Digitus DN-11007-N User Manual

Digitus DN-11007-N User Manual

Internet usb multi-function router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DN-11007-N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Digitus DN-11007-N

Summary of Contents for Digitus DN-11007-N

  • Page 2 DN-11007-N Internet USB Multi-Function Router User’s Manual...
  • Page 3 Copyright Statement This user’s manual, includes the products and software may be reproduced, transcribed, transmitted and stored. That totally depends on the legal authorized copyright. Furthermore, it can be translated into any language in any form or by any means, except some documents or public software without the copy permission of our company.
  • Page 4 Warranty One-Year Warranty is provided for consumer products. This warranty is subject to the conditions and limitations set forth herein. ("We") warrants and tests the Product to be free from defects in material and workmanship and to conform to published specifications.
  • Page 5 Safety Statements This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation. This device has been tested and has to comply with Part 15 of the Federal Communications Commission (FCC) rules.

  • Page 6: Table Of Contents

    ............................13 ARDWARE ONNECTIONS 1.8 G IP A & M ......................16 ET YOUR UTOMATICALLY ANUALLY Chapter 2: DN-11007-N Home page............18 2.1 H DN-11007-N H ........................18 OW TO LINK OME PAGE 2.2 H DN-11007-N’ ......................19 OW TO ENTER S SETTING ITEMS Chapter 3: DN-11007-N Settings..............20...
  • Page 7 3.4.2 Virtual Server ..............................38 3.4.3 Virtual DMZ..............................40 3.5 I ..............................41 NTERNET IREWALL 3.5.1 WAN & LAN Filter............................41 3.5.2 MAC Address Filter............................43 3.5.3 URL Filter................................ 45 3.6 USB A ..............................46 PPLICATION 3.6.1 FTP Server..............................46 3.6.2 Web Camera..............................

  • Page 8: Chapter 1: Introduction & Installation

    Chapter 1: Introduction & Installation 1.1 Overview DN-11007-N is the latest model of networking product. It not only has the basic Internet firewall and IP sharing functions, but also contains several unique features, for instance, webcam monitor, print server, FTP server. The installations of Internet (via WAN with XDSL or Cable Modem) and local network (via LAN with computers) are shown as below.

  • Page 9: The Installation Of Lan With Computers

    With LPR protocol, users can share a printer from both WAN and LAN. 1.2.3 FTP Server DN-11007-N supports FAT 16/ FAT 32 file system format. Plug with USB hard drive or thumb drive, DN-11007-N becomes a FTP server and users can share files from both WAN and LAN.

  • Page 10: Specifications

    1.3 Specifications WAN port Interface Conforms to IEEE802.3 (100 BASE-TX/10 BASE-T) and bit rate 10/100 Mbps with auto cross-over function (MDI-X) Protocol TCP/IP Transmission encoding method Ethernet 100 BASE-TX 4B5B/MLT-3 and 10 BASE-T Manchester coding port connector RJ45 Access method CSMA/CD Transmission rate 10/100 Mbps (auto-sensing)

  • Page 11: System Requirements

    1.4 System Requirements To begin using DN-11007-N, you must have the following minimum system requirements. A. ADSL/Cable Modem and broadband Internet Account. B. One Ethernet (10 BASE-T or 10/100 BASE-TX) network interface card. C. TCP/IP and at least one web browser software installed (E.g.: Internet Explorer or Netscape).

  • Page 12: Front Panel Led Indicators

    XDSL or Cable Modem is connected. Off: Your WAN port can' work. Please check the networking cable whether it is connected to your DN-11007-N properly, or check your ISP. Flashing: Modem is sending/ receiving data. E. RESET Button To restore the factory default values.

  • Page 13: Hardware Connections

    Rear Panel A. Power Inlet: For Power Adapter (5VDC/2A). Incorrect type will damage DN-11007-N. B. USB Port: For USB 1.1/ 2.0 devices. (REF: Chapter5) C. LAN Port (RJ-45): For computer, switch and hub. D. WAN Port (RJ-45): XDSL/ Cable Modem.
  • Page 14 2. If you want to connect a printer, please follow the figure below. 3. If you want to connect a USB hard disk, please follow the figure below.
  • Page 15 4. If you want to put all devices mentioned above and connect PCs together, please follow the figure below.

