Connect the microphone or other devices with audio
interface to the audio interface with 3.5mm headphone
cable.
Plug in power cord with IEC connector.
How to work
Push power button to ON position, the red indicator is
on if the device is in normal operation.
When input DVI and HDMI signal simultaneously, the
HDMI signal has priority, green signal indicator lights,
and the device output HDMI signal. Pull out the HDMI
cable, green signal indicator lights, and then the device
output DVI signal.
How to control the brightness of sending
card
1. First, make sure the device is in normal operation.
2. Choose the brightness value according to actual need
via UP/DOWN keys, the adjustment value range is
0~16 for Colorlight Q7e sending card, 0~64 for
Nova MSD300 sending card, and 1~16 for Linsn 801,
802 and DBstar HRV2011 sending card. The higher
the brightness value, the brighter sending card will be.
Common Questions and Solution
Nixie tube can not display brightness value
It usually occurs in Nova sending card. When Nova
sending card connected to PC software via USB, the key
operation of control brightness is invalid, and nixie tube
will not display the brightness value. User can only
control the brightness via PC software or pull out the
USB cable to recover the key brightness controlling.
No output on LED display
1. Check whether input the signal.
2. Check whether the cable is connected, and in good
connection.
3. Check whether the input and output cable are normal.
