Stepp SRM Operation, Maintenance And Parts Manual

Diesel burner systems mobile asphalt recycler
Hide thumbs

Advertisement

Quick Links

Download this manual
Rev. 12/2014
OPERATIONS/MAINTENANCE/PARTS
MANUAL
Diesel Burner Systems
12325 River Road North Branch MN 55056 ~ Phone: 651-674-4491 ~ Fax: 651-674-4221
www.steppmfg.com
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the SRM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Stepp SRM

Summary of Contents for Stepp SRM

  • Page 1 Rev. 12/2014 OPERATIONS/MAINTENANCE/PARTS MANUAL Diesel Burner Systems 12325 River Road North Branch MN 55056 ~ Phone: 651-674-4491 ~ Fax: 651-674-4221 www.steppmfg.com...

  • Page 2: Www.steppmfg.com

    (1) year from the date of purchase. Stepp Mfg., at its discretion, will provide for the repair or replacement of any part found upon examination by Stepp Mfg. to be defective, except as noted below. Such repair or re- placement will be free of charge to the original purchaser for a period of one (1) year from the date of purchase, except as noted below.

  • Page 3: Introduction

    SRM Recycler Thank you for selecting Stepp highway maintenance equipment. We are confi- dent you will be satisfied with the Stepp Recycler Mixer. Stepp Manufacturing is backed by over 70 years of experience in the design and manufacture of high- way maintenance equipment.
  • Page 4 Dimensions (approx.) Length.………………………………………………………………...……...……234 in. Width…………………………………..………………...……………………..…...99 in. Height……………………………………………………………..…….Operating 116 in. Weight…………………………………………………..…………………...…..5,350 lbs. General Fuel Tank Capacity……………………..……………………………..……... 60 Gallons Preheat Hopper Capacity……………………………………………………………………….….10 cu.ft. Opening Dimensions…………………………………………………………. …23"x 38" Loading Conveyor Belt………………………………………………………...…………... 16" Wide Cleated Hydraulic Motor…………………….….4.0 cu.in. Hydraulic Motor w\ Forward-Reverse Mixing Chamber Chamber Type………………………………...………………..Continuous Batch Mixing Mixing Style…………………………………..………………………..
  • Page 5 Kettle Pumping System Pump Model……………………………………………………………….Viking HL32® Relief Valve ………………………………………………………...…….…. WPC Valve GPM Output Rating……………………………………………………………….20 gpm Pump Mounting……………………….………………………………..……...Submerged Pump Drive……………….…..Hydraulic, Reversible, Variable Speed with PLC Display Engine Manufacture………………………………..………………………………...…. Kubota® Model…………………………………..……………………..……………….. V1505EB Displacement…………………………..……………………...…………….81 cubic inch Number of Cylinders…..…………………………………………………………...…..(4) Horse Power…………………………..………………..…………………………35.1 HP Fuel Type……………………………….……………..…………………………….Diesel Cooling………………………………...……………….…………………………..Liquid Hydraulic System System Type………………………………………...…..Eaton 7000 Series Load Sensing...
  • Page 6 TABLE OF CONTENTS Introduction Warnings, Cautions, Notes Operations Maintenance Trouble Shooting Replacement Parts Warranty Guide Schematics Hydraulic Oil MSDS Tire Information Insert Engine Manual Insert IMPORTANT NOTICE! This manual contains cautions and warnings that alert you to potential safety issues. WARNING is used to inform you of conditions or operations that could cause serious injury or death.
  • Page 7 Before Starting or Operating this Machine Understand and observe all the following Warnings, Cautions, and Notes. WARNINGS This equipment contains mechanical and heating components that may cause serious injury or death if not  handled or maintained properly. All personnel must be properly trained in the operation and maintenance of this equipment.

