Stepp SPHD series Operation, Maintenance And Parts Manual

Diesel burner systems dump style premix heater
Hide thumbs
Table of Contents

Advertisement

Quick Links

Rev. 12/2014
Operations/MAINTENANCE/PARTS
MANUAL
12325 River Road North Branch MN 55056 ~ Phone: 651-674-4491 ~ Fax: 651-674-4221
www.steppmfg.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPHD series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Stepp SPHD series

Summary of Contents for Stepp SPHD series

  • Page 1 Rev. 12/2014 OPERATIONS/MAINTENANCE/PARTS MANUAL Diesel Burner Systems 12325 River Road North Branch MN 55056 ~ Phone: 651-674-4491 ~ Fax: 651-674-4221 www.steppmfg.com...
  • Page 2 (1) year from the date of purchase. Stepp Mfg., at its discretion, will provide for the repair or replacement of any part found upon examination by Stepp Mfg. to be defective, except as noted below. Such repair or re- placement will be free of charge to the original purchaser for a period of one (1) year from the date of purchase, except as noted below.

  • Page 3: Introduction

    In addition, the operator must re- ceive instruction from their supervisor, or the manufacturer, on how to safely operate the Stepp Hot Pack Dump Style Trailer. Contact the manufacture if any questions arise or if you desire training for additional staff members.

  • Page 4: Table Of Contents

    This manual explains the basic operations, maintenance and use of the Stepp SPHD Premix Heater. The main objective of this equipment is to maintain heat in patching ma-...
  • Page 5 Before Starting or Operating this Machine Understand and observe all the following Warnings, Cautions, and Notes. WARNINGS This equipment contains mechanical and heating components that may cause serious injury or death if not  handled or maintained properly. All personnel must be properly trained in the operation and maintenance of this equipment.
  • Page 8 OPERATIONS Loading Loading Main Hopper WARNING: Hydraulic equipment can crush any object with tremendous force, causing injury or death. Keep yourself and all other persons clear when raising and lowering hopper. Hydraulically Operated Doors 1. Shut OFF the heating system. 2.
  • Page 9 OPERATIONS Dumping Hydraulic Dump WARNING: Hydraulic equipment can crush any object with tremendous force causing injury or death. Keep yourself and all other persons clear when operating hydraulic equipment. 1. Find the magnet remote mounted toward rear curbside of unit. 2.
  • Page 10 OPERATIONS Diesel Burner w/ Thermostat NOTE: This system incorporates a 12 volt burner and blower assembly and burns #2 diesel fuel. A 12 volt battery and charging circuit supply power to the burner, blower motor, and ther- mostat. The charging circuit may consist of an engine driven alternator mounted on the unit, or a hook-up to the tow vehicles charging system.

  • Page 11: Contents

    OPERATIONS Diesel Burner Tack Tank (optional) An optional tack tank is available to pre-heat the tack oil used to obtain better repairs. The tack tank incorporates its own heating system similar to the systems used to heat the Pre-Mix Heater. Burner operating instructions for the tack tank are included with the burner instruc- tions for the Pre-Mix Heater main hopper on the previous pages.

  • Page 12: Operations

    OPERATIONS Tack Tank & Pumping System CONT. 1. System Flush. (optional) Flushing solvent is pumped through the pump and wand to clean material from the system. WARNING: Do not allow flushing solvent to contaminate the contents of the tack tank. a.
  • Page 13 OPERATIONS Overnight Heat/Washdown Overnight Heaters (optional) The overnight heaters are designed to pre-heat, or maintain the temperature of the heat transfer oil up to the capacity of the heating elements. This will decrease the amount of time necessary to bring the materials up to the recommended application temperatures. The burner is automatically disconnected from the system and the electric heating elements are activated when the power cord is plugged in.

  • Page 16: Maintenance

    PRE-MIX HEATER MAINTENANCE SCHEDULE ITEM OPERATION TO PERFORM DAILY EVERY EVERY EVERY EVERY EVERY WEEK MONTH YEAR Burner Diffuser Inspect burner diffuser for damage and deterioration. Burner Diffuser Replace burner diffuser. Refer to parts list for P/N Burner Fuel Replace fuel nozzle. Refer to parts Nozzle section for P/N Door Hinges...
  • Page 17 PRE-MIX HEATER MAINTENANCE RECORD DATE MAINTENANCE PERFORMED HOUR METER SERVICED BY All maintenance items must be performed according to the maintenance schedules All maintenance items must be performed according to the maintenance schedules and documented for warranty coverage to be effective. and documented for warranty coverage to be effective.

