Stryker Performance-LOAD Operation Manual page 37

Electrostatic discharge
(ESD)
IEC 61000-4-2
Power frequency (50/60 Hz)
magnetic field
IEC 61000-4-8
N N o o t t e e : : U is the a.c. mains voltage before applications of the test level.
T
Conducted RF
IEC 61000-4-6
Radiated RF
IEC 61000-4-3
6392-009-001 Rev D.3
G G u u i i d d a a n n c c e e a a n n d d m m a a n n u u f f a a c c t t u u r r e e r r ' ' s s d d e e c c l l a a r r a a t t i i o o n n - - e e l l e e c c t t r r o o m m a a g g n n e e t t i i c c i i m m m m u u n n i i t t y y
+8 kV contact
+15 kV air
30 A/m
3 Vrms
150 kHz to 80 MHz
10 V/m
80 MHz to 2.5 GHz
+8 kV contact
+15 kV air
30 A/m
3 Vrms
10 V/m
Floors should be wood,
concrete, or ceramic tile. If
floors are covered with
synthetic material, the
relative humidity should be
at least 30%.
Power frequency magnetic
fields should be at levels
characteristic of a typical
location in a typical
commercial or hospital
environment.
Portable and mobile RF
communications equipment
should be used no closer to
any part of P P e e r r f f o o r r m m a a n n c c e e - -
L L O O A A D D , including cables,
than the recommended
separation distance
calculated from the equation
appropriate for the
frequency of the transmitter.
Recommended separation
distance
D=(.35) (√ P )
80 MHz to 800 MHz
D=(0.70) (√ P )
800 MHz to 2.5 GHz
where P is the maximum
output power rating of the
transmitter in watts (W)
according to the transmitter
manufacturer and d is the
recommended separation
distance in meters (m).
Field strengths from fixed
RF transmitters, as
determined by an
electromagnetic site a
should be less than the
compliance level in each
frequency range. b
Interference may occur in
the vicinity of equipment
marked with the following
symbol:
33 EN