  • Page 10: Operations

    OPERATIONS Basic Operation WARNING: Before refueling, shut off the burners and the engine. CAUTION: Be sure operators have been properly instructed in starting and op- erating all equipment before beginning. NOTE: See following pages for specific instructions on operating burners and heating systems.
  • Page 11 OPERATIONS Basic Operation 1. Start engine (refer to engine operations). 2. Turn on control box power switch. 3. Load bituminous/asphalt material into kettle using the safety loading chute. Make sure no moisture is present in tank. Be sure to wear proper protective clothing. Flues must be completely covered with 4”...
  • Page 12 OPERATIONS Basic Operation 12. If necessary, add heated bituminous binding material to the recycler mixing chamber (refer to the plumbing operations chart). Here again, experience is the best indicator of how much to add. Start with gallons of oil. Know the material being added and the flash point. We recommend that you use an AC type oil and add the oil in the first three minutes of the batch timer.
  • Page 13 (solvent) in the oil. This makes the material soft and pliable, but also makes them very easy to catch on fire. If you are using the SRM to heat cold patch material, only fire the burner in 1-2 minute cycles and check the temperature very often to prevent the material...
  • Page 14 OPERATIONS Kettle Heating System WARNING: The burners must be shut off when the product reaches a level approximately 4" above the flues. Exposed flues will overheat causing an explosion in the tank. This will cause equipment damage and possible injury or death to personnel. Before Igniting the Burner: 1.
  • Page 15 Igniting the Burner: 1. The SRM recycler chamber has two set point temperatures. One “higher firing” set point for heating up the mix, and one “stand-by” temperature setting that keeps the liner and materials at a given temperature. Pressing the “Cycle Start” button changes the max set point to the “higher firing”...
  • Page 16 OPERATIONS PLC Controller Recycler Chamber: Shows temperature of Tack Oil: Shows SP (set point) and actual temperature of oil kettle. the recycler/mixing chamber. Does not show indicated material temperature. Tack Oil SP Cycle Start: (set point) Resets the Temperature batch timer. Adjustment Burner Tim- er Adjust-...
  • Page 17 Be sure all pre-start checks are complete prior to starting engine. The SRM is equipped with a digital engine management system. This system will shut the en- gine down in case of an engine overheat or low oil pressure. It is also equipped with an hour meter, cold weather glow plug button, and a starting button.
  • Page 18 OPERATIONS Pumping System WARNING: DO NOT allow flushing solvent to enter hot oil tank or mixer. DO NOT allow the hot oil tank burner to operate with the product level less than 2 inches above the flues. Severe damage to equipment and possible serious injury will result! DO NOT flush through a heated wand.
  • Page 19 OPERATIONS Pumping System...
  • Page 20 OPERATIONS WPC Valve Hand Wand Wand Pressure Control Valve (WPC Valve) Operators must understand the proper operation of the WPC valve located on the top rear of the unit. The purpose of this valve is to direct the flow of product either back to the tank (during start-up to assist melting) or to the wand (during crack filling or pothole spraying oper- ations).
  • Page 21 OPERATIONS Heated Hose Heated Hose & Wand (optional) The application hose and wand are equipped with internal heating elements. The elements are powered by the 24 volt alternator run by the engine. This heating element prevents the product from freezing in the hose and wand. The electric wand heat control should be turned on 20 to 30 minutes before trying to pump material through the hose and wand.
  • Page 22 OPERATIONS Wand Application with Twist-Valve Wand 1. Position the WPC valve midway between the wand and recirculate position. 2. Close the wand flow control valve (located on the wand handle) and remove wand from the recirculating flange. 3. Set product pump to "Pump" position, then open the wand flow control valve to apply prod- uct to the road surface.
  • Page 23 Pumping System WARNING: The Stepp SRM requires special shut down procedures that must be followed to maximize safety and equipment performance. The procedures will assure that the hose and wand always have product in them to avoid an over-heated element. (Do Not suck the prod- uct back out of the wand and hose assembly) No hose cleanup is necessary as the product in the hose is re-melted at the next start up with the wand and hose heating element.
  • Page 24 Pumping System Standard Shut Down Procedures for Units With Non-Heated Hose WARNING: The Stepp SRM requires special shut down procedures that must be followed to maximize safety and equipment performance. CAUTION: Set pump to OFF or neutral before adjusting valves.
  • Page 25 OPERATIONS Helpful Hints 1. It is recommended that the product be drawn down to capacity or less prior to shutdown. This will decrease the start up time the next time the machine is used. How- ever if you are certain the equipment will be used the next day (no chance of rain, etc.), leave the unit about ½...