  • Page 16: Get Your Ip Automatically & Manually

    1.8 Get your IP Automatically & Manually After connecting DN-11007-N to your computer, please make sure your IP is in the automatic IP position or you want it manually. If you don’t know how to enter the settings, please follow the steps below.
  • Page 17 10 to be the example.) Notice: IP address and Default gateway couldn’t be the same. Subnet Mask: 255.255.255.0 (same as the DN-11007-N) Gateway: 192.168.1.1 (this is the IP address of DN-11007-N) DNS: 192.168.1.1 (use the DN-11007-N IP address or your own choice).

  • Page 18: Chapter 2: Dn-11007-N Home Page

    Chapter 2: DN-11007-N Home page In this Chapter, DN-11007-N Home page is divided into two parts. The first part is How to link DN-11007-N’s Home page. Follow the instructions, you can know how to get in DN-11007-N’s setting screen easily. The second part is How to enter DN-11007-N’s setting items.

  • Page 19: How To Enter Dn-11007-N's Setting Items

    Select the functional items you want under the Main Menu bar to do related settings. 2.2 How to enter DN-11007-N’s setting items The Main Menu includes total 9 functional items as showed below. Select a specific item you want in the left panel and it will reveal its sub-menu items. Follow the instructions of...

  • Page 20: Chapter 3: Dn-11007-N Settings

    Home Home page lists all functional items for your quick link. Click this item will also help you to back to DN-11007-N’s Main Menu. The 6 functional items, showed on the central part are the most common use, Quick Setup, IP Sharing, Internet Firewall, USB Application, Printer Sharing and Status &...

  • Page 21: Quick Setup

    Select Quick Setup menu to enter the Quick Setup page. DN-11007-N supports four WAN connection types. These types are selected from the drop-down menu beside WAN Connection Type. The setting fields will differ depending on what kind of connection type you select. Follow the instructions to setup DN-11007-N.

  • Page 22: Adsl Static Ip

    【Step4】 It will take you 15 seconds to save your settings and restart the device. 3.2.2 ADSL Static IP If your ISP supply you the Static IP connection type, please follow the steps to setup your WAN connection. 【Step1】 1. Select ADSL Static IP. 2.

  • Page 23: Automatic Ip

    【Step4】 It will take you 15 seconds to save your settings and restart the device. 3.2.3 Automatic IP If your ISP supply you the Automatic IP connection type, please follow the steps to setup your WAN connection. 【Step1】 1. Choose Automatic IP. 2.

  • Page 24: Cable Modem (Dhcp)

    3.2.4 Cable Modem (DHCP) If your ISP supply you the Cable Modem (DHCP) connection type, please follow the steps to setup your WAN connection. 【Step1】 1. Choose Cable Modem (DHCP). 2. Then, click Next. 【Step2】 If you don’t want to do any block setting, please ignore the item 1 and 2.

  • Page 25: Ip Config

    3.3.1 WAN & LAN Select WAN & LAN in the IP Config menu. DN-11007-N supports four WAN connection types as listed below: ADSL Dialup (PPPoE) ADSL Static IP Automatic IP Cable Modem (DHCP). Follow the instructions to enter the WAN & LAN page.
  • Page 26 (your_name). ＊2: You can change this default LAN IP address depending on demand, for example, 192.168.2.X. Please notice that means you have to login DN-11007-N’s setting screen with the same LAN IP address, 192.168.2.X.
  • Page 27 3.3.1.2 ADSL Static IP If your WAN connection type is ADSL Static IP, please follow the instructions to complete the setup of WAN connection. 1. WAN Connection Type: Select ADSL Static IP from the menu of WAN Connection Type first. 2.
  • Page 28 ＊3: You can change this default LAN IP address depending on demand, for example, 192.168.2.X. Please notice that means you have to login DN-11007-N’s setting screen with the same LAN IP address, 192.168.2.X. 3.3.1.3 Automatic IP If your WAN connection type is Automatic IP, please follow the instructions to complete the setup of WAN connection.
  • Page 29 Click Apply to save the settings. If you want to clean the settings, please click Cancel. 192.168.1.1 255.255.255.0 ＊5: You can change this default LAN IP address depending on demand, for example, 192.168.2.X. Please notice that means you have to login DN-11007-N’s setting screen with the same LAN IP address, 192.168.2.X.

