Jason.L Elements 6 Person Workstation Assembly Instructions Manual

Size: 1800mm
Hide thumbs
1
2
3
4
5
6

Advertisement

Quick Links

Download this manual
ASSEMBLY INSTRUCTIONS
Elements 6 Person
Workstation
Size: 1800mm
Tools Required: Power screwdriver.
Special Note: No pre-drilled holes or nut inserts are
provided. Wood screws will be required to be drilled
directly into underside of desk top.
2 persons required for installation
www.jasonl.com.au
Need help!
Call us on
1300 527 665
Page 1 of 6

Advertisement

loading
Need help?

Need help?

Do you have a question about the Elements 6 Person Workstation and is the answer not in the manual?

Questions and answers

Related Manuals for Jason.L Elements 6 Person Workstation

Summary of Contents for Jason.L Elements 6 Person Workstation

  • Page 1 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Elements 6 Person Need help! Call us on Workstation 1300 527 665 Size: 1800mm Tools Required: Power screwdriver. Special Note: No pre-drilled holes or nut inserts are provided. Wood screws will be required to be drilled directly into underside of desk top. 2 persons required for installation Page 1 of 6...
  • Page 2 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Elements 6 Person Need help! Call us on Workstation 1300 527 665 Size: 1800mm COMPONENTS Desk top x6 (1800mm x 800mm) Base Foot x16 Top plate x8 Core cover x8 Leg core insert x4 Sleeve Cap x16 SCREWS Leg core return x8 Extandable Beam x6...
  • Page 3 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Elements 6 Person Need help! Call us on Workstation 1300 527 665 Size: 1800mm Unwrap all leg components. Remove sleeve cap (J) and sleeve cover (F) from all leg sleeves. Insert base foot (H) into leg sleeve (E) by rotating base foot (H) clockwise.
  • Page 4 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Elements 6 Person Need help! Call us on Workstation 1300 527 665 Size: 1800mm Connect extendable Beams (K) to Legs Core (D) Tighten Top Plates (B) to outer legs core (D) by tightening Screw (P). Tighten Top Plates (B) to middle legs core (D) by tightening Screw (P). Page 4 of 6...
  • Page 5 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Elements 6 Person Need help! Call us on Workstation 1300 527 665 Size: 1800mm Attach outsider legs + beam to Desk Tops by tightening Scews (O). Attach middle leg to Desk Tops by tightening Scews (O). Page 5 of 6...

  • Page 6: Need Help

    www.jasonl.com.au ASSEMBLY INSTRUCTIONS Elements 6 Person Need help! Call us on Workstation 1300 527 665 Size: 1800mm Using an Allen key remove top 2 caps from all screens (L) uprights. Bring two partition towards one another and slide the 2 way connector rod (N) - down between the two screen uprights.