  • Page 28: Maintenance

    MAINTENANCE Product Pump Fig. 1 The pump used for hot oil pumping is a gear type pump. Shaft rotation will determine which port is suction and which is discharge. A look at the Fig.1 will show how the fluid will flow through the pump.
  • Page 29 MAINTENANCE Hot Asphalt Hose Replacement CAUTION: Do not remove hose without first removing the heating element or damage to heating element will result. Hose Removal: 1. Remove heating element from hose (refer to heating element removal procedures). 2. Disconnect all electrical connections from hose. 3.
  • Page 30 MAINTENANCE Hose Heating Element Replacement (Functioning Element) Hose Heating Element Removal: These instructions assume the heating element is functioning properly. If the heating element does not function, refer to the instructions on the following pages. NOTE: If the hose is damaged, skip steps 1 through 3, activate wand heat for 15 minutes, then begin at step 4.
  • Page 31 MAINTENANCE Hose Heating Element Replacement (Functioning Element) Hose Heating Element Installation: 1. Remove wand from hose at quick coupling. 2. Lay the hose out as straight as possible. 3. Install new compression fitting into cross fitting. NOTE: If hose DOES NOT contain material proceed with step 4. If hose CONTAINS material, replace step 4 with steps A &...
  • Page 32 MAINTENANCE Hose Heating Element Replacement (Non-Functioning Element) Hose Heating Element Removal and Installation: These instructions assume the heating element is damaged and NOT functioning. If the heat- ing element functions properly, refer to the instructions on the previous page. The element may be damaged during removal, rendering it useless.
  • Page 33 MAINTENANCE Wand & Boom Heating Element Replacement Wand or Boom Heating Element Removal and Installation: These instructions assume the heating element is damaged and not functioning. The element may be damaged during removal rendering it useless. A functioning heating element is slid into the wand or boom along side the non-functioning element.
  • Page 34 MAINTENANCE Pugmill Mixer The SRM has many high torque moving parts. As a weekly inspection, we suggest that the operators check for loose fittings and loose bolts. Outlined below are some that need to be checked periodically due to the torque and vibration that the unit incurs.
  • Page 35 MAINTENANCE Conveyor The conveyor needs to be inspected daily for wear, and to make sure that the belt is tracking properly. As the belts are used, they will stretch, requiring tightening. 1. Check grease bearings daily (#1). 2. Check belt tension and tracking (#2). To adjust tracking, you must first loosen the 4 nuts on the bearing.

  • Page 38: Trouble Shooting

    TROUBLE SHOOTING Hydraulic System POSSIBLE CAUSE Items to Check /Service Plugged Strainer Screen Service strainer screen LACK OF PERFORMANCE Hydraulic Filter Plugged Replace hydraulic oil filter Collapsed Suction Hose Replace suction hose and service strainer screen Air Leak in Suction Hose Replace hose Low Fluid Level Fill reservoir to proper level...
  • Page 39 TROUBLE SHOOTING Product Delivery POSSIBLE CAUSE Items to Check /Service PRODUCT PUMP Product in Tank not Melted Allow more time for product to melt DOES NOT TURN Foreign Material Jamming Product Remove foreign material Pump from product pump Pump Motor not Functioning Refer to “Hydraulic System”...
  • Page 40 TROUBLE SHOOTING Product Pump Lack of flow from wand. Check for rotation No Rotation Engage pump control Refer to hydraulic Little or no of product pump. and observe engine system trouble change in RPM. Shooting. Rotation Definite RPM drop Check that the pump control is in Check that the product CAUTION:...
  • Page 41 TROUBLE SHOOTING Electric Wand No heat, or low heat in wand or hose. With engine OFF, Check for loose pulleys and loose or missing belts on 24 volt alternator. Check for a dead battery, then check for an open resister or open wires Start engine, with wand 9 volts or less from battery to alternator, or a short-...
  • Page 42 Test the Primary control- condition, turn main power ler function, replace if switch “off” then “on” again to Check the photo faulty. Contact Stepp reset the system. electric eye for a Mfg. if this does not cor- Check to see if : dirty lens and prop- rect problem.
  • Page 43 TROUBLE SHOOTING Diesel Burner Component Primary Controller Burner MTD/Hard Wired NOTE: The primary controller can be bench tested for proper operation us- ing an automotive type, 12 volt battery as a power source. Refer to the wir- ing schematics for wire identification. 1.
  • Page 44 TROUBLE SHOOTING Diesel Burner Photo Electric Eye NOTE: The Photo Electric Eye can be bench tested for proper oper- ation using an ohm meter. Assure the lens of the Photo Electric Eye is clean prior to testing. 1. Block off all light to the Photo Electric Eye. Test across the leads with your ohm meter;...