  • Page 30: Dhcp Server

    3.3.2 DHCP Server This section lists all the computers and other devices that DN-11007-N detects on your network. Please follow the instructions to configure your settings. Select DHCP Server in the IP Config menu. DN-11007-N supports up to 253 IP addresses for your local network.
  • Page 31 When you enable DHCP on a network, you allow DN-11007-N to assign temporary IP addresses to your computers whenever they connect to your network. The assigning device is called a DHCP Server, and the receiving device is a DHCP client.

  • Page 32: Routing Table

    3.3.3 Routing Table This function allows you to add routing rules into DN-11007-N. It is useful if you connect several computers behind DN-11007-N to share the same connection to Internet. Follow the steps. Select Routing Table in the IP Config menu.
  • Page 33 Please follow the instructions to complete the setup of Dynamic Route. 1. RIP Setup: The default RIP Setup is in the Rip2 position. Enable this function. Your DN-11007-N will build a routing table automatically, and get a path to the destination.

  • Page 34: Miscellaneous

    Tips are given when you move your cursor over each item. ※ Notice: After setting DN-11007-N’s external devices, such as USB Web Camera, USB Printer, USB HD, you can make choice if open rights to allow clients to access from WAN.
  • Page 35 Select Yes or No to enable or disable the DDNS Client. 2. Server: Select DynDNS.org or TWNIC embedded in DN-11007-N. You also can click Free Trial behind this field to link up a free trial address. 3. User Name or E-mail Address: User Name or E-mail Address is used as an identity to login Dynamic-DNS or TWNIC service.

  • Page 36: Nat Setting

    3.4 NAT Setting NAT Setting It contains three functional items under NAT Setting, such as Port Trigger, Virtual Server and Virtual DMZ. Follow the instructions to configure your settings. ※ Tips are given when you move your cursor over each item.
  • Page 37 【Step1】 This is the outgoing (outbound) port number for a particular application. Select Yes to enable Port Trigger if you need to use Port Trigger special application. ※ Notice: Only a LAN client can use a particular special application at a time. The range of the trigger ports is from 0 to 65535.

  • Page 38: Virtual Server

    3.4.2 Virtual Server DN-11007-N has built-in firewall function, which makes all hosts behind DN-11007-N are invisible to the outside. If you would like to set up servers, such as web server or mail server. Follow the steps. Select Virtual Server...
  • Page 39 1. Enable Virtual Server? Select Yes to enable Virtual Server, otherwise, please ignore it. 2. Well-Known Applications: Please select one of Well-Known Applications. The Information of Local Port, Server Port, Protocol and Description will be shown automatically. If there is no one you can choose in the item of Well-Known Applications.

  • Page 40: Virtual Dmz

    (for example, a web, gaming, or messaging server) to operate correctly from inside your DN-11007-N firewall. Follow the steps. (Caution: Enabling this function might expose the virtual DMZ host as well as your entire network to increase security risk.)

  • Page 41: Internet Firewall

    Select Yes to enable the firewall, it can help you to reduce the risk of outside unauthorized access. 2. Enable Firewall Log? Select Yes to enable the firewall Log. As you enable this function, your DN-11007-N system will be logged accordingly when the packets dropped.
  • Page 42 【Step2】 For the advanced settings of Internet Firewall, please follow the steps below. 1. Well-Known Applications: You can select any pre-configured service from the drop-down list of Well-Known Applications. The pre-configured services include WWW, ICQ, REAL PLAYER/ QuickTime, Telnet, FTP, MSN Messenger, MIRC, NET Meeting (1)~(4). If you select one of them, a port number will appear in the Destination Port Range at the same time.

