PHCC Pro Series Instruction Manual & Safety Warnings

Sewage Pumps
Instruction Manual &
Safety Warnings
Models E7040, E7055, E7105
E7040-NS
E7105-NS

Important Safety Instructions

• ALWAYS disconnect the pump and float switch controller from the power source before servicing
• NEVER handle the pump or motor with wet hands or when standing on a wet or damp surface
• MAKE SURE THERE IS A PROPERLY GROUNDED RECEPTACLE AVAILABLE. This pump is wired with
• NEVER bypass grounding wires or remove the ground prong from the plug.
• DO NOT use an extension cord. The electrical outlet should be within the length of the pump's
• DO protect the electrical cord from sharp objects, hot surfaces, oil, and chemicals. Avoid kinking
• MAKE SURE the supply circuit has a dedicated fuse or circuit breaker rated to handle the power
• DO NOT use the power cord or strain relief to carry the pump. Use the pump handle.
• DO NOT pull on the float switch cord.
• DO NOT expose the control unit to any type of moisture, water, rain or snow.
• DO NOT place the controller on the floor. The electrical outlet should be within the length of the
• DO NOT operate this product if it has been damaged in any way.
• DO NOT use sewage pumps in pits handling salt water or hazardous liquids.
• DO NOT flush foreign objects down the toilet including but not limited to paper towels, napkins,
• DO NOT disassemble this product. When service is required, contact Glentronics technical support
• When installing or replacing a sewage pump you should also install a high water alarm.
E7055-NS
Items Included:
Pump
Choice of controller, float
Stainless steel hose clamp
You may also need:
2" rigid PVC pipe to connect to
the existing plumbing
A check valve or union
PVC pipe cleaner
and cement
SAVE THESE INSTRUCTIONS. This manual contains important SAFETY WARNINGS and OPERATING
INSTRUCTIONS. You will need to refer to it before attempting any installation or maintenance.
ALWAYS keep these instructions with the unit so that they will be easily accessible.
Failure to read and follow these warnings and instructions could result in property damage,
serious injury, or death.
Risk of electric shock. To reduce this risk, observe the
! WARNING
following precautions.
or making adjustments.
while the pump is plugged into the power source.
a 3-prong grounded plug. To reduce the risk of electric shock, be certain that it is only connected
to a properly grounded, 3-prong receptacle. If you have a 2-prong receptacle, have a licensed
electrician replace it with a 3-prong receptacle according to local codes and ordinances.
power cord, and at least 4 feet above the floor level to minimize potential hazards from flood
conditions.
the cord.
requirements noted on the nameplate of the pump.
To reduce the risk of hazards that can cause injury or property
! CAUTION
damage, observe the following precautions.
pump's power cord and at least 4 ft above the floor.
wipes, baby wipes, feminine products (sanitary napkins or tampons), prophylactics,
contraceptives, or dental floss.
at 800-991-0466. Return the product to the manufacturer for any repairs at the following address:
Glentronics, Inc., 645 Heathrow Drive, Lincolnshire, IL 60069
Specifications 4/10 HP Model E7040
GPH @ 5' 5640
GPH @ 10' 4440
Pump diameter 9"
Volts 115V, 60Hz
Amps 6.3
Enhanced Deluxe
Controller Controller
1/2 HP Model E7055 1 HP Model E7105
6360 8040
5340 6000
9" 9"
115V, 60Hz 115V, 60Hz
7.0 10.5
Vertical Float Tether Float
Switch Switch
