Media Access Control
Antenna
Network Architecture
Security
OS Supported
Host Interface
Operating Voltage
Dimension

5. Power Consumption

power Consumption
(Typical by using SWR)
FN-LINK TECHNOLOGY LIMITED
WiFi:
CSMA/CA with ACK
BT:
AFH, Time Division
External Antenna
WiFi:
Ad-hoc mode (Peer-to-Peer )
Infrastructure mode
Software AP
WiFi Direct
BT:
Pico Net, Scatter Net
WiFi:
WPA, WPA-PSK, WPA2, WPA2-PSK,
WEP 64bit & 128bit, IEEE 802.11x, IEEE 802.11i
BT:
Simple Paring
Android /Linux/ Win CE /iOS /XP/WIN7
WiFi: USB
BT: USB
3.3±10% Vdc I/O supply voltage
Typical L12.0*W12.0*H1.7mm
WiFi only
:
TX Mode: (Throughput mode) 170mA (MCS7/BW40/13dBm)
RX Mode: (Throughput mode) 130mA (MCS7/BW40/-60dBm)
Associated Idle power saving with DTIM=3 2.1mA
Unassociated Idle: 0.1mA
RF disable Mode:
BT:
Inquiry & Page Scan: 0.9 mA
ACL no traffic:
SCO HV3:
6
6223E-UUD
0.1mA
7.5mA
15.0mA