  • Page 43: Mac Address Filter

    You can control over your LAN ports easily. It means that it will enhance your internal network security through the MAC address settings. Actually, managers can allow or disallow one or more LAN ports they assigned passing DN-11007-N during a specific time. 【Step1】...
  • Page 44 【Step2】 Select MAC Address Filter in the Internet Firewall menu. Follow the instructions to enter the MAC Address Filter page to configure the settings you want. ※ Tips are given when you move your cursor over each item. 【Step3】 1. Enable filter? Select Yes to enable filter function.

  • Page 45: Url Filter

    3.5.3 URL Filter As long as you give the keyword and timing in the URL Filter, your LAN ports clients can’t get into the website in the certain period of time with the same keyword among the website address string. Select Filter in the Internet Firewall...

  • Page 46: Usb Application

    Moreover, through the Printer settings, users can share the printer from both WAN and LAN. 3.6.1 FTP Server WARNING: Before connecting with your USB HD to DN-11007-N, please make sure that DN-11007-N is in Power-Off condition. Select FTP Server...
  • Page 47 Account Table. Click Del to erase one datum in the list table. Apply Click Apply to complete DN-11007-N’s FTP Setup. If you want to clean the settings, please click Cancel. All being used functional buttons, includes Add, Del and Cancel...
  • Page 48 ● ● ● 【Step2】 Address Open Internet browser and input ftp://192.168.1.1 in the web address field, then press Enter. User Name, Password & Login Input User Name and Password you have set before, then click Login. The data folders will appear.

  • Page 49: Web Camera

    ※ Notice: If you select Yes, users can access your FTP Server from WAN; On the contrary, users only can access your FTP Server from LAN. ● 3.6.2 Web Camera WARNING: Before connecting with your USB Web Camera to DN-11007-N, please make sure that DN-11007-N is in Power-Off condition. Select Web Camera...
  • Page 50 3.6.2.1 IE Browser’s Settings 【Step1】 Open Internet browser and click Tools tab and Internet Options…. 【Step2】 1. Click Security. 2. Click Custom Level…. 3. Click OK.
  • Page 51 【Step3】 1. Select Enable in the items. 2. Click OK. 【Step4】 Click Yes. 3.6.2.2 Configure and Use Web Camera 【Step1】 Open Internet browser. Input 192.168.1.1 in the address field. 192.168.1.1...
  • Page 52 After finishing the settings above, you can access the video screen directly follow the steps. 1. From outside (WAN): Input DN-11007-N’s WAN IP/webcam.htm in the address field, when you access from outside. 2. From your local network (LAN): Input DN-11007-N’s LAN IP/webcam.htm in the address field, when you access...
  • Page 53 【Step3-2】Using Java mode to preview 1. USB Application & Web Camera Click Web Camera in the USB Application menu. 2. Web Camera Mode: Select Java Preview and click Preview. The following video screen will appear immediately. ※ Notice: If you select JAVA mode preview, please download JAVA software from http://www.java.com/en/download/manual.jsp.
  • Page 54 After downloading and installing the Java software, you can access the video screen directly follow the steps. 1. From outside (WAN): Input DN-11007-N’s WAN IP/showwebcam.htm in the address field, when you access from outside. 2. From your local network (LAN): Input DN-11007-N’s LAN IP/showwebcam.htm in the address field, when you...
  • Page 55 3. Add Favorites Click OK. 4. DN-11007-N ACTIVEX Web Camera Click DN-11007-N ACTIVEX Web Camera then the monitor screen will appear. 3.6.2.4 Webcam Application from WAN with DDNS For more DDNS information, please check on Chapter 4 DDNS Service. 1. Open Internet browser Input your hostname/webcam.htm from WAN, DN-11007-N/webcam.htm for...
  • Page 56 DN-11007-N/webcam.htm 3.6.2.5 Store Webcam’s File In order to store files, please move your cursor on the active window and click the right or left buttons. SAVE 1. One Left click to get a picture, and save as a *.bmp file Record 2.
  • Page 57 3.6.2.6 Security Mode Settings 1. Enable Security Mode? If you want to set a time period for your webcam to work, please click Yes to enable security mode. If you click No, please don’t do the following steps. 2. Sense Level: Give your webcam a sense level, high, medium or low, in order to operate itself automatically, when moving objects pass.

