Table 8: Signal Descriptions (Continued)
Pin
24
R
ATINGS

Table 9: Absolute Maximum Ratings

Parameter
Storage Temperature
Operating Temperature
V with Respect to GND
CC
Input Voltage
Output Voltage
S S
ILICON YSTEMS
All unauthorized use and/or reproduction is prohibited.
P
AGE
SSD-C
Type Description
In true IDE mode, this input signal is
not used and should be connected to
V by the host.
CC
O Write Protect Memory Mode. The
SiliconDrive CF does not have a write
protect switch. This signal is held low
after the completion of the reset
initialization sequence.
I/O Operation. When the SiliconDrive
CF is configured for I/O operation, pin
24 is used for the -I/O Selected, which
is a 16-bit port (-IOIS16) function. A
low signal indicates that a 16-bit or
odd byte only operation can be
performed at the addressed port.
In true IDE mode, this output signal is
asserted low when this device is
expecting a word data transfer cycle.
Minimum Maximum Units
-55
-40
-0.3
-0.5
-0.3
P
ROPRIETARY
14
(I)-3600 D S
XXX ATA HEET
125 °C
85 °C
6.7 V
3.8 V
3.6 V
