Vehicletool Mini VAG505A Manual page 5

Mini VAG505A/VAG506M/VAG506/V801
⑤ UP/DOWN arrows: moves the selection pointer and scrolls up or down
⑥ LEFT/RIGHT arrows: move cursor. For V801 also to flip page
⑦ USB interface: connect to USB cable
Dimensions: Length 201mm (7.9"), Width 94mm (3.70"),Height 36mm
(1.74")
OBDII connector, 900mm (35.4")
① OBDII Connector: connect car and the scan tool
② LCD screen: Backlit LCD, 128*64 pixel display.
③ ENTER key: confirm selection and enter
④ Esc key:
⑤ LEFT/RIGHT arrows: move cursor.
⑥ up/down arrows: moves the selection pointer and scrolls up or down
⑦ USB interface: connect to USB cable
Dimensions: Length
(0.90")
OBDII connector, 735mm (28.9")
VAG506M
2
3
5
go back to the previous screens
125mm (4.92"), Width 75 mm
5
1
4
6
(2.95"),Height 23 mm