  • Page 58: Print Server

    WARNING: Before connecting with your USB Printer to DN-11007-N, please make sure that DN-11007-N is in Power-Off condition. 3.6.3 Print Server Print Server Setup Select Print Server in the USB Application menu. Follow the instructions to enter the Print Server page and finish the settings to share a USB printer from both WAN and LAN.
  • Page 59 3.6.3.1 Share USB printer on your local network Please follow the steps to complete DN-11007-N printer settings and the printer configuration on Windows platforms. 1. USB Application & Print Server Click Print Server in the USB Application menu. The screen of Printer Setup will appear.
  • Page 60 3.6.3.2.1 For Windows XP Please follow the steps below to complete the printer configuration for Windows XP platform. 【Step1】 Go to desktop and click Start > Printer and Faxes. 【Step2】 Double click Add a printer. 【Step3】 Select Create a new port. Select the Type of port: Standard TCP/IP Port.
  • Page 61 【Step4】 Click Next. 【Step5】 1. Input 192.168.1.1 in the IP Address field. 2. Give this port a name “Printer1” for example. Printer1 3. Click Next. 【Step6】 1. Select Custom. 2. Click Settings.
  • Page 62 【Step7】 1. The information you had input will be showed on this screen. Printer1 2. Select LPR. 3. Input Queue Name “111” for example, which must be the same as the USB Printer Name you set on Print Server setting page.
  • Page 63 【Step10】 1. Your computer will supply a name for this printer automatically or you can change it. 2. Click Next. 【Step11】 1. Select Yes or No to print a test page or not. 2. Click Next. 【Step12】 It shows you the printer settings that you have specified, and then click Finish.
  • Page 64 【Step13】 Click OK. If the test page isn’t printed out, click Troubleshoot. 3.6.3.2.2 For Windows 2000 Please follow the steps below to complete the printer configuration on Windows 2000 platform. 【Step1】 Go to desktop and click Start > Settings > Printers. 【Step2】...
  • Page 65 【Step3】 Click Next. 【Step4】 Click Next. 【Step5】 Select Create a new port. Select the Type: Standard TCP/IP Port. Click Next. 【Step6】 Click Next.
  • Page 66 【Step7】 1. Input 192.168.1.1 in the IP Address field. 2. Give this port a name “Printer1” for example. Printer1 3. Click Next. 【Step8】 1. Select Custom. 2. Click Settings. 【Step9】 1. The information you had input will Printer1 be shown on this screen. 2.
  • Page 67 【Step10】 Click Next. 【Step11】 Click Finish. 【Step12】 1. Select your printer’s manufacturer “Hewlett-Packard” for example. 2. Select your printer’s model “HP deskjet 3500 …” for example. 3. If yours is not on the list, please click Have Disk…to get yours from CD or floppy disc.
  • Page 68 【Step13】 1. If you had installed the print driver, it will appear this window to ask you to keep you own or to replace it. We choose Keep existing driver for example. 2. Click Next. 【Step14】 1. Your computer will supply a name for this printer automatically or you can change it.
  • Page 69 【Step16】 1. You can describe the location and capabilities of this printer or ignore it. 2. Click Next. 【Step17】 1. Select Yes or No to print a test page or not. 2. Click Next. 【Step18】 It shows you the printer settings that you have specified, and then click Finish.
  • Page 70 【Step19】 Click OK. If the test page isn’t printed out, click Troubleshoot. 3.6.3.2.3 For Windows 98 or 98SE From the beginning, there must be two computers or more in the local network because Windows 98 or 98 SE doesn’t support LPR TCP/IP printer sharing. So in detail there must be at least a Windows 2000 or up platform as the print server because it can share a printer to the client computer with windows98 or 98SE.
  • Page 71 【Step3】 It will appear a pull down menu. Select Sharing… 【Step4】 1. In Shared as field: The default printer model “HP3535” for example will appear. 2. Click Additional Drivers…. 【Step5】 1. Select an operation system platform you want to share. 2.
  • Page 72 【Step6】 1. Click Browse… to find the path where the file is located. 2. Click OK. 【Step7】 Click Apply to finish the settings. 【Step8】 Go to desktop and click Start > Settings > Control Panel. 【Step9】 Double click Administrative Tools.
  • Page 73 【Step10】 Double click Computer Management. 【Step11】 1. Move your cursor on the item Users. 2. Click the right button of your mouse. Select New User…. 【Step12】 1. Input your client computer’s name 111 for example. 2. Select Password never expires. 3.
  • Page 74 3.6.3.2.3.2 Printer Settings on Windows 98 or 98SE 【Step1】 Go to desktop and click Start > Settings > Printers. 【Step2】 Double click Add Printer. 【Step3】 Click Next.
  • Page 75 【Step4】 1. Select Network printer. 2. Click Next. 【Step5】 1. Click Browse…. 【Step6】 1. Find the printer that is attached to the computer “hp3535” for example. 2. Click OK.
  • Page 76 【Step7】 1. The Network path or queue name \\User\hp3535 example will appear automatically. 2. Click Next. 【Step8】 1. The Printer name hp deskjet 3500 series for example will be showed automatically. 2. Click Next. 【Step9】 1. Select Yes to print a test page.
  • Page 77 Power –On and on the LAN. ※ Notice 2: If you want to know whether your inserted device such as USB Web Camera, USB Printer or USB HDD corresponds with DN-11007-N, please check with your product provider.

