OPERATOR MANUAL
IMPORTANT INFORMATION, KEEP FOR OPERATOR
This manual provides information for:
MODEL HY-6G
HYPERSTEAM™
ATMOSPHERIC
CONVECTION STEAMER
· Self Contained
· Gas
· Capacity: 6 Steamer Pans (12" x 20" x 2-1/2")
THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE.
READ, UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND
WARNINGS CONTAINED IN THIS MANUAL.
WARNING / FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
POST IN A PROMINENT LOCATION
Instructions to be followed in the event user smells
gas. This information shall be obtained by consulting
your local gas supplier. As a minimum, turn off the gas
and call your gas company and your authorized service
agent. Evacuate all personnel from the area.
WARNING
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, injury or
death. Read the installation, operating and maintenance
instructions thoroughly before installing or servicing this
equipment.
NOTIFY CARRIER OF DAMAGE AT ONCE
It is the responsibility of the consignee to inspect the container upon receipt of
same and to determine the possibility of any damage, including concealed dam-
age. Unified Brands suggests that if you are suspicious of damage to make a
notation on the delivery receipt. It will be the responsibility of the consignee to file
a claim with the carrier. We recommend that you do so at once.
Manufacture Service/Questions 888-994-7636.
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
PART NUMBER 141601 REV F (07/14)
1055 Mendell Davis Drive
Jackson, MS 39272
888-994-7636, fax 888-864-7636
unifiedbrands.net

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HY-6G HYPERSTEAM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Groen HY-6G HYPERSTEAM

Summary of Contents for Groen HY-6G HYPERSTEAM

  • Page 1 OPERATOR MANUAL IMPORTANT INFORMATION, KEEP FOR OPERATOR This manual provides information for: MODEL HY-6G HYPERSTEAM™ ATMOSPHERIC CONVECTION STEAMER · Self Contained · Gas · Capacity: 6 Steamer Pans (12” x 20” x 2-1/2”) THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ, UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS CONTAINED IN THIS MANUAL.

  • Page 2: Important Operator Warnings

    LEVEL THE UNIT FRONT TO BACK, OR PITCH IT SLIGHTLY TO THE REAR, TO AVOID DRAINAGE PROBLEMS. CAUTION: MAKING ANY ELECTRICAL OR MECHANICAL CHANGE IN THE UNIT WITHOUT PRIOR APPROVAL FROM GROEN FOOD SERVICE ENGINEERING WILL VOID ALL WARRANTIES. WARNING: TO AVOID DAMAGE OR INJURY, FOLLOW THE WIRING DIAGRAM EXACTLY WHEN CONNECTING A UNIT.
  • Page 3 USE NO DE-GREASER THAT CONTAINS POTASSIUM HYDROXIDE OR SODIUM HYDROXIDE OR THAT IS ALKALINE. WARNING: USE OF ANY REPLACEMENT PARTS OTHER THAN THOSE SUPPLIED BY GROEN OR THEIR AUTHORIZED DISTRIBUTOR VOIDS ALL WARRANTIES AND CAN CAUSE BODILY INJURY TO THE OPERATOR AND DAMAGE THE EQUIPMENT. SERVICE PERFORMED BY OTHER THAN FACTORY- AUTHORIZED PERSONNEL WILL VOID ALL WARRANTIES.

  • Page 4: Table Of Contents

    Table of Contents Important Operator Warnings ............page 2-3 References..................page 4 Equipment Description..............page 5 Water Quality and Treatment ............page 6 Inspection and Unpacking ............page 7 Installation .................. page 8-9 Initial Start-Up................page 10 Operation ................page 11-12 Cleaning..................

  • Page 5: Equipment Description

    WARNING Your Groen HY-6G HyPerSteam Convection Steamer is designed to give years of BEFORE REMOVING ANY PARTITION OR service. It has two stainless steel cavities (cooking chambers) which are served by PANEL, TURN OFF THE ELECTRICAL POWER twin, independent atmospheric steam generators which are gas-heated. A powerful AND LET THE FAN STOP ROTATING.

  • Page 6: Water Quality And Treatment

    Water Quality & Treatment It is essential to supply the steam generator with water that will not form scale or cause corrosion. Even though the steam generator is engineered to minimize scale formation and the effects of corrosion, their development depends on the quality of your water and Treated the number of hours per day you operate the equipment.

  • Page 7: Inspection And Unpacking

    Inspection & Unpacking CAUTION Your HY-6G HyPerSteam will be delivered completely assembled in a heavy shipping SHIPPING STRAPS ARE UNDER TENSION carton and attached to a skid. On receipt, inspect the carton carefully for exterior AND CAN SNAP BACK WHEN CUT.

  • Page 8: Installation

    Installation WARNING The HY-6G steamer is suitable for installation on or near both combustible and THE UNIT MUST BE INSTALLED BY noncombustible surfaces. Minimum installation clearances are: PERSONNEL WHO ARE QUALIFIED TO WORK Right Side 2 inches WITH GAS, ELECTRICITY AND PLUMBING. Left Side 0 inches IMPROPER INSTALLATION CAN CAUSE...

  • Page 9: Installation

    Installation For a unit on casters, complete connection to the gas supply with connectors that comply with the standard for connectors for moveable gas appliances, ANSI Z21.69 — latest edition. Restrain movement of the unit by attaching a cable or chain to the eyelet (provided at the back of the frame) and anchoring the cable or chain to the wall or floor.

