CO Alarm
CO Alarm
is a life-safety device that
alarms when it detects carbon
monoxide.
Features
• UL2034 and CSA 6.19-01 listings
• Detects carbon monoxide
• 5 year warranty
Key Instructions
.
1
Review sections 1 and 2 for
information regarding the CO alarm.
2. Determine where to place the CO
alarms per Section 3.
3. Install per Section 4.
Cryptix Enrolment:
4. Enroll the CO alarm into the panel:
• Place panel in enrollment mode
• Press and hold TEST button until you
hear the sounder beep
• The panel will learn the CO alarm
• Press and hold TEST button until
sounder is done sounding beeps
• Panel will indicate a CO Test by
sounding temporal 4 siren one time
Interlogix Compatible Enrollment
• Place panel in enrollment mode
• Press and hold TEST button until
sounder is done sounding beeps
• Panel will learn the CO alarm-
recommended group 34
• Test that the CO alarm is enrolled in
the panel:
• Put panel into test mode
• Press and hold TEST button until
sounder is done sounding beeps
• Panel will indicate a CO sensor has
tripped
This manual should be read prior to use and retained for further information.
Use the Helix installation guide to verify proper system setup.
Attention
Red
Light
Amber
Light
Green
Light
Test
Button
I
Advertisement
Table of Contents
Related Manuals for Resolution RE115
Summary of Contents for Resolution RE115
- Page 1 CO Alarm CO Alarm is a life-safety device that alarms when it detects carbon monoxide. Features • UL2034 and CSA 6.19-01 listings • Detects carbon monoxide • 5 year warranty Key Instructions Review sections 1 and 2 for information regarding the CO alarm. 2.
-
Page 2: Read This First
Honeywell Compatible Enrollment • Panel will learn the CO alarm • Place panel in enrollment mode • Recommended group is 81 • Zone type= Carbon Monoxide • Test that the CO alarm is enrolled in the panel • Input type= Supervised RF Transmitter •... -
Page 3: Carbon Monoxide - The Silent Killer
• Test the alarm weekly by pressing the THE ALARM! test/hush button. The horn will sound at 2.3 Symptoms of CO Poisoning a diminished sound output level initially CO in Symptoms and then quickly reach maximum sound output level. • Replace alarm after approximately 10 The maximum allowable years operation (see ‘replace by’... -
Page 4: Alarm Indicators
OSHA Occupational Safety and Health Association Alarm Indicators Condition Indicator Pre Alarm Red LED flash only CO Alarm Red LED flash + sounder Faults Yellow LED flash + beeps Table B: CO Alarm Response Red Light Horn/ Sounder Level Pre-Alarm (before horn sounds): When 0 - 30 Off (unless the Alarm detects over 50 ppm CO, the... - Page 5 LED will flash in accordance to the CO people sleep, place a CO Alarm in this Response Table. Display models will room show the peak level of CO measured. - Locate a CO Alarm in a room containing Reset Memory: Hold down the test a flueless or open-flued appliance, and - Locate an Alarm in a room where the occupant(s) spend most of their time...
-
Page 6: Installation
• If it is mounted on a wall, it should be Figure 4 located at a height greater than the Location in bedrooms & other rooms height of any door or window but still be remote from the appliance at least 150mm from the ceiling. (at breathing level) •... -
Page 7: Testing And Maintenance
the mounting plate attached. 6. Ensure the RF module is fitted correctly into the base of the Alarm. If necessary it is possible to further secure 7. Remove the battery door and gently or tamper proof the Alarm by using a No.2 pull the battery tab and replace the or No.4 (2 to 3mm diameter - not supplied) battery door. -
Page 8: What To Do When The Alarm Sounds
Maintenance Figure 8 Position Clean the outside case by occasionally wiping with a clean damp cloth. Do not use any cleaning agents, bleaches, detergents or polishes, including those in aerosol cans. Avoid spraying air fresheners, hair spray, paint or other aerosols near the CO Alarm. -
Page 9: How To Protect Your Family
1. Operate reset/ Silence button. these signs are present get the appliance checked out by an expert before further 2. Call your emergency services Fire use. If family members are ill get medical Department or 911. help. 3. Immediately move to fresh air – 2. -
Page 10: Troubleshooting
batteries connected. bottled gas (propane, butane) or other 1. The CO Alarm will not work without combustible gases. Fit combustion Gas good batteries. If the batteries have Alarms to detect these. Note: Carbon been drained, the Alarm will not give Monoxide Alarms with electrochemical protection. - Page 11 chemical cleaners, aerosol sprays, damp proofing done with an aqueous emulsion such as Aminofunctional Siloxane, and Alkylalkoxysilane. 3. Ensure there is no outdoor source of CO in the vicinity such as a car with the engine running, heavy traffic, or heavy air pollution.
-
Page 12: Specifications
Changes or modifications not expressly approved Le présent appareil est conforme aux cnr d’Industrie by Resolution Products, Inc. could void the user’s Canada applicables aux appareils radio exempts de authority to operate this equipment. licence. L’exploitation est autorisée aux deux conditions...