  • Page 78: System Setup

    Setting, Router Time Setup, Firmware Upgrade, Setting Management, Factory Default and Wake On LAN. Configuring these settings will give you much more control over DN-11007-N. ※ Tips are given when you move your cursor over each item. 3.7.1 Change User Setting...

  • Page 79: Router Time Setup

    2. Apply & Cancel Click Apply to Confirm above settings and save your username and password. If you forget the username and password, please reset DN-11007-N to its factory settings. If you want to clean the settings, please click Cancel. The functional button, Cancel can take effect after click on Apply.
  • Page 80 4. Daylight saving time? If you select Enable, the summer and winter time will be adjusted automatically. If you select Disable, DN-11007-N won’t do anything. 5. User Setup If you prefer getting time manually, please select User Setup and input time information in the blank fields or click Get Time From Local Computer to get time from your computer.

  • Page 81: Firmware Upgrade

    3.7.3 Firmware Upgrade It will show you the DN-11007-N basic information, includes product ID, firmware version and upgrade function. Follow the steps below to configure. Select Firmware Upgrade in the System Setup menu. Follow the instructions to enter the Firmware Upgrade page to configure the settings you want.

  • Page 82: Setting Management

    1. Here Click Here to save your current settings into a file for backing up before you reset DN-11007-N or your settings are missing. 2. New Setting File: If you want to get your original settings back, please click Browse… to find out the path and the file you saved.

  • Page 83: Factory Default

    ※ Tips are given when you move your cursor over each item. 【Step】 You can restore all settings from the Factory Default page. Click Restore and it takes about 15 seconds to restore. When it’s done, the DN-11007-N’s Login Screen page will appear...

  • Page 84: Wake On Lan

    3.7.6 Wake on LAN This function allows the user to switch on a specified computer with a MAC address located on a LAN port of DN-11007-N. Follow the steps below to configure. Select Wake On LAN in the System Setup menu.

  • Page 85: Status & Log

    Follow the instructions to enter the Status page to configure the settings you want. ※ Tips are given when you move your cursor over each item. 【Step1】 System Up Time: System Up Time means the DN-11007-N’s lasting time from System Up to System Down every time.
  • Page 86 【Step2】 1. Connection Type: It means the WAN type you select in previous setting. 2. IP Address: It means the current WAN IP. 3. Subnet Mask: It means the current subnet mask. Default Gateway: It means the current default gateway. DNS Servers: It means the current DNS Server.
  • Page 87 【Step3】 1. IP Address: It means the current LAN IP. 2. Subnet Mask: It means the current Subnet Mask. 3. Mac Address: It means the current Mac Address of LAN Interface. 4. Printer Model: It means the default printer model. 5.

