E S
LECTRICAL PECIFICATION
Signal Name
DMARQ
(True IDE mode)
D15-D00
(PC Card memory
mode)
D15-D00
(PC Card I/O
mode)
D15-D00
(True IDE mode)
GND
(PC Card memory
mode)
GND
(PC Card I/O
mode)
GND
(True IDE mode)
