Quick
Start Guide
RP-AC51
Wi-Fi AC Repeater
E12398 / First Edition / March 2017
BEFORE SETUP
Placing your RP-AC51
01
1
Place your RP-AC51 near your
router/AP.
SETUP METHODS
1
APP SUPPORT
METHOD
Download the app
01
2
WPS SUPPORT
METHOD
Connect via WPS
01
1
Press the WPS button on your
router/AP.
E12398_RP-AC51_QSG_Special_A3.indd 1
WE SUGGEST...
2
Check the LEDs and see the
LED explanations.
around 2 meters
2
Press the WPS
button on your
RP-AC51 for
more than two (2)
seconds until the
power LED starts
to blink.
NOTE: Wait until the existing network LED blinks
for about two (2) minutes, then turns solid blue,
indicating the WPS process is completed.
LED explanations
POWER
On: RP-AC51 is power on.
Off: RP-AC51 is power off.
EXISTING NETWORK
On: Connected to the router/AP.
Off: Not connected to the
router/AP.
MOVE CLOSER
Need to move RP-AC51 closer
to the router/AP.
MOVE AWAY SLIGHTLY
Need to move RP-AC51 slightly
away from the router/AP.
Power On
02
1
Plug your RP-AC51 to a
power outlet.
2
Turn on the power switch.
02
Use the app
1
Tap SET UP EXTENDER.
2
Open your phone Wi-Fi, and connect
to your RP-AC51's SSID.
Enjoy Wi-Fi
02
Your RP-AC51's wireless network name (SSID) changes to your existing Wi-Fi network name,
ending with _RPT or _RPT5G and shares your router/AP's Wireless Password.
Button explanations
POWER SWITCH
Switch this button on/off to turn
RP-AC51 on/off.
WPS BUTTON
Press this button to quickly
connect to the router/AP via the
WPS method.
RESET
BUTTON
Use a pin
to push this
button to reset
RP-AC51 to
its factory de-
fault settings.
Wait until the power LED turns blue,
indicating that your RP-AC51 is ready to
connect to your existing router/AP.
3
Follow the Quick Extender Setup instructions.
4
Assign a unique network name (SSID) for your extended
network.
5
Wait until the setup is completed.
Reset
