Inertisation /
Tankblanketing regulators
USER MANUAL
TBVS8
Read the complete manual before installing and using the regulator.
TBVS8 User Manual
Rev.date: 20-09-2010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RHPS Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Swagelok RHPS Series

Summary of Contents for Swagelok RHPS Series

  • Page 1 Inertisation / Tankblanketing regulators USER MANUAL TBVS8 Read the complete manual before installing and using the regulator. TBVS8 User Manual Rev.date: 20-09-2010...
  • Page 2 WARNING INCORRECT OR IMPROPER USE OF THIS PRODUCT CAN CAUSE SERIOUS PERSONAL INJURY AND PROPERTY DAMAGE. Due to the variety of operating conditions and applications for this product, the user is solely responsible for making the final proper decisions concerning the correct assembly and functioning of the product and assuring that all the performance, safety and warning requirements are met.

  • Page 3: Table Of Contents

    CONTENTS Introduction .............................. 1 Detailed description ........................... 1 Special features and options ......................1 Typical picture of the TBVS8......................2 Installation ..............................3 Points of attention before installation ....................3 Installation instructions ........................3 Operation ..............................4 Required tools for operation ......................4 Points of attention before operation ....................

  • Page 4: Introduction

    Introduction Detailed description This regulator is a diaphragm sensing spring loaded back-pressure regulator, designed to regulate low pressures at medium gaseous flow. The back-pressure regulator keeps control of the inletpressure. If the inletpressure exceeds the setpressure, the valve opens and gas starts to flow. It is ideal for highly accurate control of pressure because of it’s large effective sensing area.

  • Page 5: Typical Picture Of The Tbvs8

    Typical picture of the TBVS8 body assembly valve guiding ring setscrew springhousing assembly retaining ring springhousing cover ring seal housing ring socket head screw diaphragmplate bodyplug o-ring diaphragm valve ring o-ring support diaphragm valve o-ring o-ring valve stem setspring ring valve seat springguide socket head cap screw...

  • Page 6: Installation

    Installation WARNING A BACK-PRESSURE IS NOT A SAFETY VALVE AND SHOULD NOT BE USED AS SUCH Points of attention before installation This regulator can be equipped with different options and connections. Before installing the regulator you, should fully understand the options and the suitability of your particular regulator and its suitability for the application.

  • Page 7: Operation

    Operation Required tools for operation Use a socket wrench (19 mm) with an extended piece to change the setpressure. Points of attention before operation The product can be hot or cold, depending on the environment temperature and the used media temperature.

  • Page 8: Maintenance

    INCORRECT OR IMPROPER REPAIR OR SERVICING OF THIS PRODUCT CAN CAUSE SERIOUS PERSONAL INJURY AND PROPERTY DAMAGE. SWAGELOK B.V. recommends the product to be removed from the system and to be shipped to SWAGELOK B.V. for service or maintenance as all regulators must pass rigid acceptance tests before leaving the factory.

  • Page 9: Points Of Attention Before Removal From The System

    Points of attention before assembly All parts must be clean and undamaged before starting assembly. SWAGELOK B.V. recommends replacing all o-rings and the diaphragm before assembly. All threaded parts must be lubricated a little before assembly, this to avoid galling of threads.

  • Page 10: Recommended Torques

    Recommended torques Bodyplug 40 Nm Valve assembly socket head screw 10 Nm Nut on the diaphragmscrew - M10 10 Nm Socket head cap screws - 16 pcs M06 10 Nm Springhousing cover 5 Nm Testing Check the TBR8 for leakage across the seat, bodyplug and the diaphragm. Check the required setpressure range and function.
  • Page 11 TBVS8 User Manual Rev.date: 20-09-2010...

  • Page 12: Trouble Shooting

    Install the regulator with proper piping and connections. Consider the pressure drop caused by piping resistance. Warranty Information Swagelok products are backed by The Swagelok Limited Lifetime Warranty. For a copy, visit swagelok.com or contact your authorized Swagelok representative. TBVS8 User Manual Rev.date: 20-09-2010...