  • Page 20: Troubleshooting

    Test the Primary control- condition, turn main power ler function, replace if Check the photo switch “off” then “on” again to faulty. Contact Stepp electric eye for a reset the system. Mfg. if this does not cor- dirty lens and prop- Check to see if : rect problem.
  • Page 21 Diesel Burner Adjustments 1. Bleed all air from fuel system through bleeder screw. electrode 5/32” See Fig. 4 (burner motor must be running). 2. Check and adjust igniter electrodes as shown in Fig. 1. 3. Verify dimensional adjustments. The “Z” in dimen- nozzle sion is set to 1 1/8’...
  • Page 22 TROUBLE SHOOTING Diesel Burner Component Primary Controller Burner MTD/Hard Wired NOTE: The primary controller can be bench tested for proper operation us- ing an automotive type, 12 volt battery as a power source. Refer to the wir- ing schematics for wire identification. 1.
  • Page 23 TROUBLE SHOOTING Diesel Burner Photo Electric Eye NOTE: The Photo Electric Eye can be bench tested for proper oper- ation using an ohm meter. Assure the lens of the Photo Electric Eye is clean prior to testing. 1. Block off all light to the Photo Electric Eye. Test across the leads with your ohm meter;...

  • Page 26: Replacement Parts

    REPLACEMENT PARTS 2.0 Hopper Assembly...
  • Page 27 REPLACEMENT PARTS 2.0 Hopper Assembly...
  • Page 28 REPLACEMENT PARTS 2.0 Hopper Assembly...
  • Page 29 REPLACEMENT PARTS 2.0 Hopper Assembly...
  • Page 30 REPLACEMENT PARTS 3.0 Hopper Assembly...
  • Page 31 REPLACEMENT PARTS 3.0 Hopper Assembly...
  • Page 32 REPLACEMENT PARTS 3.0 Hopper Assembly...
  • Page 33 REPLACEMENT PARTS 3.0 Hopper Assembly...
  • Page 34 REPLACEMENT PARTS 2.0 Hopper Assembly w/ Hyd. Doors...
  • Page 35 REPLACEMENT PARTS 2.0 Hopper Assembly w/ Hyd. Doors...
  • Page 36 REPLACEMENT PARTS 2.0 Hopper Assembly w/ Hyd. Doors...
  • Page 37 REPLACEMENT PARTS 2.0 Hopper Assembly w/ Hyd. Doors...
  • Page 38 REPLACEMENT PARTS 3.0 Hopper Assembly w/ Hyd. Doors...
  • Page 39 REPLACEMENT PARTS 3.0 Hopper Assembly w/ Hyd. Doors...
  • Page 40 REPLACEMENT PARTS 3.0 Hopper Assembly w/ Hyd. Doors...
  • Page 41 REPLACEMENT PARTS 3.0 Hopper Assembly w/ Hyd. Doors...
  • Page 42 REPLACEMENT PARTS Hydraulic Door– Curb Side...
  • Page 43 REPLACEMENT PARTS Hydraulic Door– Street Side...
  • Page 44 REPLACEMENT PARTS Discharge Door Cylinder Mount...
  • Page 45 REPLACEMENT PARTS Shovel Platform...
  • Page 46 REPLACEMENT PARTS 2.0 Trailer Assembly w/ Electric Brakes...
  • Page 47 REPLACEMENT PARTS 2.0 Trailer Assembly w/ Electric Brakes...
  • Page 48 REPLACEMENT PARTS 3.0 Trailer Assembly w/ Electric Brakes...
  • Page 49 REPLACEMENT PARTS 3.0 Trailer Assembly w/ Electric Brakes...
  • Page 50 REPLACEMENT PARTS 2.0 Trailer Assembly w/ Hydraulic Brakes...
  • Page 51 REPLACEMENT PARTS 2.0 Trailer Assembly w/ Hydraulic Brakes...
  • Page 52 REPLACEMENT PARTS 2.0 Hitch w/ Hydraulic Brakes...
  • Page 53 REPLACEMENT PARTS 3.0 Trailer Assembly w/ Hydraulic Brakes...
  • Page 54 REPLACEMENT PARTS 3.0 Trailer Assembly w/ Hydraulic Brakes...
  • Page 55 REPLACEMENT PARTS 3.0 Hitch w/ Hydraulic Brakes...
  • Page 56 REPLACEMENT PARTS Pintle Hitch...
  • Page 57 REPLACEMENT PARTS Ball Hitch...
  • Page 58 REPLACEMENT PARTS Tow Connector– 7RV...
  • Page 59 REPLACEMENT PARTS Tow Connector– 7 Round...
  • Page 60 REPLACEMENT PARTS Tow Connector– 6 Round...
  • Page 61 REPLACEMENT PARTS Light Package– Incandescent...
