American Standard Town Square S T45550X Installation Instructions

TOWN SQUARE
PRESSURE BALANCING
BATH AND SHOWER
TRIM KIT
Thank you for selecting American Standard...
the benchmark of fine quality for over 140 years.
To ensure that your installation proceeds smoothly-please
read these instructions carefully before you begin.
RECOMMENDED TOOLS
Plumbers' Putty
or Caulking
ROUGHING-IN DIMENSIONS
• To assure proper positioning in relation to wall.
Note roughing-in dimensions.
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2018
INSTALLATION
INSTRUCTIONS
S
®
Phillips Screwdriver
Teflon Tape Flat Blade Screwdriver
3-1/2"
(90 mm)
6-3/4"
(72 mm)
FINISHED WALL
74" FOR HEAD
CLEARANCE
(188 cm)
(188 mm)
18" OPTIONAL
(457 mm)
2-7/8"
(72 mm)
4" (102 mm)
7-3/8" (187 mm)
TOP OF
TUB RIM
BOTTOM OF
TUB
T45550X
Adjustable Wrench
1-5/8" TO 3-1/4"
7-1/8"
(41 mm TO 83 mm)
(181 mm)
2-1/2"
(64 mm)
1/2" NPT
9-1/8"
1/2" NPT
(232 mm)
7-3/8"
2-5/8"
(66 mm)
1/2" COPPER
1-3/4" MIN.
(44 mm)
- 1 -
Certified to comply with ANSI A112.18.1M
Channel Locks
M965904 (4/18)
