Supplied accessories

Make sure the following accessories are provided with the product.
Remote control unit
(×1)
Page 10
NOTE
• Always use the AC cord supplied with the TV/DVD.

QUICK REFERENCE

Attaching the stand

• Before attaching (or detaching) the stand, unplug the AC cord from the AC input terminal.
• Before performing work spread cushioning over the base area to lay the TV/DVD on. This will prevent it from being damaged.
CAUTION
• Attach the stand in the correct direction.
• Be sure to follow the instructions. Incorrect installation of the stand may result in the TV/DVD falling over.
1
Confirm the 8 screws supplied with the TV/DVD.
Short screws (
X
(used in step 2)
2
Remove the covering sheet of the stand.
Attach the base to the post.
1
Attach the base to the 4 screws into the 4 holes on the
2
bottom of the base.
Hex key
Screw
8
"AA" size battery (×2)
Page 10
4) Long screws (
X
(used in step 3)
AC cord (×1) Stand unit (×1)
Page 9
3
Insert the stand into the openings on the bottom of the
1
4)
TV/DVD.
Insert and tighten the 4 screws into the 4 holes on the
2
rear of the TV/DVD.
4
For protection, sheets
are covering the product.
Please remove these
sheets before use.
NOTE
• To detach the stand, perform the step in reverse order.
Operation manual (×1)
Page 8
Hex key
Screw
Soft cushion
(Illustration is LC-26DV28UT.)