  • Page 62 REPLACEMENT PARTS Light Package– LED...
  • Page 63 REPLACEMENT PARTS 4 Light System...
  • Page 64 REPLACEMENT PARTS 4 Light System...
  • Page 65 REPLACEMENT PARTS 4 Light System...
  • Page 66 REPLACEMENT PARTS Diesel Burner...
  • Page 67 REPLACEMENT PARTS Burner Rain Cover...
  • Page 68 REPLACEMENT PARTS Burner Rain Cover...
  • Page 69 REPLACEMENT PARTS Burner Rain Cover...
  • Page 70 REPLACEMENT PARTS Burner Enclosure...
  • Page 71 REPLACEMENT PARTS Fuel Tank and Filter...
  • Page 72 REPLACEMENT PARTS Battery Box w/ Charger...
  • Page 73 REPLACEMENT PARTS Battery Box w/ Charger...
  • Page 74 REPLACEMENT PARTS Control Box...
  • Page 75 REPLACEMENT PARTS Control Box...
  • Page 76 REPLACEMENT PARTS Recessed Strobe Light– Street Side...
  • Page 77 REPLACEMENT PARTS Recessed Strobe Light– Curb Side...
  • Page 78 REPLACEMENT PARTS Beacon Style Strobe Light...
  • Page 79 REPLACEMENT PARTS Arrowboard...
  • Page 80 REPLACEMENT PARTS Tack Tank...
  • Page 81 REPLACEMENT PARTS Pumping System for Tack Tank...
  • Page 82 REPLACEMENT PARTS Pumping System for Tack Tank...
  • Page 83 REPLACEMENT PARTS Spray Wand for Pumping System...
  • Page 84 REPLACEMENT PARTS Washdown Assembly w/ Hose Reel...
  • Page 85 REPLACEMENT PARTS Washdown Kit...
  • Page 86 REPLACEMENT PARTS Catwalk...
  • Page 87 REPLACEMENT PARTS Catwalk...
  • Page 88 REPLACEMENT PARTS Shovel Shelf...
  • Page 89 REPLACEMENT PARTS Shovel Shelf...
  • Page 90 REPLACEMENT PARTS Shovel Shelf...
  • Page 91 REPLACEMENT PARTS Spare Tire Carrier...
  • Page 92 REPLACEMENT PARTS Compactor Plate Carrier...
  • Page 93 REPLACEMENT PARTS Shovel Cleaning Compartment...
  • Page 94 REPLACEMENT PARTS Tool Box...
  • Page 95 REPLACEMENT PARTS Water Tank...
  • Page 96 REPLACEMENT PARTS Water Tank Fender Mount...
  • Page 97 REPLACEMENT PARTS Water Tank Fender Mount...
  • Page 98 REPLACEMENT PARTS Water Tank Fender Mount...
  • Page 99 REPLACEMENT PARTS Engine Control Package...
  • Page 102 REPLACEMENT PARTS Diesel Burner ITEM DESCRIPTION PART# Burner, fuel oil, Beckett Mod ADC W/CON 5-02 A10008215 Air Tube 509070 Photo electric eye (under ignition transformer) A10007678 Valve, fuel control 509091 Ignition Transformer 509087 Primary Controller A10008216 Motor, fan and pump 509092 Coupling, pump to motor 509086...
  • Page 103 REPLACEMENT PARTS Controls ITEM DESCRIPTION PART# Thermostat, Watlow 0-550°, (12volt) P10003540 Sensor, RTD Watlow 0-550°, (12volt) A10001017 Switch– SPST Toggle ON/OFF P10000180 Light– Call For Heat 12V P10000181 Volt Meter P10000184 20 Amp Breaker P10000179 ** Not Shown ITEM DESCRIPTION PART # Light 2.5”...
  • Page 104 If you believe that your vehicle has a defect in which could cause a crash or could cause injury or death, you should imme- diately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying STEPP MANUFAC- TURING CO., INC..
  • Page 105 Consumer Warranty Guide 12325 River Road, North Branch, MN 55056~ Phone: 651-674-4491~ Fax: 651-674-4221 www.steppmfg.com...
  • Page 106 If you do not have the facilities, or the technicians, to perform the repair, the unit can be brought to a local repair facility. In either case, Stepp Manufacturing MUST be contacted and authorize the warranty repair PRI- OR to any work being performed.