  • Page 10: Initial Start-Up

    The steam generator will fill with water. NOTE: For operation at high altitudes (2000 feet and above) please consult the Groen NOTE: The door MUST be closed for the main burner to work. Food Service Engineering Department.

  • Page 11: Operation

    Operation WARNING NOTE: Before the steamer can be operated as described in this section, the pilot ALL POTENTIAL USERS OF THE EQUIPMENT burner flame must be established. For details see the Initial Start-Up section and the SHOULD BE TRAINED IN SAFE AND CORRECT Automatic Operation of Pilot on previous page.
  • Page 12 Operation Operating Procedure Press the ON switch/pad for the steamer. The steam generator will fill, and heat until the READY light comes on. (Aprox. 10 minutes.) Load food into pans in uniform layers. Pans should be filled to about the same levels, and should be even on top.

  • Page 13: Cleaning

    Stainless steel exterior cleaner such as Zepper® CLEAN ANY PART OF THE UNIT. Steam generator de-liming agent, such as Groen Delimer Descaler. A liquid de-liming agent will be easier to use than crystals or powders. See the DON’T MIX DE-LIMING AGENTS (ACID) WITH DE- warning about chlorides, below GREASERS (ALKALI) ANYWHERE IN THE UNIT.
  • Page 14 DELIME and POWER lights remain on (all lights will turn on, then off, except DELIME and POWER). STEP 4 After 5 minutes, beeper will beep rapidly, signaling you to add Groen De- limer/ Descaler. Door(s) must remain closed for entire delime cycle. Deliming...

  • Page 15: Maintenance

    Certain parts may need replacement after prolonged use. If THE UNIT CONTAINS NO FUSES THAT SHOULD there is a need for service, only Groen personnel or authorized Groen representatives BE REPLACED BY THE OPERATOR. should perform the work. Always supply water with a low mineral count that meets the standards outlined in the Water Conditioning section of this manual.

  • Page 16: Troubleshooting

    Troubleshooting This Groen Steamer is designed to operate smoothly and efficiently if properly maintained. However, the following is a list of checks to make in the event of a problem. Wiring diagrams are furnished inside the service panel. If an item on the check list is marked with (X), it means that the work should be done by a factory-authorized service representative.
  • Page 17 Parts List External Cabinet & Sheet Metal To order parts, contact your authorized Groen Service Agency. Supply the model designation, Description Part # part description, part number, quantity, and where applicable, voltage and phase. Lower Side Panels 096848 Lower Front Panel...
  • Page 18 Parts List Cavity Control Section Description Part # Top Cover Clip 123156 Timer 096826 Door Switch 096857 Ready Thermostat 088865 Steam Port 141366 Steam Hose, Top 141461 Steam Hose, Bottom 141462 1d” Hose Clamp 127525 Fan Motor 096740 Motor Capacitor 096812 Control Board 141082...
  • Page 19 Description Part # Adjustable Table Leg 042505 Gas Switch 087951 Main Gas Valve: Natural Gas 098443 Propane Gas 098444 Alternate Main Gas Valve 099988 Outer Steam Generator Assy 141618 Inner Steam Generator Assy 141618 Water Fill Hose 096772 Water Level Probe, Right 141285 Water Level Probe, Left 141424...
  • Page 20 Parts List Steam Motor & Controls Description Part # Fan Motor w/Mounting Plate 096740 Motor Shaft Seal 096868 Motor Insulator 094135 096790 Timer 096826 Control Board 141082 Timer Knob 123100 Door Switch 096857 Steam Port Kit* 141617 Ready Thermostat 088865 Steam Port Gasket 099250 Timer Fastener Nut...
  • Page 21 Parts List Steam Generator Individual Parts Description Part # Steam Generator Weldment 141619 Right Steam Generator Insul. 096896 Left Steam Generator Insul. 096770 Safety Valve 106392 Drain Box Spray Nozzle 081670 Water Level Probe Right 141285 Water Level Probe Left 141424 2-1/4”...
  • Page 22 Parts List Steamer - Individual Parts Description Part # MAin Gas Valve 099988 Gas Manifold, Left 141341 Gas Manifold, Right 141341 Igniter Module 085153 Solenoid Gas Valve 099906 Pilot Gas Switch 087951 Water Inlet Mounting for 2 071235 Outlet Split Water Control Transformer 094164 Steam Generator Drain Valve...

  • Page 23: Electrical Schematic

    Electrical Schematic OM-HY/6G...

  • Page 24: Service Log

    Service Log Model No: Purchased From: Serial No: Location: Date Purchased: Date Installed: Purchase Order No: For Service Call: Date Maintenance Performed Performed By OM-HY/6G...
  • Page 25 OM-HY/6G...
  • Page 26 OM-HY/6G...
  • Page 27 OM-HY/6G...
  • Page 28 1055 Mendell Davis Drive • Jackson MS 39272 888-994-7636 • 601-372-3903 • Fax 888-864-7636 unifiedbrands.net PART NUMBER 141601 REV F (07/14) © 2014 Unified Brands. All Rights Reserved. Unified Brands is a wholly-owned subsidiary of Dover Corporation.
