- Page 1 Your Global Automation Partner NIC…-M30 Inductive Coupler Instructions for Use...
- Page 2 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
-
Page 3: Table Of Contents
Contents About these Instructions 5 Target groups 5 Explanation of Symbols Used 5 Other documents 5 Feedback about these instructions 5 Notes on the Product 6 Product identification 6 Scope of delivery 6 Legal requirements 6 2.3.1 Device classification according to SRD EN 300 440 6 Manufacturer and Service 7... - Page 4 Technical data of the secondary side 21 14.3 Technical data of inductive transfer system 22 14.4 Design 22 Appendix: EU Declaration of Conformity 23 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
-
Page 5: About These Instructions
We make every effort to ensure that these instructions are as informative and as clear as pos- sible. If you have any suggestions for improving the design or if some information is missing in the document, please send your suggestions to techdoc@turck.com. V01.01 | 2018/11... -
Page 6: Notes On The Product
The device complies with the following classifications according to ETSI EN 300 440: Receiver category 3 Generic short range device Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 7: Manufacturer And Service
45472 Muelheim an der Ruhr Germany Turck supports you with your projects, from initial analysis to the commissioning of your applic- ation. The Turck product database contains software tools for programming, configuration or commissioning, data sheets and CAD files in numerous export formats. You can access the product database at the following address: www.turck.de/products... -
Page 8: For Your Safety
Do not place any metal objects such as screw drivers in the electrical field between the primary and secondary side. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 9: Product Description
Product Description The devices have a cylindrical housing style with an M30 × 1.5 male thread. An M12 connector (male) directly on the housing is used to connect the NICP-M30-IOL2P8X-H1141 primary side. The NICP-M30-8P8-0,3-RSC12T primary side and the NICS-M30-IOL2P8-0,3-RKC4.4T secondary side are provided with a 0.3 m connection cable with an M12 male connector (pigtail). Device overview Fig. 1: Primary side NICP-M30- Fig. 2: Primary side NICP-... -
Page 10: Functions And Operating Modes
IO-Link mode. IO-Link mode provides a bidirectional IO-Link communica- tion between an IO-Link master and an IO-Link device via the air interface. Fig. 6: Setup example for IO-Link communication Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 11: Transfer Of 8 Standard Pnp Signals
4.4.3 Transfer of 8 standard PNP signals The following devices are required for the transfer of 8 standard PNP signals: NICP-M30-8P8-0,3-RSC12T (primary side) NICS-M30-IOL2P8-0,3-RKC4.4T (secondary side) TBIL-M1-16DIP (I/O hub for IO-Link) If the secondary side is connected to a TBIL-M1-16DIP I/O hub for IO-Link, up to 8 standard PNP signals can be transferred via the inductive coupler. -
Page 12: Technical Accessories
2 m, M23 plug connector, straight, 19- pin, for direct connection to BL67 base module with M23 plug connector Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 13: Mounting
Mounting The maximum tightening torque of the housing nuts is 40 Nm. „ Check whether the housing material and the degree of protection is sufficient for your application in terms of resistance, vibration resistance and cleaning (see chapter 14, Technical Data. „... -
Page 14: Power With Lateral Offset
12 W 2 mm 12 W 4 mm 12 W 6 mm 12 W 7 mm 12 W 8 mm Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 15: Connecting
Connecting Transfer of 2 standard PNP signals (digital inputs) „ Connect sensors (e.g. to a VB2-FSM4.4-2FKM4 2-port junction system). „ Connect NICS-M30-IOL2P8-0,3-RKC4.4T on the secondary side to a sensor as per the pin layout. „ Connect the primary side NICP-M30-IOL2P8X-H1141 to a controller or a fieldbus device via an M12 connection cable (e.g. -
Page 16: Transfer Of 8 Standard Pnp Signals
3 BU 4 Input 1 & C/Q (IO-Link) 4 BK Fig. 22: Pin layout, secondary side Fig. 23: Wiring diagram, secondary side Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 17: Commissioning
Commissioning The device is ready for power transfer after the power supply is connected and switched on and after a power up delay of 160 ms. The delay for the data transmission is typically 750 ms, but can take longer in individual cases. The length of the delay, for example, may depend on the following factors: Connected devices on the secondary side Set cycle time in the IO-Link master... -
Page 18: Operation
FOD status pin is set. As soon as the device no longer detects any metal, the system returns automatically to the op- erational state. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 19: Troubleshooting
Troubleshooting If the device does not function as expected, first check whether ambient interference is present. If there is no ambient interference present, check the connections of the device for faults. If there are no faults, there is a device malfunction. In this case, decommission the device and replace it with a new device of the same type. -
Page 20: Maintenance
Undo if necessary the connection of the device to the mounting aid. Disposal The devices must be disposed of correctly and must not be included in normal household garbage. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 21: Technical Data
Technical Data 14.1 Technical data of the primary side Technical data NICP-M30-IOL2P8X-H1141 NICP-M30-8P8-0,3-RSC12T Operating voltage 24 VDC ± 10 % 24 VDC ± 10 % Operating current 750 mA 750 mA Nominal distance 0…7 mm 0…7 mm Ambient temperature -20…+55 °C -20…+55 °C Output function 4-wire PNP and IO-Link 12-wire PNP... -
Page 22: Technical Data Of Inductive Transfer System
Short-circuit protection Reverse polarity protection 14.4 Design Technical data Housing material Metal, CuZn, chrome-plated Material of active face Plastic, PA 12-GF30 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 23: Appendix: Eu Declaration Of Conformity
Appendix: EU Declaration of Conformity V01.01 | 2018/11... - Page 24 Over 30 subsidiaries and over 60 representations worldwide! 100003896 | 2018/11 100003896 www.turck.com...