  • Page 46: Replacement Parts

    REPLACEMENT PARTS SRM Recycler...
  • Page 47 REPLACEMENT PARTS Pugmill & Mixing Chamber...
  • Page 48 REPLACEMENT PARTS Pugmill & Mixing Chamber...
  • Page 49 REPLACEMENT PARTS Pugmill & Mixing Chamber...
  • Page 50 REPLACEMENT PARTS Pugmill & Mixing Chamber...
  • Page 51 REPLACEMENT PARTS Pugmill & Mixing Chamber...
  • Page 52 REPLACEMENT PARTS Pugmill & Mixing Chamber...
  • Page 53 REPLACEMENT PARTS Pugmill & Mixing Chamber...
  • Page 54 REPLACEMENT PARTS Pugmill & Mixing Chamber...
  • Page 55 REPLACEMENT PARTS Pugmill & Mixing Chamber...
  • Page 56 REPLACEMENT PARTS Pugmill & Mixing Chamber...
  • Page 57 REPLACEMENT PARTS Pugmill & Mixing Chamber...
  • Page 58 REPLACEMENT PARTS Pugmill & Mixing Chamber...
  • Page 59 REPLACEMENT PARTS Pugmill & Mixing Chamber...
  • Page 60 REPLACEMENT PARTS Pugmill & Mixing Chamber...
  • Page 61 REPLACEMENT PARTS Pugmill & Mixing Chamber...
  • Page 62 REPLACEMENT PARTS Oil Kettle and Pumping System...
  • Page 63 REPLACEMENT PARTS Oil Kettle and Pumping System...
  • Page 64 REPLACEMENT PARTS Oil Kettle and Pumping System...
  • Page 65 REPLACEMENT PARTS Oil Kettle and Pumping System...
  • Page 66 REPLACEMENT PARTS Heated and Non-Heated Overhead Boom...
  • Page 67 REPLACEMENT PARTS Heated Spray Wand...
  • Page 68 REPLACEMENT PARTS Heated Hose...
  • Page 69 REPLACEMENT PARTS Non-Heated Spray Wand...
  • Page 70 REPLACEMENT PARTS Conveyor...
  • Page 71 REPLACEMENT PARTS Conveyor...
  • Page 72 REPLACEMENT PARTS Trailer With Electric Brakes...
  • Page 73 REPLACEMENT PARTS Trailer With Hydraulic Brakes...
  • Page 74 REPLACEMENT PARTS Trailer...
  • Page 75 REPLACEMENT PARTS Trailer...
  • Page 76 REPLACEMENT PARTS Engine...
  • Page 77 REPLACEMENT PARTS Engine...
  • Page 78 REPLACEMENT PARTS Hydraulics...
  • Page 79 REPLACEMENT PARTS Hydraulics...
  • Page 80 REPLACEMENT PARTS Controls...
  • Page 81 REPLACEMENT PARTS Controls...
  • Page 82 REPLACEMENT PARTS Controls...
  • Page 83 REPLACEMENT PARTS Controls...
  • Page 84 REPLACEMENT PARTS Compactor Plate Carrier...
  • Page 85 REPLACEMENT PARTS Washdown...
  • Page 86 REPLACEMENT PARTS Fuel Filter...
  • Page 87 REPLACEMENT PARTS Burner Liner...
  • Page 88 REPLACEMENT PARTS Diesel Burner ITEM DESCRIPTION PART# Burner, fuel oil, Beckett Assembly A10008105-011 Air Tube 509070 Photo electric eye w/connectors (under ignition transformer) A10007678 Valve, fuel control 509091 Ignition Transformer 509087 Primary Controller A10008216 Motor, fan and pump 509092 Coupling, pump to motor 509086 Pump, burner fuel 509094...
  • Page 89 REPLACEMENT PARTS 8’/12’ Heated Hose ITEM DESCRIPTION PART # 8' Hose Assembly with heating element ..............523089 12' Hose Assembly with heating element ......................523093 Compression Fitting 3/8" ..................M10009910 8' Heating element, for hose, includes **connector ..........A10009933 12' Heating element, for hose, includes **connector ..........A10009934 8' Hose Assembly, less heating element ...............
  • Page 90 REPLACEMENT PARTS Ortec Hose ITEM DESCRIPTION PART # Hose, yellow ortec, 1/2" x 20 ft. (with fittings)………………………………523055 Hose, yellow ortec, 1/2" x 25 ft. (with fittings)………………………………523006 Hose, yellow ortec, 1/2" x 40 ft. (with fittings)………………………………523021 Hose, yellow ortec, 1/2" bulk per foot (no fittings)…………………………. P10007809 Hose, yellow ortec, 3/4"...