  • Page 107 Stepp Manufacturing Co., Inc. hereby warrants, to the original purchaser of new equipment, that products manufactured by Stepp Manufacturing will be free from defects in material and workmanship for a period of one (1) year from the date of purchase from Stepp Manufacturing.
  • Page 108 The pro-rated adjustment is based on the total number of months elapsed since the purchase date of the new equipment from Stepp Manufacturing. This rate is then applied to the one-half (0.5) hour labor rate and the current suggested retail price of the proper replacement heated asphalt hose or heating element supplied by Stepp Manufacturing.
  • Page 109 All parts returned must be tagged with the warranty authorization number and a copy of this claim. Retain all parts until credit is received from the factory. When requested, return the parts, along with this claim, to: Stepp Manufacturing Co., Inc. Attn: Warranty Department...
  • Page 112 Watlow 12v Series PM Temperature Controller Operators Programming Sequence for 12 volt devices. PN EZ-ZONE– P1003540 This programming sequence is taken from the manufacturers programming manual for this con- troller and reduced to eliminate the non-essential entries. Please follow the entries carefully and if any questions arise because of misunderstanding the instructions, see your supervisor or call the factory for clarification.
  • Page 113 Watlow Series PM-12 volt controller Sample Display Illustrations This display shows a typical temperature selection by the operator.  Upper display shows actual product temperature in red color.  Lower display shows operator desired maximum temp setting in green col- ...
  • Page 114 Watlow Series PM-12volt Temperature Controller Operators Programming Sequence for 12 volt devices This programming sequence is taken from the manufacturers programming manual for this controller and con- densed to eliminate the non-essential entries for ease of setup. Please follow the entries carefully and if any questions arise because of misunderstanding the instructions, please call the manufacturer for clarification.
  • Page 115 Watlow Series PM-12volt Temperature Controller Operators Programming Sequence for 12 volt devices Home Menu: Procedure for programming the Series PM-12 volt Watlow Control. Step 1: Connect all wires to Watlow control including RTD (temp sensor). Step 2: Connect power to Watlow controller. Step 3: Enter the Setup menu.
  • Page 116 Step 7: Press either the up or down key to select the Loop submenu. LOOP will be in the upper display and SEt will be in the lower display. If this is shown, press the advance key to enter the Loop submenu.
  • Page 117 Step 11: Use the up or down keys to select the global submenu gLbL will be in the upper dis play and SEt will be in the lower display. Press the advance key to enter the global menu. Parameter Value Description 11-1 display units...
  • Page 118 Parameter Value Description 18-3 id.5 75 degree F. Idle set point Advance key 18-4 h.hy 3.0 degree F. Heat hysteresis Advance key reads 3 on display 18-5 o.SP 0.0% Open loop set point Advance key Step 19: Pressing the advance key at parameter o.SP will advance you back to parameter C.r7 Press the infinity key...
  • Page 119 Step 28: Repeat steps 26 and 27 for display values of 4 through 2, changing each parameter to nonE. Note: The upper display will show the previous value you changed. You must increment this value from 4 through 20! Step 29: When all 20 parameters are set, press the infinity key once to return you to the main...
