VA200X Operations Guide
This manual outlines the operating procedures for all VA200X series products
NOTE: Depending on the installation mode, the VA200 instrument will have one of
1. Power Up / Default Screen – Ammeter Mode
Displays the voltmeter and ammeter information. Colors are determined by the
range values as set during installation.
Press the top button once to move to the next display screen (#3).
Ammeter mode, charge current
2. Power Up / Default Screen – Loadmeter Mode
Displays the voltmeter and loadmeter (alternator output) information. Colors are
determined by the range values as set during installation.
Press the top button once to move to the next display screen.
Loadmeter mode, alternator output
two possible default displays.
Aerospace Logic Inc.
Tel. 416-628-0725
www.aerospacelogic.com
Ammeter mode, discharge current
Loadmeter mode, alternator fault
Document # S200-VA200X-005
Rev 1.3 02/28/2017
Page 1 of 2
