4. WiFi/BT RF Specification

4.1 2.4GHz RF Specification

Feature
Operating Frequency
Standards
Modulation
PHY Data rates
EVM
FN-LINK TECHNOLOGY LIMITED
Description
2.400～2.4835GHz
WiFi:
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n,
IEEE 802.11d, IEEE 802.11e, IEEE 802.11h,
IEEE 802.11i
BT:
V2.1+EDR/BT v3.0/BT v3.0+HS/BT v4.2
WiFi:
802.11b: CCK(11, 5.5Mbps), QPSK(2Mbps),
BPSK(1Mbps),
802.11 g/n: OFDM
BT:
8DPSK, π/4 DQPSK, GFSK
WiFi:
802.11b: 11,5.5,2,1 Mbps
802.11g: 54,48,36,24,18,12,9,6 Mbps
802.11n: up to 150Mbps
BT:
1 Mbps for Basic Rate
2,3 Mbps for Enhanced Data Rate
802.11b /1Mbps : EVM≦-10dB
802.11b /11Mbps : EVM≦-10dB
802.11g /6Mbps : EVM≦-5dB
802.11g /54Mbps : EVM≦-25dB
802.11n /6.5Mbps : EVM≦-5dB
802.11n /65Mbps : EVM≦-28dB
802.11n /13.5Mbps : EVM≦-5dB
802.11n /135Mbps : EVM≦-28dB