  • Page 91 REPLACEMENT PARTS HL-32 Pump ITEM DESCRIPTION PART# Pump, complete with relief valve ..............515006 Pump, complete without relief valve, with steel rotor .... 515063 (OJK-50, 75, 120) Pump, complete without relief valve, with standard rotor ......515005 Packing seal, shaft ................... 515019 Bushing, bracket .....................
  • Page 92 REPLACEMENT PARTS Spray Nozzles For Spray Bars and Spray Wands ITEM DESCRIPTION PART # Nozzle, Duckbill, 2½" Elkhart #184..............P-160 V-Jet Nozzle, H¼VV9508 ............P10002943 (for spray wands) V-Jet Nozzle, H¼U4070 ............520088 (for spray bars) V-Jet Nozzle, H¼U6515 ............P10002944 (for spray bars) V-Jet Nozzle, H¼U6520 ............
  • Page 93 REPLACEMENT PARTS Burner Filters For Diesel Burner and LP Systems ITEM DESCRIPTION PART # Fuel Filter Element, Diesel Burner (includes gaskets) ........509078 LP Fuel Filter Element, LP Burners (includes gaskets) ........509028 Note: Illustrations are for parts identification only. Illustrations may not represent actual parts.
  • Page 94 REPLACEMENT PARTS Chassis Lighting Connectors ITEM DESCRIPTION PART# Connector-7 Pin Flat Female ................48485 Connector-7 Pin Flat Male................P10002841 Connector-7 Pin Round Female ...............526017 Connector-7 Pin Round Male ................P10002840 Connector-6 Pin Round Female ...............P10002838 Connector-6 Pin Round Male ................P10002839 Connector-4 Pin Round Female ...............526103 Connector 4 Pin Round Male ................526014 Connector 9 Pin Round Female ...............P10002758 Connector 9 Pin Round Male ................P10002562...
  • Page 95 REPLACEMENT PARTS Chassis Lighting– Grommeted Lights ITEM DESCRIPTION PART# Oval Red Taillight 6" ..................P10002899 Oval Red Taillight LED 6" ................P10007080 Round Red Taillight ..................P10002896 Round Red LED Taillight 4" ................44030R Round Red Clearance Light 2.5" ..............P10002892 Round Amber Clearance Light 2.5"...
  • Page 96 REPLACEMENT PARTS Chassis ITEM DESCRIPTION PART# Screw Jack, 15" body ..................501051 Screw Jack, 20" body ..................P10001273 Ring Hitch ....................... W10004075 Ball Hitch, 2 5/16" ..................901038 Ring hitch-model 10 actuator, hydraulic brakes ..........901317 Right hitch-model 20 actuator, hydraulic brakes ..........901317A Note: Illustrations are for parts identification only.
  • Page 97 REPLACEMENT PARTS Miscellaneous CONVEYOR ASSEMBLY Belt Conveyor 18"x332" P10006477 Hydraulic Motor P10006578 Sprocket #50 Chain 1" Bore P10006471 Chain- 50# Roller P10006227 Master Link #50 P10006480 ENGINE Engine Cabinet A10008210 1505 Engine Assembly A10008263-002 Includes: Fuel Pump 12 volt DC P10000156 Kubota 1505 Diesel 60 Amp Alter.
  • Page 98 REPLACEMENT PARTS Miscellaneous PRODUCT PUMP Pump- HL32 L/RV Product P10004373 Key Stock 3/16x3/16 P10002018 Key Stock 1/4x1/4 P10002019 Valve- 1 1/2- 3 way Ball Valve P10004387 Valve 1" - 3 way Ball Valve P10004391 Chain Hub - 4016x 3/4 P1000455-002 Chain Hub - 4016x 1 Bore P1000455-004 Chain Only 4016...
