Measure Pupils

Position the NPi-200 with SmartGuard at a right angle
to the patient's axis of vision, minimizing any tilting of
the device (Ex. 16).
Press and hold either the RIGHT or LEFT button until the eye is centered on the
touchscreen and the display shows a green circle around the pupil (Ex. 17). Once the
green circle appears, release the button, holding the NPi-200 in place for approximately
three seconds, making sure the patient maintains an open eye position.
Repeat the scan procedure for the patient's other eye
to complete the bilateral pupil exam (Ex. 18).
When the bilateral pupil exam is complete, the NPi-200
measurement results will be displayed in yellow for the
Left eye and in green for the Right eye (Ex. 19).
Using the touchscreen or keypad, select page 1 (1/2) or 2 (2/2)
to display the results of the pupil measurement parameters
and pupillary light reflex waveform (Ex. 20).
Video Replay
From the Results screen, select the Video icon
of the reading (Ex. 21). Only the last measurement's video can be played back.
Once the device has been turned off, the last video is not accessible.
Disabling SmartGuard
The SmartGuard is designed for single patient use. To assist
facility compliance with HIPAA guidelines, the patient data
stored on each SmartGuard can be disabled once pupil exams
are no longer required. To permanently disable the patient data
on the SmartGuard, in the Settings menu press Disable SG
and follow the prompts (Ex. 22A & 22B).
NeurOptics® NPi®-200 Pupillometer System—Instructions for Use © 2018 NeurOptics, Inc.
Ex. 16
to view the video playback
Ex. 18 Ex. 19
Ex. 20
Ex. 21
Ex. 22A Ex. 22B
Ex. 17
5
