PHCC ST1033 Instruction Manual & Safety Warnings

Sump Pumps
Instruction Manual &

Safety Warnings

Models ST1033 & ST1050

Items included:

You may also
need:
Pump
Choice of controller,
1-1/2" or 2" rigid PVC
float/sensor
pipe to connect to the
existing plumbing
Stainless steel hose
clamp
A check valve or union
2" x 1-1/2" reducer
PVC pipe cleaner and
adapter (on 1/2 HP
cement
pump only)
A surge protector
Note:
The 1/2 HP pump will accomodate a 2" discharge
pipe. However, most homes have 1-1/2" pipes.
Therefore we have included a 2" x 1-1/2" reducer
adapter with this pump. You may replace your 1-
1/2" discharge pipe with a 2" discharge pipe, and a
2" adapter to obtain the optimum gallons per hour.

Important Safety Instructions

• ALWAYS disconnect the pump from the power source before servicing or making
• NEVER handle the pump or motor with wet hands or when standing on a wet or damp
• MAKE SURE THERE IS A PROPERLY GROUNDED RECEPTACLE AVAILABLE. This pump is
• NEVER bypass grounding wires or remove the ground prong from the plug.
• DO NOT use an extension cord. The electrical outlet should be within the length of the
• DO protect the electrical cord from sharp objects, hot surfaces, oil, and chemicals. Avoid
• MAKE SURE the supply circuit has a fuse or circuit breaker rated to handle the power
• DO NOT use the power cord or strain relief to carry the pump. Use the pump handle.
• DO NOT expose the control unit to rain or snow.
• DO NOT operate the pump or control unit if it has been damaged in any way.
• DO NOT use sump pumps in pits handling raw sewage, salt water, or hazardous liquids.
• DO NOT disassemble the pump or control unit. When service is required, contact
1-1/2"
discharge
1/3 HP Pump 1/2 HP Pump
ST1033 ST1050
SAVE THESE INSTRUCTIONS. This manual contains important SAFETY WARNINGS and
OPERATING INSTRUCTIONS for the Pro Series pumps. You will need to refer to it before
attempting any installation or maintenance.
ALWAYS keep these instructions with the unit so that they will be easily accessible.
Failure to read and follow these warnings and instructions could result in property
damage, serious injury, or death.
Risk of electric shock. To reduce this risk, observe the
WARNING
following precautions.
adjustments.
surface while the pump is plugged into the power source.
wired with a 3-prong grounded plug. To reduce the risk of electric shock, be certain that
it is only connected to a properly grounded, 3-prong receptacle (preferably with ground
fault circuit interrupt). If you have a 2-prong receptacle, have a licensed electrician
replace it with a 3-prong receptacle according to local codes and ordinances.
pump's power cord, and at least 4 feet above the floor level to minimize potential
hazards from flood conditions.
kinking the cord.
requirements noted on the nameplate of the pump.
To reduce the risk of hazards that can cause injury or
CAUTION
property damage, observe the following precautions.
Glentronics technical support at 800-991-0466, option 3. Return the product to the
manufacturer for any repairs at the following address:
Glentronics, Inc., 645 Heathrow Drive, Lincolnshire, IL 60069

Specifications

1/3 HP Model ST1033
GPH @ 0' 4100
GPH @ 10' 2770
G/Wh 6.1
Pump diameter 7.375"
Volts 115V, 60Hz
Amps 3.8
G/Wh = Gallons per Watt Hour
2"
discharge
DFC1 Controller
& Dual Float
1/2 HP Model ST1050
5300
3630
6.3
9.75"
115V, 60Hz
4.8
G/Wh = GPH/(Amps x Volts)
DFC2 Deluxe
USC3 Ultimate Solid
Controller
State Controller &
& Dual Float Ultimate Sensor
