Before using this product please read the instructions carefully.
After reading the instruction manual, please keep it for reference.
Caution
● Keep this product out of the reach of children under 3.
● Keep this product away from small children.
Seek medical advice immediately if it is swallowed.
● Please be careful and not allow children to wrap
the cord around their neck.
● Keep the controller away from dusty or humid areas.
● Do not use this product if damage or alteration occurs.
● Do not get the product wet or leave it where it can get wet.
It may cause an electric shock or defect.
● Do not leave the product around a heater, audio amp, etc.
Do not leave it under direct sunlight It may cause a defect.
Included
Platform
Nintendo Switch / PC(Xinput)
Please read the Nintendo Switch instructions carefully before you use this product
Important
with the Nintendo Switch console.
Make sure that your Nintendo SwitchTM is updated with the latest system software.
※ This product is not a wireless controller.
※ Please be aware that unexpected action may occur if the Turbo function is used in the HOME Menu.
Layout
Nintendo Switch
Left Stick
{Left Stick Button (Hold)}
Right Stick
{Right Stick Button (Hold)}
- Button
Controller cable
PC
Left Stick
{Left Stick Button (Hold)}
Right Stick
{Right Stick Button (Hold)}
BACK Button
Controller cable
How to connect
Please insert the USB connector of the controller into the USB port of
the Nintendo Switch
TM
※ Do not connect to anything other than a USB port. It may cause a defect.
L/R to ZL/ZR Toggle Function
Switch button functions between L/R and ZL/ZR buttons.
How to switch
TURBO LED will turn off.
Press and hold the ZL and ZR buttons simultaneously and connect the USB connector to
the Nintendo Switch Dock USB port.
TURBO LED (RED) will turn on.
※ Settings will be saved even after you unplug the controller or turn off the power.
※ To reset the button settings, repeat the "How to switch" process.
※ Turning ON the Nintendo Switch while simultaneously pressing the ZL/ZR buttons with the USB connected will switch the button settings.
How to use the Turbo Functions
The Turbo hold function allows continuous rapid ire without having to hold the button.
(Pressing the assigned button deactivates this).
The following buttons can be set to Turbo or Turbo hold mode:
A Button / B Button / X Button / Y Button / L Button / R Button / ZL Button / ZR Button /
Control Pad (UP / DOWN / LEFT / RIGHT)
* Control Pad (UP, DOWN, LEFT or RIGHT) are not compatible with the Turbo hold mode,
and can only be set to Turbo mode.
Turbo Mode
Hold down the Turbo button and
then press the button that you
want to set to Turbo mode.
Turbo Hold
Press the button once more,
and the button will remain
inTurbo (Turbo Hold).
Turbo OFF
OFF
(All buttons)
Hold the TURBO Button and
press the SELECT Button.
* The Turbo LED will flash at a rate corresponding to the Turbo speed. The Turbo LED will flash as long as one of the button is in Turbo mode.
* By pressing the HOME Button, all Turbo function and Turbo hold settings will be deactivated.
When restarting game play, you will need to set the Turbo function again.
* Turbo Function may not be compatible with all software titles. Please try adjusting the Turbo settings or simply turn OFF TURBO.
* Turbo function will deactivate when you unplug the USB connector.
How to change Turbo Speed
You can adjust the Turbo mode to 3 different speeds.
While pressing the Turbo Button, push up on the Right Analog Stick
to change the Turbo speed in the following order :
5 times/second → 10 times/second → 20 times/second
While pressing the Turbo Button, push down on the Right Analog Stick
to change the Turbo speed in the following order :
20 times/second → 10 times/second → 5 times/second
* Turbo speed is set to 10 times/second by default.
* Right Stick must be returned to the neutral position before changing to the next turbo speed.
* The Turbo LED will lash at a rate corresponding to the Turbo speed for 2 seconds.
Main Features
■ External dimensions : (width) 103mm × (depth) 141mm × (height) 69mm
■ Cable length : (Overall length) Approximately 3 m ■ Weight : About 230g
■ Rating : 5V 45mA
This product is not a wireless controller.
This product is not equipped with vibration function.
The image on the packaging may differ from the actual product.
The manufacturer reserves the right to change the product design or speci ications without notice.
Nintendo Switch logo, Nintendo Switch are trademarks of Nintendo.
HORI & HORI logo are registered trademarks of HORI.
Instruction manual
Thank you for purchasing this product.
Controller ： × 1
Control Pad
B Button
TURBO LED
L Button
Control Pad
B Button
TURBO LED
LT Button
Dock.
ZL Button
+
ZL Button
Setting method
+
TURBO Button
+
TURBO Button
+
TURBO Button
Pressing the button again
once more will deactivate
the Turbo function.
+
- Button
TURBO Button
● Do not touch the metal parts of the USB plug with your
finger or other metal material. It may cause injury or defect.
● Do not apply strong impact or weight on the product.
● Do not pull roughly or bend the cable of the controller.
● Never disassemble, repair or modify this product.
● If product needs cleaning, use only a soft dry cloth.
Do not use any chemical agents like benzine or thinner.
● Do not use this product for anything other than its
intended purpose.
We are not responsible for any accidents or damages
in the event of use other than the intended purpose.
Instruction manual ： × 1
Supported OS
System requirements
Capture Button
A Button
+ Button
ZL Button
There is no function
A Button
START Button
LB Button
Connect it to the Nintendo Switch Dock USB port.
L Button
Connect it to the Nintendo Switch Dock USB port.
L Button
Button ON
TURBO LED will lash.
（Green or Orange）
Button ON
TURBO LED will turn on.
（Green or Orange）
※ LED will turn red while L/R and ZL/ZR button
functions are switched.
In the case that after deactivating the turbo
function, the turbo Indicator LED does not
OFF
turn off, this means that there is still a button
set to Turbo/Turbo Hold.
※ LED will turn red while L/R and ZL/ZR button
functions are switched.
If you forget which buttons you have set to
Turbo mode, deactivate them all and reassign,
OFF
as you require.
®
Windows
10 ／ 8 ∼ 8.1 ／ 7
USB Port, Internet Connection
TURBO Button
X Button
USB Connector
R Button
TURBO Button
X Button
USB Connector
RT Button
Turbo LED Status
Button OFF
TURBO LED will turn on.
（Green or Orange）
Button OFF
TURBO LED will lash.
（Green or Orange）
+
+
Target age : 6 years and over
HOME Button
Y Button
ZR Button
GUIDE Button
Y Button
RB Button
R Button
ZR Button
ZR Button
R Button
