- Page 1 Mobile Projector Mobile Projector Startup Guide Guía de inicio Guia Rápido © 2016 Sony Corporation Printed in Korea MP-CL1A MP-CL1A 3-MPA- 011-01 MP-CL1A 3-MPA- 011-01 MP-CL1A 3-MPA- 011-01...
-
Page 2: Table Of Contents
Connecting via Bluetooth® connection..........14 ................ﺗﺤﺮ ي اﻟﺨﻠﻞ وإﺻﻼﺣﮫ Connecting using a cable..............16 Troubleshooting............. 17 ....................اﻟﻤﻮاﺻﻔﺎت ............... ﻣﻼﺣﻈﺎت ﺣﻮل اﻻﺳﺘﻌﻤﺎل Specifications............18 .................. اﻟﻌﻼﻣﺎت اﻟﺘﺠﺎرﯾﺔ Notes on Use............19 Trademarks ............22 ....................ﺗﺤﺬﯾﺮ WARNING .............. 22 MP-CL1A 3-MP0-xxx-01 MP-CL1A 3-MP0-xxx-01... - Page 3 More information Refer to “Help Guide” in the menu for details about how to use the projector. [ Information] [ Help guide] “Help Guide” is also available on the Internet. http://www.sony.net/SonyInfo/Support/ MP-CL1A 3-MPA-011-01...
-
Page 4: Checking The Bundled Items
Doing so may cause serious injuries such as loss of eyesight. Checking the Bundled Items • Projector (1) • Lens cover stand (1) (see pages 8 to 9) • USB cable (1) • Carrying pouch (1) • Startup Guide (this manual, 1) MP-CL1A 3-MPA-011-01... -
Page 5: Parts And Controls
(for power supply) projector) Ventilation holes (power) button (charge) lamp (red/ Jog lever (−/ENTER/+) orange/green) Use this lever to select a (power) lamp (white menu item. Speaker Lens Laser radiates from this HDMI/MHL IN jack aperture. AUDIO OUT jack MP-CL1A 3-MPA-011-01... -
Page 6: About The Status Of Lamp
70% to 100% remaining 30% to 70% remaining 0% to 30% remaining Empty* * The (power) lamp (white) blinks at the same time. Green Status of lamp Projector condition Supplying power* * When connected with the AC Adaptor Low battery MP-CL1A 3-MPA-011-01... -
Page 7: Getting Started
Getting Started Charging the projector Connect the projector to a wall outlet with the USB cable ( supplied) and an AC adaptor (sold separately). (charge) lamp lights in amber while charging. AC adaptor Micro USB jack USB cable MP-CL1A 3-MPA-011-01... -
Page 8: Turning The Power On
Attach the lens cover stand by sliding from left to right. When projecting on a wall or in front Attach the lens cover stand by sliding from left to right, then rotate the stand and adjust the tilt of the projector to set the projection p osition. MP-CL1A 3-MPA-011-01... - Page 9 When projecting on the ceiling Attach the lens cover stand by sliding it from the bottom to the top, then rotate the stand. Note When taking out the projector from the carrying pouch, hold its body tightly. MP-CL1A 3-MPA-011-01...
-
Page 10: Connecting Your Device
HDMI connection, an Apple Digital AV adapter is required. Apple Digital AV adapter HDMI cable (sold separately) (sold separately) • HDMI device (PC, game, and so on) page 12 You can connect your device by using an HDMI connection. HDMI cable (sold separately) MP-CL1A 3-MPA-011-01... -
Page 11: Projecting The Contents Or Screen Of The Connecting Device
You can connect other devices to the projector by using screen mirroring or cables. Connecting via screen mirroring Press the jog lever while at the “ENTER” position to display the menu of the projector. Select [ Input change] - [ Screen mirroring] in the menu. MP-CL1A 3-MPA-011-01... -
Page 12: Connecting Via Hdmi Or Mhl Cable
A list of connectable devices is displayed on the screen of your device. For details, refer to the instruction manual of your device. Select the projector (MP-CL1A) in the list. Select [ Return] - [ ] in the menu of the projector to exit the menu. - Page 13 • Apple devices require an Apple Digital AV adapter (sold separately). • Depending on the specification of the AC adaptor or the projecting contents, the battery remaining may decrease while connecting to the AC adaptor. MP-CL1A 3-MPA-011-01...
-
Page 14: Connecting To External Speakers Or Headphones
Press the jog lever while at the “ENTER” position to display the menu of the projector. Select [@ Bluetooth function] - [@ Bluetooth function ON] in the menu. The Bluetooth mark (gray) appears on the screen, and the projector shifts into the pairing mode. MP-CL1A 3-MPA-011-01... - Page 15 If the mark color is gray, it means it is unconnected. In this case, r etry steps from 4 to 5. Connected Unconnected Select [Close] - [ ] in the menu of the projector to exit the menu. MP-CL1A 3-MPA-011-01...
-
Page 16: Connecting Using A Cable
• If your Bluetooth device is not displayed on [Available devices], select [Refresh] and wait until your device is displayed. • Select [Forget] to delete your device from [Paired devices]. Connecting using a cable Connect your speaker or headphone to the AUDIO OUT jack using a cable. MP-CL1A 3-MPA-011-01... -
Page 17: Troubleshooting
, check its specifications or cont Depending on the remaining act its manufacturer. battery power, the projector may shut down. In the event this happens, MP-CL1A 3-MPA-011-01... -
Page 18: Specifications
Pulse Frequency: 60 Hz Out (2.4000 GHz - 2.4835 GHz) put : 206 mW Modulation method: FHSS Com FOV (horizontal): 42.1° patible Bluetooth profiles* Input: DC5 V/1.5 A P (Advanced Audio Distribution Li-ion Battery: DC3.8 V/3400 Profile) Supported Codec* : SBC* MP-CL1A 3-MPA-011-01... -
Page 19: Notes On Use
• Do not disassemble or modify • Magnetic or electric noise may the projector. cause the noise from the proje ctor to become louder or MP-CL1A 3-MPA-011-01... - Page 20 Avoid hitting it with to use it with the projector. a hammer, putting any heavy obje • Sony is not liable for damage or l ct on top, stepping on it or droppi oss resulting from the use of the ng it.
- Page 21 • Use on a stable or flat surface • Sony is not liable for financial when using the projector with damages, lost profits, claims the lens cover stand. from third parties, etc., arising •...
-
Page 22: Trademarks
FCC RF Radiation Exposure ned by Bluetooth SIG, Inc. and an Statement: This equipment comp y use of such marks by Sony Corp lies with FCC RF Radiation expos oration is under license. Other tra ure limits set forth for an uncontr... - Page 23 • Reorient or relocate the receiving antenna. MP-CL1A 3-MPA-011-01...
- Page 24 For more information regard nd your body. ing recycling of rechargeabl e batteries, call toll free 1-80 0-822-8837, or visit http://w ww.call2recycle.org Caution: Do not handle dama ged or leaking Lithium- Ion b atteries. MP-CL1A 3-MPA-011-01...
- Page 25 Term: For the time period set forth above from the original da te of purchase of the product when purchased directly from S ony or Sony authorized dealer (To determine if a dealer is in th e Sony authorized dealer network, please visit US: www.sony.c om/retailers;...
