Frequency (Hz)
Max. Inlet
Water Pressure
(See LP Water
section)
Max. Inlet Temp.
Min. Inlet Temp.
Min. Inlet
Flow Rate
Inlet Water Quality
Hydraulic Cooling Water (if not air cooled)
Min. Inlet
Water Pressure
Max. Inlet
Water Pressure
(See LP Water
section)
Max. Inlet Temp.
Min. Inlet Temp.
Normal Inlet Flow
Rate
Hydraulics
Hydraulic Oil Type
Hydraulic Oil
Capacity
Max. Oil Temp.
Min. Oil Temp.
50hp 60hp
(37kW) (45kW)
50 60 50 60
2 gpm (7.6 lpm) 2.5 gpm (9.5 lpm)
3 gpm
(11.5 lpm)
Castrol Hyspin 32 or Hyspin 46 Hydraulic Oil
38 gal (144 L)
75hp
(56kW)
50 60
115 psi (7.72 bar)
70°F (21°C)
40°F (4.4°C)
4 gpm (15.1 lpm)
See Water Quality section
40 psi (2.76 bar)
115 (7.93 bar)
70°F (21°C)
40°F (4.4°C)
4 gpm 8 gpm
(15 lpm) (30 lpm)
130°F (55°C)
55°F (12.8°C)
100hp 150hp
(75kW) (112kW)
50 60 50
5 gpm (18.9 lpm)
10 gpm
(38 lpm)
55 gal (208 L)
96 gal (363 L)
60
58