  • Page 88: Dhcp Leases

    3.8.2 DHCP Leases This part lists the computers and other devices that the DN-11007-N detects on your network. Follow the steps below to configure. Select DHCP in the Status & Log menu. Follow the instructions to enter the DHCP Leases page to configure the settings you want.

  • Page 89: System Log

    3.8.3 System Log This part displays all user records of accessing DN-11007-N settings. Select System Log in the Status & Log menu. Follow the instructions to enter the System Log page to configure the settings you want. ※ Tips are given when you move your cursor over each item.

  • Page 90: Logout

    3.9 Logout Logout When you click Logout, the DN-11007-N setting page will change to the Login Screen page. Follow the instructions. 【Step1】 Select Logout in the Main Menu. ※ Tips are given when you move your cursor over each item.

  • Page 91: Chapter 4: Ddns Service

    Chapter 4: DDNS Service DDNS is a service let the dynamic IP change to the static IP. The settings of DDNS can solve the problem of being given the different IP every time. After setting the Router, your hostname would correspond to your dynamic IP. You just use the hostname instead of your static IP. Moreover, via the hostname application, it could be easier to use your webcam remotely.
  • Page 92 【Step3】 Please finish these blank fields. Then, click Create Account. 【Step4】 When you got this account created message, close it, and check your mailbox. You would get a mail from DynDNS website. 【Step5】 1. Click the mail. 2. Click the address: https://www.dyndns.
  • Page 93 【Step6】 Click login. 【Step7】 Click the Add Host of Dynamic DNS. 【Step8】 1. Input the name created in step2 2. Select one of the tails you like. 3. Then, click Add Host. 【Step9】 Your hostname have been created.

  • Page 94: Chapter 5: Q & A

    A: Check if the output voltage is suitable, or check if the power supply is out of order. 2. Q: The Internet browser still cannot find or connect to the DN-11007-N after verifying the IP address and LAN cable, the changes cannot be made, or password is lost.
  • Page 95 PC.) 10. Q: Why can’t my USB devices work on DN-11007-N? A: Maybe your USB devices and DN-11007-N are not compatible. So if you want to know whether your inserted device such as USB Web Camera, USB Printer or USB HDD corresponds with DN-11007-N, please check with your product provider.
  • Page 96 PCs IP properties. Dynamically from DHCP pool: You can configure the DHCP Server of DN-11007-N and create an address pool with the specified DNS addresses distributed to the PCs. In either case, you can specify the actual addresses of the ISPs DNS servers (on the PC or in the DHCP pool), or you can specify the IP address of the LAN port on DN-11007-N (e.g., 192.168.1.1).

  • Page 97: Chapter 6: Glossary

    Chapter 6: Glossary Broadband: A type of data transmission in which a single medium (such as cable) carries several channels of data at once. Cable Modem (CM): The term "Cable Modem" is quite new and refers to a modem that operates over the ordinary cable TV network cables.
  • Page 98 the computers on your home network is the location of the DNS server your ISP has assigned to you. Firewall: A firewall determines which information passes in and out of a network. NAT can create a natural firewall by hiding a local network’s IP addresses from the Internet. A Firewall prevents anyone outside of your network from accessing your computer and possibly damaging or viewing your files.
  • Page 99 A network mask is also a 32-bit binary pattern, and consists of consecutive leading 1’s followed by consecutive trailing 0’s, such as 11111111.11111111.11111111.00000000. Therefore sometimes a network mask can also be described simply as “x” number of leading 1’s. When both are represented side by side in their binary forms, all bits in the IP address that correspond to 1’s in the network mask become part of the IP network address, and the remaining bits correspond to the host ID.
  • Page 100 Subnet Mask：A Subnet mask is a set of four numbers configured like an IP address. It is used to create IP address numbers used only within a particular network. Ping (Packet Internet or Inter-network) group: A program used to verify whether the host associated with an IP address is online.
