file. Note! After AC restart, trap will go back to default...
Page 10
Inverter-Status1 Bit Number Description Value Description Bit 0 Low Battery Alarm =0, No =1, Yes Bit 1 Over Load Shutdown =0, No =1, Yes Bit 2 Over Load Alarm =0, No =1, Yes Bit 3 FAN Fault =0, No =1, Yes Bit 4 Temperature status =0, Normal =1, Abnormal...
2. Installation and Operation 2-1 Installation of SN-1 Fig.9 Installation Step 1 : Hold the button on the panel and slot in the SN-1 card for 1 second Step 2 : Fix the screw 2-2 Connection from SN-1 to PC 2-2-1 Connection via the router ...
2-2-2 Connection via PC Connect from SN-1 to PC The default static IP of SN-1 is 192.168.1.250. Please change the setting value of network interface card in PC. The static IP address of PC is 192.168.1.X (The value X cannot be the same value of SN-1 IP’s 250) Fig.
24 months from the date of purchase. In case you need to repair or replace any defective power inverters, please contact COTEK local distributor. This warranty will be considered void if the unit has been misused, altered, or accidentally damaged. COTEK is not liable for anything that occurs as a result of the user’s fault.
Page 14
No.33, Sec. 2, Renhe Rd., DaxiDist., Taoyuan City 33548, Taiwan Phone:+886-3-3891999 FAX:+886-3-3802333 http:// www.cotek.com.tw 2017.11._A0...
