INSTRUCTION MANUAL 499430
®
MASTER COMBOGEAR
RIGHT ANGLE C-FACE REDUCERS
SERVICE AND REPAIR
SIZES C150, C200, C262, C350
WARNING: Because of the possible danger to person(s) or property which may result from improper use of products, it is important that correct
procedures be followed. Products must be used in accordance with the Engineering information specified in the catalog. Proper installation, operation
and maintenance procedures must be observed. The instructions in the instruction manuals must be followed. Inspections should be made as
necessary to assure safe operation under prevailing conditions. Proper guards and other suitable safety devices or procedures as may be desirable or
as may be specified in safety codes should be provided, and are neither provided by Master Power Transmission nor are the responsibility of Master
Power Transmission. This unit and its associated equipment must be installed, adjusted and maintained by qualified personnel who are familiar with the
construction and operation of all the equipment in the system and the potential hazards involved. When risk to persons or property may be involved, a
failsafe device must be an integral part of the driven equipment beyond the speed reducer output shaft.
3300 Tenth St. / Columbus, IN 47201 / (888) 616-1094
www.master-pt.com
Master ComboGear Right Angle Reducer Instruction Manual 499430
10/2013
