- Page 1 www.jasonl.com.au INSTALLATION GUIDE San Fran System Need help! Call us on 6 Person Workstation 1300 527 665 Size: 1800mm Tools Required: Power screwdriver. Special Note: No pre-drilled holes or nut inserts are provided. Wood screws will be required to be drilled directly into underside of desk top. Page 1 of 4...
-
Page 2: Installation Guide
www.jasonl.com.au INSTALLATION GUIDE San Fran System Need help! Call us on 6 Person Workstation 1300 527 665 Size: 1800mm COMPONENTS Leg x8 Adjustable Foot x8 Leg Cable Cover x8 Rail Lengths x4 (1520mm) Rail Widths x4 (620mm) 2 Way Connector x4 2 Way Connector Cap x4 3 Way Connector x4 3 Way Connector Cap x4... - Page 3 www.jasonl.com.au INSTALLATION GUIDE San Fran System Need help! Call us on 6 Person Workstation 1300 527 665 Size: 1800mm Slide the 2 way and 3 way connectors over each leg, and securely lock into place Loosely connect the longer M8x20mm dome head bolt and slot nut through the using M8x20mm cap head bolts.
- Page 4 www.jasonl.com.au INSTALLATION GUIDE San Fran System Need help! Call us on 6 Person Workstation 1300 527 665 Size: 1800mm Securely connect legs to rails widths using the shorter M8x12mm dome head Ensure the work surfaces are centered over the frame. Fully tighten all M5x20mm bolts.
