- Page 1 BroadWeigh Original Instructions mantracourt.com BroadWeigh Dynamic Wireless Load Monitoring...
-
Page 2: Table Of Contents
Navigating This Manual ................................... 2 Safe Use .......................................... 2 Inspection and Maintenance .................................. 5 Pre Use Checks ......................................7 Log 100 ........................................... 9 Toolkit ........................................... 11 Troubleshooting ....................................... 13 Declaration of Conformity ..................................16 Warranty ........................................17 Mantracourt Electronics Limited BroadWeigh Original Instructions... -
Page 3: Introduction / Overview
Hyperlinks are coloured orange and are underlined. Safe Use Designed to aid rigging professionals on a daily basis, the BroadWeigh wireless Crosby load cell shackles offer simple, real-time, effective and accurate load monitoring. It allows users to know the precise loads on any given rigging point, guy wire or hoist in a rigging system. - Page 4 The pin must be aligned in the same orientation with the bow as it was when calibrated. • The BroadWeigh shackle is designed to only fit together in one orientation. The ABS enclosure should be • on the opposite side to the ID marking on the shackle bow.
- Page 5 If using the shackle as part of a bridle, remember that the load in legs of the bridle will increase with the angle. If the BroadWeigh shackle pin is not connected to that part of the leg then it will not register this increase.
- Page 6 Please remember that BroadWeigh does not give advice as to how the data from BroadWeigh shackles is used. All lifting operations are different and must be supervised by suitably qualified and experienced riggers. It is the user’s responsibility to ensure conformity with local regulations and legislation.
-
Page 7: Inspection And Maintenance
Inspection and Maintenance As with all rigging equipment, BroadWeigh shackles and TwistLinks should be inspected before and after every use, ensuring that all the components are present and correct (bow, pin, bobbin or TwistLink, nut and r clip) and the serial numbers match. All load bearing components must be free from cuts, nicks, cracks, gouges or excessive wear and distortion. -
Page 8: Pre Use Checks
It is a good idea to note down all the shackles’ data tags and IDs and where they are located within the rig plot. This is crucial for identifying which loads are being measured and where. The ID will be needed to soft pair. BroadWeigh Handheld Display Mantracourt Electronics Limited... - Page 9 Bobbins or TwistLinks are in place R-clips are in place Shackles’ data tags and rig location are noted All load bearing components must be free from cuts, nicks, cracks, gouges or excessive wear and distortion Mantracourt Electronics Limited BroadWeigh Original Instructions...
-
Page 10: Log 100
LOG100 PC logging and mapping software will be provided by your distributor. The BroadWeigh Toolkit is available to download from www.broadweigh.com/support. It is used for the initial setup of the hardware and to monitor wireless traffic in the area (see below). - Page 11 To summarise, select the number of display channels required, assign Data Tags to the expression section (ensuring that they are enclosed in triangular brackets, <FF69>) and change any other parameters as necessary. The triangular brackets allow the expression field to identify the Data Tag for what it is. Mantracourt Electronics Limited BroadWeigh Original Instructions...
-
Page 12: Toolkit
More detailed information on the BroadWeigh Toolkit is available in the main user manual at www.broadweigh.com/support. Install the BroadWeigh Toolkit by inserting the CD or USB stick and following the instructions. Then connect the USB base station and launch the software. - Page 13 Pairing This is the system used for configuring the BroadWeigh devices. First, remove one of the batteries. Then, click the ‘Pair’ button (on the home screen) and firmly re-connect the power to the device. This makes a very reliable link without needing to know the device’s Data Tag or radio channel.
-
Page 14: Troubleshooting
Be aware that the base station can only be set to one radio channel. Therefore you cannot log data and pair devices at the same time. It is good practice to configure the hardware via the BroadWeigh Toolkit before using the LOG100 software as it is possible for the two programs to give conflicting instructions. - Page 15 Check local traffic on the 2.4GHz radio band. Using the BroadWeigh Toolkit, go to the Spectrum Analyser page. This will show local traffic on the 2.4GHz radio band and highlight any potential congestion. You can then change the radio channels for all devices via pairing.
- Page 16 Make sure that all the devices required are visible and make sure that any receivers to be moved are powered up. (They won’t be visible on this page to check). Please see our website or scan QR code for quick start videos, the manual and associated software: www.broadweigh.com/support.html Mantracourt Electronics Limited BroadWeigh Original Instructions...
-
Page 17: Declaration Of Conformity
Address: The Drive, Farrington, Exeter, Devon, EX5 2JB Country: United Kingdom Declare under our sole responsibility that the Broadweigh Product Range is in conformity with the following relevant Union harmonisation legislation: LVD Directive 2014/35/EU EMC Directive 2014/30/EU RoHS Directive 2011/65/EU... -
Page 18: Warranty
(1) year from the date of dispatch. If the 'Mantracourt' product you purchase appears to have a defect in material or workmanship or fails during normal use within the period, please contact your Distributor, who will assist you in resolving the problem. - Page 19 This page intentionally blank Mantracourt Electronics Limited BroadWeigh Original Instructions...
- Page 20 In the interests of continued product development, Mantracourt Electronics Limited reserves the right to alter product specifications without prior notice. www.mantracourt.com Manufactured in the UK by: Mantracourt Electronics Ltd, The Drive, Farringdon, Exeter, Devon, EX5 2JB, UK Distributor: Mantracourt Electronics Limited...
