- Page 1 Moisture Controller Installation Manual PNEG-1405 Version: 2.0 Date: 03-09-16 PNEG-1405...
- Page 2 All information, illustrations, photos and specifications in this manual are based on the latest information available at the time of publication. The right is reserved to make changes at any time without notice. PNEG-1405 Moisture Controller...
-
Page 3: Table Of Contents
Table of Contents Contents Chapter 1 Safety ..............................4 Safety Guidelines ..........................4 Safety Instructions ..........................5 Chapter 2 Component Installation ........................7 Chapter 3 Electrical Connections ........................12 Chapter 4 Warranty ..............................17 PNEG-1405 Moisture Controller... -
Page 4: Chapter 1 Safety
This symbol indicates a potentially hazardous situation which, CAUTION if not avoided, may result in minor or moderate injury. This symbol indicates a potentially hazardous situation CAUTION which, if not avoided, may result in property damage. PNEG-1405 Moisture Controller... -
Page 5: Safety Instructions
Prepare for Emergencies Be prepared if fire starts. Keep a first aid kit and fire extinguisher handy. Keep emergency numbers for doctors, ambulance service, hospital and fire department near your telephone. Keep Emergency Equipment Quickly Accessible PNEG-1405 Moisture Controller... - Page 6 A respirator may be needed to prevent breathing potentially toxic fumes and dust. Wear a hard hat to help protect your head. Hard Hat Wear appropriate fall protection equipment when working at elevations greater than six feet (6'). Fall Protection PNEG-1405 Moisture Controller...
-
Page 7: Chapter 2 Component Installation
2. Component Installation Location for the Moisture control box second and Moisture control box leg channel. (D01-1656) third leg back from dryer control box. Figure 2A Figure 2B Moisture control box leg channels installed. Figure 2C PNEG-1405 Moisture Controller... - Page 8 3/8"-16 x 1" flanged bolts and 3/8"-16 flanged nuts as shown in Figure 3. Install the moisture sampler assembly as shown in the installation manual PNEG-1283. Figure 2E Moisture sampler assembly installed on the discharge box. PNEG-1405 Moisture Controller...
- Page 9 5. Connect the ground wire (A) for the Moisture Sensor to the rear auger bearing plate as shown Figure 6. Run the shielded wire (B) connected to the Moisture Sensor through the grey flex conduit supplied. Connect the conduit to 90° conduit connector already installed on the Moisture Sensor. PNEG-1405 Moisture Controller...
- Page 10 Figure 2K Plenum Thermocouple (602E181) Ref # Description Plenum knockout holes Where to install the Plenum Thermocouple. The Figure 2J and Figure 2K is showing the right rear side of the dryer (near the rear access door). PNEG-1405 Moisture Controller...
- Page 11 10. Put cable ties approximately every 4'' to hold all loose wires and cables in place. Do not tie any of these wires to AC leads. Cut off cable tie ends. After all the components, conduits and wire are in place proceed to the electrical connections starting with Step 1 on Page PNEG-1405 Moisture Controller...
-
Page 12: Chapter 3 Electrical Connections
1/4" for the individual wires and connect them to the terminal strip according to the decal below it (i.e. green to GN.) Location of terminal strip for connecting the Moisture Sensor cable leads. Connecting the Moisture Sensor leads. Figure 3A PNEG-1405 Moisture Controller... - Page 13 Location of terminal strip for connecting the weather sensor cable leads. Connecting the Weather Sensor leads. Figure 3B Ref # Description Ref # Description White Terminal 11 Red Terminal 7 Black Terminal 10 Green Terminal 8 Brown terminal 9 Weather Sensor Cable PNEG-1405 Moisture Controller...
- Page 14 10) and connect them to the terminal strip as shown in Figure Location of terminal strip for connecting the Moisture Sensor cable leads. Connecting the Plenum Thermocouple leads. Figure 3C Ref # Description Red Terminal 6 White Terminal 5 PNEG-1405 Moisture Controller...
- Page 15 Figure DMC AIR SYSTEM Figure 3D Moisture/Matic and GSI Dryer Hookup Installation of the Moisture Manager assembly is complete. Be sure to tie down any loose sensor wire and make sure all connections and hardware are tight. PNEG-1405 Moisture Controller...
- Page 16 NOTES PNEG-1405 Moisture Controller...
-
Page 17: Chapter 4 Warranty
GSI Group, LLC Limited Warranty The GSI Group, LLC (“GSI”) warrants products which it manufactures to be free of defects in materials and workmanship under normal usage and conditions for a period of 12 months after sale to the original end-user or if a foreign sale, 14 months from arrival at port of discharge, whichever is earlier. - Page 18 GSI Group 1004 E. Illinois St. Assumption, IL 62510-0020 Phone: 1-217-226-4421 Fax: 1-217-226-4420 www.gsiag.com GSI is a worldwide brand of AGCO Corporation. Copyright © 2016 by The GSI Group, LLC Printed in the USA CN-314486...
