Summary of Contents for Wingsland X1
- Page 1 User Manual V1.0...
-
Page 2: Table Of Contents
Control Flight by Using Mobile Devices 13-17 Preparation Before Flight Operation of Virtual Joy Stick Motion Control Flip Flight Disclaimer Product Safety Notice Flight Battery Safety Guidelines Limitation of Liability Firmware Update Appendix Specifications After Sales Service Information Copyright © 2017 WINGSLAND All Rights Reserved... -
Page 3: Introduction
Notice User Suggestion Wingsland X1 is an aircraft with lots of entertaining options, but please be attention that the X1 is not a toy. The wingsland X1 contains a flight controller, video system, propulsion system and intelligent flight battery, we highly recommend you to read the wingsland X1 Quick Start Manual and the X1 User Manual carefully before your first flight , to watch the video tutorial to ensure your safety. -
Page 4: Product Introduction
Product Descriptions Brief Introduction The wingsland X1 is a FPV drone with many entertainment features, you can control the flight by using your mobile devices. Indoor Optical Flow Positioning System can help you to achieve indoor hover and speed racing easily. The X1 is Equipped with adjustable HD camera and HD digital transmission to seize the moment. -
Page 5: Aircraft
X1 can hover at current height and postion. At a flight height no higher than 2.5m, the vision system can’t function properly, the X1 won’t hover but flow with air. -
Page 6: Exclusive Battery
2. Connect one end of the micro USB connector to the aircraft, and the other end to the power adapter. The input voltage is 5V. 3. During the charging , the front indicator light of the X1 will blink slowly, and it will go out when the charging is complete. -
Page 7: Status Indicating Light
There are 2 indicators on the aircraft, 2 are located on the front and 1 is located at the end of the aircraft, they show the orientation and some functions of the X1, it helps the users to get to know the aircraft status in an easy way. -
Page 8: Propeller & Propeller Guard
Counter-clockwise（B） Clockwise（A） If the propellers are not installed on corresponding motors, the X1 aircraft cannot fly normally, and will even flip over or rotate on the ground. How to Disassemble ① How to disassemble the propeller Pull the propeller guard down with one hand, while use the tool to clamp the propeller to lift it up. -
Page 9: Extension Port
X1 User Manual Extension Port The extension port is located at the bottom of X1, it is used to connect with the optional entertaining accessories provided by wingsland. DIY Stickers Stickers Usage: ① Paste the middle stickers on the middle of the aircraft upper shell. -
Page 10: Wingsland X1 App
X1 User Manual Wingsland X1 APP After the mobile device connected with the X1 WiFi, you could control the X1 on wingsland X1 APP. Control Interface Introduction： TakeOff H: 0. 0 V . S： 0. 0 F . T: 00: 00... - Page 11 4. Select “Start to Fly”and get into control interface. Real-time image would be shown on screen if device is successfully connected. Aerialhighlight TakeOff H: 0. 0 V . S： 0. 0 F . T: 00: 00 China hainan Start to Fly Main Interface Control Interface Copyright © 2017 WINGSLAND All Rights Reserved...
- Page 12 9. Under the “Connection Setting”, you can also change the WiFi frequency channel. If the you fly the aircraft in a strong signal interference area, or more than one X1 in the same area, we recommend changing the frequency channel, so that mobile devices and X1 can smoothly communicate.
-
Page 13: Function Menu
Motion Sensitive Palm Takeoff Cancel H: 0. 0 V . S： 0. 0 F . T: 00: 00 H: 0. 0 V . S： 0. 0 F . T: 00: 00 Copyright © 2017 WINGSLAND All Rights Reserved... -
Page 14: Control Flight By Using Mobile Devices
: wingsland X1_air_xxxxxx , and the password should be “wingsland”. 4. Run the wingsland X1 APP, tap “Start to Fly” and get into the control interface. The real-time image would be shown if the mobile device is successfully connected. -
Page 15: Operation Of Virtual Joy Stick
X1 User Manual Palm Takeoff ● After the aircraft is connected to the mobile device, put X1 on your palm and stretch your arm. ● Tap “Function Menu” icon and select “Palm Takeoff”, double tap the screen after confirm the notification, then the aircraft should automatically take off. - Page 16 Right joystick Left thumb slide up,Aircraft will fly upwards,Left thumb slide down,Aircraft will fly downwards. Right joystick Right thumb slide left,Aircraft will fly leftwards.Right thumb slide right,Aircraft will fly rightwards. Copyright © 2017 WINGSLAND All Rights Reserved...
-
Page 17: Motion Control
Aircraft will fly left Right Left Backward Nose Direction of Aircraft Aircraft will fly forward Aircraft will fly backward Under Motion Sensitive mode, left virtual joystick functions are the same as Mode 2. Copyright © 2017 WINGSLAND All Rights Reserved... -
Page 18: Flip Flight
F . T: 00: 00 ● Please ensure enough space for the Aerial Flip, at least 1m from X1 to the top, bottom, left and right. ● The Auto Flipping function can not be active when battery power is lower than 60%. -
Page 19: Disclaimer
2. Do not put the battery into fire or store in a high temperature environment. Using the battery in environments above 50℃ may cause fire or explosion. 3. Do not use non-Wingsland batteries, wingsland takes no responsibility for any damage or accidents caused by non-Wingsland batteries. -
Page 20: Limitation Of Liability
Limitation of Liability Wingsland accepts no liability for damage(s), injuries or any legal responsibilities incurred directly or indirectly from the use of this product in the following conditions, and this limitation of liability applies to wingsland suppliers, dealers and service providers: 1. -
Page 21: Firmware Update
X1 User Manual Firmware Upgrade When new firmware is launched, wingsland will publish the new firmware on the our official website. Please subscribe to our official website: www.wingsland.com Please go to wingsland official website www.wingsland.com for user registration, when a new firmware update, we will inform you by e-mail. - Page 22 This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. ★ Information in this User Manual could be amended without notice. Please download the latest version from the technical support page on our website: www.wingsland.com. MADE IN CHINA...
