Page 1: User Manual
Two Way15" Full Range Passive Speaker THUNDER Series Pro Loudspeaker System User Manual UM-T15-20120905 ver B... - Page 2 SAFETY INSTRUCTIONS PLEASE READ THIS MANUAL FIRST Thank you for a buyin product. Read this manual first as it will help you operate the system properly. Please keep this manual for future reference. WARNING: This product must be installed by professionals. When using hanging brackets or rigging other than those supplied with the product, please ensure they comply with the local safety codes.
-
Page 3: Table Of Contents
CONTENT THUNDER Series Pro Loudspeaker System CONTENT INTRODUCTION Features Description Applications CONNECTION 2 NL4 NL4 Connection System Connection Reference INSTALLATION Mounting Accessories Installation Reference TECHNICAL SPECIFICATION Technical Sheet Frequency Response and Impedance Curve 2D Dimension Product information is subject to change without prior notification. -
Page 4: Introduction
35mm SMART pole mount for vertical and 5downwardti lt. Integrated feet for stage monitor applications. M8 rigging points for convenient installation. Description T15 Thunder series is designed for portable and installed Applications applications. The integrated polymer PVC cabinet design ensures durability and full natural high performance sound. -
Page 5: Connection
CONNECTION THUNDER Series Pro Loudspeaker System Two NL4 connectors are located on the rear panel for power amplifier connection and parallel connection to another speaker. 2 NL4 Crossover HIGH NL4 Connection 1. Connect 2. Disconnect System Connection Reference BRIDGEI N... -
Page 6: Installation
INSTALLATION THUNDER Series Pro Loudspeaker System Installation Accessories(Optional) Installation Reference 1. Speaker stand 1.Reference A 2.Reference B 3.Reference C 4.Reference D 2. U-Bracket Speaker stand application Warning: Make sure the mounting accessories safety factor not less than 5:1 or meet the local standard during... -
Page 7: Technical Specification
TECHNICAL SPECIFICATION THUNDER Series Pro Loudspeaker System Technical Specification Speaker Testing Method System: 1. Frequency Response Two Way15" Full Range Passive Speaker Use Pink noise to test the speaker in the anechoic chamber, System components: 1 15 " 1 1.7 "... -
Page 8: Dimension
TECHNICAL SPECIFICATION THUNDER Series Pro Loudspeaker System 2D Dimension Top view 462mm [18.2in] Front view Back view Side view Bottom view... - Page 9 Notes:...
